Summary of Contents for JENCO 765KC

  • Page 1 Jenco 765KC Thermocouple Panel Thermometers Limited Availability Used and in Excellent Condition Open Web Page https://www.artisantg.com/47323-1 A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
  • Page 2 OPERATION MANUAL MODEL 765 THERMOCOUPLE PANEL THERMOMETER JENCO ELECTRONICS, LTD. MANUFACTURER OF PRECISION INSTRUMENTS...
  • Page 3 For rapid changing display, the ''HOLD'' function may be used to freeze the display. INITIAL INSPECTION: Carefully unpack the instrument. Inspect damage in shipment. If any damage is found, notify your JENCO distributor immediately. All packing material should be saved until satisfactory operation is confirmed.
  • Page 4 SPECIFICATION : MODEL TYPE RANGE RESOULTION ACCURACY 765K -105 to 1372 1.5 , 1 digit -l57℉ to 1999℉ l℉ 2.7℉, l digit -210 to 760 1.5 , 1 digit -346℉ to 1400℉ l℉ 2.7℉, 1 digit 765T -105 to 400 1.5 , 1 digit -157℉...
  • Page 5 GENERAL : Analog Output (linearized) 1 mV/count Analog Output Accuracy +0.2% of reading , +1 mV (accuracy specified at 23"C, +5'C) T/C Resistance 100 (min) Sensor Break indication Positive over range (upscale) Display 0.56" High efficiency LED Power 115V AC, 230V AC, ±l0%,50/60 Hz Dimensions 48mm x 96mm x 110mm...
  • Page 6 MOUNTING PROCEDURE: 1. Make a cutout on any panel, with a thickness of l/l 6 inch (l .5 mm) to 3/8 inch (9.5 mm) Refer to DRAWING 1. PANEL CUTOUT DRAWING 1...
  • Page 7 2. Remove the mounting brackets assembly from the panel meter and insert the panel meter to PANEL METER WITR MOUNTING BRACKET AND SCREW DRAWING 2...
  • Page 8 3. Replace the mounting brackets assembly into the panel meter and fasten the mounting screws to secure the panel meter to the mounting panel. Refer to DRAWING 3. MOUNTING METHOD DRAWING 3...
  • Page 9 ANALOG VOLTAGE OUTPUT: The analog voltage output can be used to interface with other instruments such as recorder, printer, remote indicator, 4-20 mA converter, etc. The following rule must be observe in order to avoid reading inaccuracies or possible damage to the instrument. 1.
  • Page 10 WIRING DIAGRAM FOR T/C MODEL DRAWING 4...
  • Page 11 WIRING DIAGRAM FOR RTD MODEL DRAWING 5...
  • Page 12 TO ℉ JUMPER DRAWING 6...
  • Page 13 If you purchased the item from our Jenco distributors and it is under warranty, please contact them to notify us of the situation. Jenco Service Department alone will determine if the product problem is due to deviations or customer misuse.
  • Page 14 NOTE: Jenco Instruments, Inc reserves the right to make improvements in design, construction, and appearance of our products without notice. JENCO INSTRUMENTS, INC. 7968 Arjons Drive, Suite C San Diego, CA 92126 USA TEL: 858-578-2828 FAX: 858-578-2886 E-MAIL: jencoi@ix.netcom.com JENCO ELECTRONICS, LTD.

This manual is also suitable for:

765k765t765e765pt765ptb765
