TM
Altos BrainSphere
T15 F6
User Manual
Revision 1.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the Altos BrainSphere T15 F6 and is the answer not in the manual?

Questions and answers

Related Manuals for Acer Altos BrainSphere T15 F6

Summary of Contents for Acer Altos BrainSphere T15 F6

  • Page 1 Altos BrainSphere T15 F6 User Manual Revision 1.0...
  • Page 2 Altos Computing Inc. (abbr. Altos) is established in 2017 and it is a subsidiary of Acer Inc. The business model of Altos is to provide the best streamlined and cost-effective integrated solutions thru in-house R&D working with ODM/IHV/ISV on servers, workstations, thin client, network and storage. In...
  • Page 3 Conventions The following conventions are used in this user's guide: NOTE! Gives bits and pieces of additional information related to the current topic. CAUTION! Gives precautionary measures to avoid possible hardware or software problems. WARNING! Alerts you to any damage that might. result from doing or not doing specific actions.
  • Page 4 Warnings and Cautions Before installing, be sure that you understand the following warnings and cautions. WARNING! To reduce the risk of electric shock or damage to the equipment: • Do not disable the power cord grounding plug. The grounding plug is an important safety feature.
  • Page 5 Electrostatic Discharge (ESD) CAUTION! ESD CAN DAMAGE DRIVES, BOARDS, AND OTHER PARTS. WE RECOMMEND THAT YOU PERFORM ALL PROCEDURES AT AN ESD WORKSTATION. IF ONE IS NOT AVAILABLE, PROVIDE SOME ESD PROTECTION BY WEARING AN ANTI-STATIC WRIST STRAP AT- TACHED TO CHASSIS GROUND -- ANY UNPAINTED METAL SURFACE -- ON YOUR SERVER WHEN HANDLING PARTS.
  • Page 6 CAUTION! Risk of explosion if battery is replaced incorrectly or with an incorrect type. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used bat- teries according to the manufacturer’s instructions.
  • Page 7 Regulatory Notices WEEE Symbol Statement The symbol shown below is on the product or on its packaging, which indicates that this product must be disposed of with other waste. Instead, the device should be taken to the waste collection centers for activation of the treatment, collection, recycling and disposal procedure. The separate collection and recycling of your waste equipment at the time of disposal will help to conserve natural resources and ensure that it is recycled in a manner that protects human health and the environment.
  • Page 8 Electrical appliance specifications and operating temperature: 100-240Vac, 7A-3A, 50-60Hz Rating (AC Input) 100-240Vac, 6A-3A, 50-60Hz Operating Temperature 10°C to 35°C Non-operating temperature -40°C to 60°C Operating humidity 8%-80% (non-condensing) Non-operating humidity 20%-95% (non-condensing) 伺服器相關警告與注意事項 警告 為了避免電擊危險或損壞設備請注意: 不要切斷電源線的接地端子，接地端子是一個很重要的安全防護。 將電源線接到有接地功能的插座，此插座需位於使用者容易使用的範圍。 電源線的配線要避免被踩到，被絆到或被過度彎折，重壓。 警告 本設備關機後內部仍存在電源，須拔掉電源線才能完全切掉設備內部的電源。...
  • Page 9 警告 如果更換錯誤電池會產生爆炸，請以相同或同型號電池更換使用。 廢電池請回收。 警告:如果更換錯誤電池會產生爆炸，請以相同或同型電池更換 注意 伺服器開機時不要長時間移除蓋子，長時間移除蓋子會造成散熱功能失效造成損壞。 注意 靜電會損害電子產品，建議您在符合靜電防護的工作環境操作伺服器，如果無法確定 環境的靜電防護。請穿上靜電手環並且將手環接到有接地的金屬表面如機櫃或機殼。 拿取電路板時僅觸碰板子的邊緣，不要觸碰連接器。板子從防靜電包裝取出後只能放 置在無靜電的桌面，零件面朝上。如果可以, 請使用防靜電泡棉. 避免使用靜電袋. 避免電 路板與任何表面摩擦產生靜電。...
  • Page 10 報驗義務人: 安圖斯科技股份有限公司 新北市汐止區新台五路89號6樓 - 11 -...
