ITOH DENKI HBM-604BN-UL Manual

HBM-604Bn/BP-UL
Driver Card Manual
Features:
Operates FS, FE and FP series motors
Runs one or two Power Mollers in one or
two zone configurations
10 pin motor connector only
LED indications for operation and error
statuses
Automatic or manual recovery for error
statuses
Motor protection against overheating,
stall condition and overspeeding
Lead free design for RoHS conformity
Logic for general zero pressure
accumulation (ZPA) is built-in
Singulated release
Slug (train) release with Flexible Zone
Recognition (patented)
Specifications subject to change without notice
Revised 1/22/2025
2 Great Valley Blvd., Wilkes-Barre, PA 18706
Office Ph: 570-820-8811
Fax: 570-820-8838
www.itohdenki.com
Direct connection for two photo-sensors for
power and signal
Easy connection between adjacent HBM-604B-
UL's with communication cables simplifies
wiring
Independent speed control for each motor
Adjustable timers by rotary switch
Automatically detects the end of a conveyor
line for accumulation when the communication
cable is disconnected
Stable speed function to ensure that different
weight articles travel at the same rate
Enclosure is made from fire resistant ABS
