Summary of Contents for LG MB-3724W
- Page 1 Instruction Manual MS-1924W MS-1924WS MB-3724W MB-3724WS...
- Page 2 Oven Parts/ª¤ÚË ÙÔ˘ ÊÔ‡ÚÓÔ˘ MB-3724W MB-3724WS 1. Front plate 1.¶ÚfiÛÔ„Ë 2. Viewing window 2.¶·Ú¿ı˘ÚÔ 3. Door seal 3.§¿ÛÙÈ¯Ô fiÚÙ·˜ 4. Safety lock system 4.™‡ÛÙËÌ· ÎÏÂȉÒÌ·ÙÔ˜ ·ÛÊ·Ï›·˜ 5. Control panel 5.¶›Ó·Î·˜ ÂϤÁ¯Ô˘ 6. Glass tray 6.°˘¿ÏÈÓÔ˜ ‰›ÛÎÔ˜ 7. Roller rest 7.™Ù‹ÚÈÁÌ· Î˘Ï›Ó‰ÚÔ˘...
- Page 3 Control Panel/ ¶›Ó·Î·˜ ÂϤÁ¯Ô˘ M M S S - - 1 1 9 9 2 2 4 4 W W M M B B - - 3 3 7 7 2 2 4 4 W W MS-1924WS MB-3724WS Power selector Allows selection of desired power.
- Page 4 5 ~17 OWNER’S MANUAL Please read this owner’s manual thoroughly before operating. 18 ~30...
- Page 5 3. Plug your oven into a standard voltage household outlet. Ensure that the electrical circuit is at least 10 amps ) and that the oven is the only appliance on the circuit. (13 amps for models MB-3724W / MB-3724WS NOTE: • This appliance should not be used for commercial catering purposes. WARNING: THIS APPLIANCE MUST BE EARTHED...
- Page 6 Important safety instructions Read carefully and keep for future reference WARNING: Please ensure cooking times are correctly set as over cooking may result in FIRE and subsequent DAMAGE to the OVEN. 1 Do not attempt to tamper with, or make any adju- 12 Before cooking, pierce the skin of potatoes, apples stments or repairs to the door, control panel, safety or any such fruit or vegetable.
- Page 7 Important safety instructions 24 Only use utensils that are suitable for use in 31 The oven should be cleaned regularly and microwave ovens. any food deposits removed. 25 When heating food in plastic or paper 32 Failure to maintain the oven in a clean containers, keep an eye on the oven due to condition could lead to deterioration of the the possibility of ignition.
- Page 8 Cooking Utensils COOKING UTENSILS Utensils should be checked to ensure that they are suitable for use in the microwave oven. The following chart summarises the proper use of cooking utensils in your oven: Cooking utensils Microwave Grill Heat resistant glass, glass ceramic Ceramic, china (Do not use china with gold or silver trim.)
- Page 9 Other Helpful Instructions 4. Some foods should not be completely thawed For best results and more enjoyable cooking, please read these comments thoroughly. before cooking. For example, fish cooks so quickly that it is sometimes better to begin cook- For Best Results: ing while still slightly frozen.
- Page 10 Check the food, positions. turning it over at least once during defrosting. MS-1924W / MS-1924WS MB-3724W / MB-3724WS 1. Turn the power select knob to set the defrosting mode. ( •...
- Page 11 Operating Procedure MB-3724W / MB-3724WS MB-3724W / MB-3724WS GRILL COOKING COMBINATION COOKING See page See page 1. Open the oven door, place the food on the The above models have a combination cooking mode which allows you to cook food rack in the oven, and close the oven door.
- Page 12 Heating or Reheating Guide To heat or reheat successfully in the microwave, it is important to follow several guidelines. Measure the amount of food in order to determine the time needed to reheat. Arrange the food in a circular pattern for best results. Room temperature food will heat faster than refrigerated food.
- Page 13 Fresh Vegetable Chart Cook time Standing Vegetable Amount Instructions (at HIGH) Time Artichokes 2 medium 5 ~ 8 Trim. Add 2 tsp water and 2 tsp juice. 2-3 minutes (230g each) 4 medium 11 ~ 13 Cover. Asparagus, 450g 3 ~ 7 ⁄...
- Page 14 Defrosting Tips Defrosting meats tips & techniques • You can defrost meats in their original wrapping as long as no metal is present. If necessary, shield small areas of meat or poultry with flat pieces of aluminium foil. This will prevent thin areas becoming warm dur- ing defrosting.
- Page 15 Grill Cooking Chart Directions for grilling meat on grill • Trim excess fat from meat. Cut fat, making sure you do not cut into the lean. (This will stop the fat curling.) • Arrange on the rack. Brush with melted butter or oil. •...
- Page 16 Questions and Answers Q. What’s wrong when the oven light will not Many foods build up enough internal heat to glow? allow the cooking process to continue, even Light bulb has blown. after the food is removed from the oven. Door is not closed.
- Page 17 2450 MHz Microwave Frequency 455 x 252x 320 Outside Dimensions (W x H x D mm) 1000 Watts Power Consumption MB-3724W / MB-3724WS 230 V AC, 50 Hz Power Input 700 Watts Output (IEC 60705 RATING STANDARD) 2450 MHz Microwave Frequency...
- Page 18 P/No.:MFL06446102...