  • Page 11 System setup System notes Thank you for purchasing your Altos Server. This user guide is intended as a reference for experienced Server technicians and helps detail many of the features available in Altos server. For more detailed information about any particular component or software solution, you may consult the technical specifications or the user manual for that application.
  • Page 12 Table of Contents Chapter 1 Hardware Installation ..............13 Installation Precautions ................13 Product Specifications ................14 System Block Diagram ................17 Chapter 2 System Appearance ..............18 Front View ....................18 Rear View ....................19 Rear Panel System LAN LEDs ............... 20 Chapter 3 System Hardware Installation ............
  • Page 13 5-2-8 Serial Port Console Redirection ..............47 5-2-9 CPU Configuration ....................51 5-2-10 Network Stack Configuration ................52 5-2-11 CSM Configuration ....................53 5-2-12 Info Report Configuration..................54 5-2-13 NVMe Configuration .................... 55 5-2-14 Offboard SATA Controller Configuration ................56 5-2-15 SATA Configuration .....................
  • Page 14 Chapter 1 Hardware Installation 1-1 Installation Precautions The motherboard/system contain numerous delicate electronic circuits and components which can become damaged as a result of electrostatic discharge (ESD). Prior to installation, carefully read the user manual and follow these procedures: • Prior to installation, do not remove or break motherboard S/N (Serial Number) sticker or warranty sticker provided by your dealer.
  • Page 15 1-2 Product Specifications NOTE: We reserve the right to make any changes to the product specifications and product-related information without prior notice.  System Mini-Tower  386 (D) x 175 (W) x 360 (H) mm (15.2 x 6.89 x 14.17 inches) Dimension ...
  • Page 16  Expansion Slot 1 x PCIe x16 (Gen5 x16) slot; integrated in CPU  1 x PCIe x16 (Gen4 x4) slot; integrated in chipset  1 x PCIe x1 (Gen4 x1) slot; integrated in chipset  2 x M.2 slot for storage: - M-key - PCIe Gen5 x4 from CPU;...
  • Page 17  1 x 500W PSU Power Supply  80 PLUS Bronze  AC Input: - 90-264V; 115V/7A, 230V/3A; 47-63Hz  DC Output: - Max. 500W +12V/ 33.81A +5V/ 9.779A +3.3V/ 9.779A +5Vsb/ 2.02A Realtek® DASH Remote Management System Management  Power state settings (on, off, restart, hibernate, or sleep) ...
  • Page 18 1-3 System Block Diagram Hardware Installation - 19 -...
  • Page 19 Chapter 2 System Appearance Front View No. Description Description 5.25” external Bay HDD Activity LED 2 USB3.2 Gen1 Type-A Ports Mic in (red)/Line out (green) Power Button /LED System Appearance - 20 -...
  • Page 20 Rear View No. Description Description Power Supply Module Cord Socket USB 3.2 GEN 2 Type-A Port 80x80x25 mm System Fan USB 3.2 GEN 2 Type-C Port (5V/1.5A) PCIe Expansion Slots 2.5GBE LAN Port Wi-Fi Antenna GBE LAN Port DP Port 2 USB 3.2 GEN1 Type-A Ports 2 HDMI 2.0 Ports Audio Ports...
  • Page 21 Rear Panel System LAN LEDs Name Color Status Description Yellow 1 Gbps data rate 1GbE Speed Green 100 Mbps data rate 10 Mbps data rate Green Link between system and network or no access 1GbE Link / Blink Data transmission or reception is occurring. Activity LED No data transmission or reception is occurring.
  • Page 22 Chapter 3 System Hardware Installation Pre-installation Instructions Computer components and electronic circuit boards can be damaged by electrostatic discharge. Working on computers that are still connected to a power supply can be extremely dangerous. Follow the simple guidelines below to avoid damage to your computer or injury to yourself.
  • Page 23 Removing and Installing the Chassis Cover Before you remove or install the chassis cover • Make sure the system is not turned on or connected to AC power. Follow these instructions to remove/install the chassis side cover and front bezel: Remove the screw securing the chassis side cover.
  • Page 24 Installing the CPU Read the following guidelines before you begin to install the CPU: • Make sure that the motherboard supports the CPU. • Always turn off the computer and unplug the power cord from the power outlet before installing the CPU to prevent hardware damage.
  • Page 25 Installing the Memory Read the following guidelines before you begin to install the memory: • Make sure that the motherboard supports the memory. It is recommended that memory of the same capacity, brand, speed, and chips be used. • Always turn off the computer and unplug the power cord from the power outlet before installing the memory to prevent hardware damage.
  • Page 26 3-3-2 Installing the Memory Before installing a memory module, make sure to turn off the computer and unplug the power cord from the power outlet to prevent damage to the memory module. Be sure to install DDR5 DIMMs on this motherboard. Follow these instructions to install the Memory: Insert the DIMM memory module vertically into the DIMM slot, and push it down.
  • Page 27 Installing the PCI Expansion Card • Voltages can be present within the server whenever an AC power source is connected. This voltage is present even when the main power switch is in the off position. Ensure that the system is powered-down and all power sources have been disconnected from the server prior to installing a PCIe card.
  • Page 28 Installing the Hard Disk Drive Read the following guidelines before you begin to install the hard disk drive: • Take note of the drive tray orientation before sliding it out. • The tray will not fit back into the bay if inserted incorrectly. •...
  • Page 29 Installing and Removing the M.2 SSD Module Follow the steps below to install an optional M.2 SSD module on your motherboard. Step1. Insert the M.2 SSD module into the slot. Step2. Secure it with the screw, tightening as necessary to fasten the M.2 SSD module in place. Installing and Removing the M.2 WiFi Module Follow the steps below to install a M.2 WiFi module on your motherboard.
  • Page 30 Peripheral Devices Connection System Hardware Installation - 31 -...
  • Page 31 Chapter 4 Motherboard Components Motherboard Components Motherboard Components - 32 -...
  • Page 32 Item Description Audio Connectors GbE LAN Port #1 (Top)/USB 3.2 Ports (Bottom) GbE LAN Port #2 USB 3.2 Port Type A(Top)/USB 3.2 Type C Port (Bottom) HDMI 2.0 Port Display Port 2x4 Pin 12V Power Connector CPU Fan Connector System Fan Connector #4 System Fan Connector #2 2x12 Pin Main Power Connector Battery Socket...
  • Page 33 Jumper Setting Motherboard Components - 34 -...
  • Page 34 Chapter 5 BIOS Setup BIOS (Basic Input and Output System) records hardware parameters of the system in the EFI on the motherboard. Its major functions include conducting the Power-On Self-Test (POST) during system startup, saving system parameters, loading the operating system etc. The BIOS includes a BIOS Setup program that allows the user to modify basic system configuration settings or to activate certain system features.
  • Page 35 ◼ Main This setup page includes all the items of the standard compatible BIOS. ◼ Advanced This setup page includes all the items of AMI BIOS special enhanced features. (ex: Auto detect fan and temperature status, automatically configure hard disk parameters.) ◼...
  • Page 36 5-1 The Main Menu Once you enter the BIOS Setup program, the Main Menu (as shown below) appears on the screen. Use arrow keys to move among the items and press <Enter> to accept or enter other sub-menu. Main Menu Help The on-screen description of a highlighted setup option is displayed on the bottom line of the Main Menu.
  • Page 37 Parameter Description BIOS Information Project Name Displays the project name information. BIOS Version Displays version number of the BIOS setup utility. Build Date and Time Displays the date and time when the BIOS setup utility was created. (Note1) LAN# MAC Address Displays LAN MAC address information.
  • Page 38 Advanced Menu The Advanced Menu displays submenu options for configuring the function of various hardware components. Select a submenu item, then press <Enter> to access the related submenu screen. BIOS Setup - 39 -...
  • Page 39 5-2-1 DASH Configuration Parameter Description Desktop and mobile Architecture for System Hardware (DASH) Configuration RTL8111 ID Displays the vendor ID information. RealManage Implementation Guide Displays the utility version. version Enable/Disable RealMange Firmware Control. (Note) RealMange Firmware Control Options available: Enabled, Disabled. Default setting is Disabled. Enable/Disable DASH Support.
  • Page 40 5-2-2 MCTP Configuration Parameter Description Management Component Transport Protocol (MCTP) Configuration Enable/Disable MCTP Support. (Note) MCTP Support Options available: Enabled, Disabled. Default setting is Disabled. Enable/Disable PLDM Support for SMBios. PLDM for SMBIOS Options available: Enabled, Disabled. Default setting is Enabled. PLDM for BIOS Control and Enable/Disable PLDM Support for BIOS Control.
  • Page 41 5-2-3 Trusted Computing Parameter Description Options available: AMD CPU ftPM, Route to SPI TPM. Default AMD fTPM switch setting is Route to SPI TPM. TPM 2.0 Device Found Firmware Version Displays the firmware version information. Vendor Displays the vendor information. Enable/Disable BIOS support for security device.
  • Page 42 Parameter Description Schedule an operation for the security device. NOTE: Your computer will reboot during restart in order to change Pending operation the state of a security device. Options available: None, TPM Clear. Default setting is None. Enable/Disable platform hierarchy. Platform Hierarchy Options available: Enabled, Disabled.
  • Page 43 5-2-4 ASF Configuration Description Parameter Alert Standard Format (ASF) Configuration ASF BIOS Mode Options available: OFF, On, Alert Only. Default setting is On. Enable/Disable WatchDog Timer. ASF WatchDog Timer Options available: Enabled, Disabled. Default setting is Disabled. BIOS Setup - 44 -...
  • Page 44 5-2-5 Super IO Configuration Description Parameter Super IO Configuration Super IO Chip Displays the super IO chip information Serial Port 1 Press [Enter] for configuration of advanced items. Configuration BIOS Setup - 45 -...
  • Page 45 5-2-5-1 Serial Port 1 Configuration Description Parameter Serial Port 1 Configuration Enable/Disable the Serial Port (COM). When set to Enabled allows you to configure the Serial port 1 settings. When set to Disabled, displays no (Note1) Serial Port configuration for the serial port. Options available: Enabled, Disabled.
  • Page 46 5-2-6 Hardware Monitor Parameter Description CPU FAN Fail Warning Options available: Enabled, Disabled. Default setting is Enabled. SYS FAN1/2/3 Fail Options available: Enabled, Disabled. Default setting is Disabled. Warning Options available: Full Speed, Standard Mode. Default setting is Standard CPU FAN Speed Control Mode.
  • Page 47 5-2-7 S5 RTC Wake Settings Parameter Description Enable/Disable system wake on alarm event. Options available: Disabled, Fixed Time. When Fixed Time is selected, Wake System from S5 system will wake on the hr::min::sec specified. Default setting is Disabled. BIOS Setup - 48 -...
  • Page 48 5-2-8 Serial Port Console Redirection Parameter Description Select whether to enable console redirection for specified device. Console COM Console redirection enables the users to manage the system from a remote (Note) Redirection location. Options available: Enabled, Disabled. Default setting is Disabled. Press [Enter] to configure advanced items.
  • Page 49 Parameter Description  Parity – A parity bit can be sent with the data bits to detect some transmission errors. – Even: parity bit is 0 if the num of 1's in the data bits is even. – Odd: parity bit is 0 if num of 1's in the data bits is odd. –...
  • Page 50 Parameter Description Legacy Console Redirection Press [Enter] to configure advanced items.  Redirection COM Port – Selects a COM port for Legacy serial redirection.  Resolution – Selects the number of rows and columns used in Console Redirection for legacy OS support. –...
  • Page 51 Parameter Description  Flow Control EMS – Flow control can prevent data loss from buffer overflow. When sending data, if the receiving buffers are full, a 'stop' signal can Serial Port for Out-of-Band be sent to stop the data flow. Once the buffers are empty, a 'start' EMS Console Redirection signal can be sent to re-start the flow.
  • Page 52 5-2-9 CPU Configuration Description Parameter CPU Configuration Displays the module version information. Module Version Displays the AGESA version information. AGESA Version Enable/Disable the generation of ACPI_PPC, _PSS, and _PCT objects. PSS Support Options available: Enabled, Disabled. Default setting is Enabled. Options available: PState 0, PState 1, PState 2.
  • Page 53 5-2-10 Network Stack Configuration Parameter Description Enable/Disable the UEFI network stack. Network Stack Options available: Enabled, Disabled. Default setting is Disabled. Enable/Disable the Ipv4 PXE feature. (Note) Ipv4 PXE Support Options available: Enabled, Disabled. Default setting is Enabled. Enable/Disable the Ipv4 HTTP feature. (Note) Ipv4 HTTP Support Options available: Enabled, Disabled.
  • Page 54 5-2-11 CSM Configuration Parameter Description Compatibility Support Module Configuration Enable/Disable CSM support. (Note) CSM Support Options available: Enabled, Disabled. Default setting is Disabled. CSM16 Module Version Displays the module version information. Options available: Upon Request, Always. Default setting is Upon GateA20 Active Request.
  • Page 55 5-2-12 Info Report Configuration Parameter Description Info Report Configuration Enable/Disable Post Report support. (Note) Post Report Options available: Enabled, Disabled. Default setting is Disabled. Sets the POST Report wait time. Delay Time Options available: 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, Until Press ESC. Default setting is 5.
  • Page 56 5-2-13 NVMe Configuration Parameter Description NVMe Configuration Displays the NVMe devices connected to the system. BIOS Setup - 57 -...
  • Page 57 5-2-14 Offboard SATA Controller Configuration Parameter Description Offboard SATA Controller Displays the information on your PCIe SATA controllers/ PCIe SSD if Configuration installed. BIOS Setup - 58 -...
  • Page 58 5-2-15 SATA Configuration Parameter Description Displays the installed HDD devices information. System will automatically SATA Configuration detect HDD type. BIOS Setup - 59 -...
  • Page 59 5-2-16 Realtek PCIe GBE Family Controller Description Parameter Realtek PCIe GBE Family Press [Enter] to view the Network Interface Controller information. Controller BIOS Setup - 60 -...
  • Page 60 5-3 Chipset Setup Menu Chipset Setup menu displays submenu options for configuring the function of the onboard controller. Parameter Description Integrated Graphics Enable/Disable Integrated Graphics controller. Controller Options available: Disabled, Forces, Auto. Default setting is Forces. UMA Frame buffer Size Options available: Auto, 64M, 128M, 256M, 512M.
  • Page 61 Parameter Description Options available: AHCI, RAID. Default setting is AHCI. NVMe RAID Mode Changes CPU performance mode. Options available: Standard Mode, Performance Mode. Default setting is CPU Performance Standard Mode. AMD PSP KVM Configuration Press [Enter] to configure advanced items. BIOS Setup - 62 -...
  • Page 62 5-3-1 AMD PSP KVM Configuration Parameter Description AMD PSP KVM Configuration AMD PSP KVM feature Enable/Disable AMD PSP KVM feature. Options available: Disabled, Enabled, Clear. Default setting is Disabled. Enable (Note) Options available: 1280 x 1024, 1024 x 768. Resolution select for AMD PSP Default setting is 1024 x 768.
  • Page 63 Security Menu The Security menu allows you to safeguard and protect the system from unauthorized use by setting up access passwords. There are two types of passwords that you can set: • Administrator Password Entering this password will allow the user to access and change all settings in the Setup Utility. •...
  • Page 64 5-4-1 Secure Boot ® The Secure Boot submenu is applicable when your device is installed the Windows 8 (or above) operating system. Parameter Description System Mode Displays if the system is in User mode or Setup mode. Enable/ Disable the Secure Boot function. Secure Boot Options available: Enabled, Disabled.
  • Page 65 Parameter Description Press [Enter] to configure advanced items. Please note that this item is configurable when Secure Boot Mode is set to Custom.  Factory Key Provision – Allows to provision factory default Secure Boot keys when system is in Setup Mode.
  • Page 66 5-5 Boot Menu The Boot menu allows you to set the drive priority during system boot-up. BIOS setup will display an error message if the legacy drive(s) specified is not bootable. Parameter Description Boot Configuration Number of seconds to wait for setup activation key. 65535 (0xFFFF) Setup Prompt Timeout means indefinite waiting.
  • Page 67 Save & Exit Menu The Save & Exit menu displays the various options to quit from the BIOS setup. Highlight any of the exit options then press <Enter>. Parameter Description Save Options Saves changes made and closes the BIOS setup. Save Changes and Reset Options available: Yes, No.
  • Page 68 5-7 BIOS POST Beep code (AMI standard) 5-7-1 PEI Beep Codes # of Beeps Description Memory not Installed. Memory was installed twice (InstallPeiMemory routine in PEI Core called twice) Recovery started DXEIPL was not found DXE Core Firmware Volume was not found Recovery failed S3 Resume failed Reset PPI is not available...
  • Page 69 Setting up the system Pre-installation requirements Selecting a site Before unpacking and installing the system, select a suitable site for the system for maximum efficiency. Consider the following factors when choosing a site for the system: Near a grounded power outlet. ⚫...
  • Page 70 Turning on the system After making sure that you have properly set up the system, applied power and connected all the necessary peripherals, you can now power on the system. Follow the procedure below. Press the power button 。 The system starts up and displays a welcome message on the monitor. After that, a series of power-on self-test (POST) messages appears.
  • Page 71 disconnected from the electrical outlet before performing this task. Note: If you have gone through the preceding actions and the system still fails to boot, ask your dealer or a qualified technician for assistance. BIOS Setup - 72 -...
  • Page 72 Turning off the system There are two ways to turn off the Server—via software or via hardware. The software procedure below applies to a system running on a Windows OS. For other shutdown procedures, refer to the related user documentation. To turn off the system via software: Press <Ctrl>...
  • Page 73 Initial system startup problems Problems that occur at initial system startup are usually caused by an incorrect installation or configuration. Hardware failure is a less possible cause. If the problem you are experiencing is with a specific application. Initial troubleshooting checklist AC power is available at the wall outlet? ⚫...
  • Page 74 Hardware diagnostic testing This section provides a detailed approach to identifying a hardware problem and its cause. Checking the boot-up status Caution: Before disconnecting any peripheral cables from the Server, turn off the system and any peripheral devices. Failure to do so can cause permanent damage to the system and/or the peripheral device.
  • Page 75 Specific problems and corrective actions Listed below are specific problems that may arise during the use of your Server and their possible solutions Confirming loading of the operating system Once the system boots up, the operating system prompt appears on the screen.
  • Page 76 Make sure the SATA and power cables are properly connected. ⚫ Check that relevant switches and jumpers on the drive are set ⚫ correctly. Check that the drive is properly configured. ⚫ Optical drive tray cannot be ejected Insert the tip of a paperclip into the small hole on the optical drive. Slowly pull the tray out from the drive until the tray is fully extended.
  • Page 77 Reduce the number of external devices connected to a USB hub. ⚫ Refer to the documentation that came with the device ⚫ There is problem with the software program. Do the following: Verify that the software is properly configured for the system. ⚫...
  • Page 78 controller. Verify that the add-in video controller card is fully seated in its slot. Reboot the system for the changes to take effect. If there are still no characters on the screen after you reboot the system, reboot it again. Take note of the beep codes emitted during POST.
  • Page 79 Notices Information for your safety and comfort Safety instructions Read these instructions carefully. Keep this document for future reference. Follow all warnings and instructions marked on the product. Turning the product off before cleaning Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners.
  • Page 80 openings must not be blocked or covered. The openings should never be blocked by placing the product on a bed, sofa, rug or other similar surface. This product should never be placed near or over a radiator or heat register, or in a built-in installation unless proper ventilation is provided.
  • Page 81 Warning！The grounding pin is a safety feature. Using a power outlet that is not properly grounded may result in electric shock and/or injury. Note: The grounding pin also provides good protection from unexpected noise produced by other nearby electrical devices that may interfere with the performance of this product.
  • Page 82 technician to restore the product to normal condition. This Server should be located in a restricted access location or an area with similar instruction. Caution: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions.
  • Page 83 List of applicable countries This device must be used in strict accordance with the regulations and constraints in the country of use. For further information, please contact local office in the country of use. Please see http://ec.europa.eu/enterprise/rtte/implem.htm or the latest country list. Note: The following sections are applicable only to Class A systems FCC notice Class A...
  • Page 84 comply with the Class A limits may be attached to this equipment. Operation with non- certified peripherals is likely to result in interference to radio and TV reception. Caution Changes or modifications not expressly approved by the manufacture could void the user’s authority, which is granted by the Federal Communications Commission, to operate this computer.
