- Page 1 Steinway & Sons BWS-110 STEINWAY & SONS BWS-110 INSTALLATION INSTALLER MANUAL MANUAL [Skriv tekst] Version 1.0...
- Page 2 January 2025 Content COMPLIANCE ..................... 3 INTRODUCING THE BWS-110 ................4 UNPACKING THE BWS-110 ................5 PRE-INSTALLATION ..................6 INSTALLING THE BWS-110 ................7 TECHNICAL DRAWINGS ................... 8 TECHNICAL SPECIFICATIONS ............... 10 SERVICE INFORMATION ................11 Steinway & Sons BWS-110 Installer manual...
- Page 3 Steinway Lyngdorf products and accessories comply with parts 15 and 68 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference; and (2) this device must accept any interference received, including any interference that may cause undesired operation.
- Page 4 Introducing the BWS-110 Thank you for purchasing the Steinway & Sons BWS-110 woofer. Designed and made in Skive, Denmark, the BWS-110 is a high-bandwidth boundary woofer for custom installations. The BWS-110 has been specifically developed as an in-wall woofer for custom installations and for following the boundary woofer principle.
- Page 5 Unpacking the BWS-110 Carefully remove the BWS-110 from the carton and check for shipping damage. Contact both the shipper and your local Lyngdorf Audio representative immediately if the unit bears any sign of damage from mishandling. In some cases, it may be necessary to return the equipment to Lyngdorf Audio or an authorized service provider for repair;...
- Page 6 Pre-Installation For the best mechanical integration and sound performance, please follow this advice before installing the BWS-110. • Chose the acoustically best place for the BWS-110 in the room. The BWS-110 has been specifically developed as an in-wall woofer for custom installations and for following the boundary woofer principle. The acoustically ideal placement is in a room corner, or at least as close as possible to the nearest room boundaries, for example floor, wall, sidwall, ceiling.
- Page 7 Installing the BWS-110 1. Fix the provided Installation Guide Panel on the ground or bottom panel. For a 4-inch wall space, the installation guide panel is centered between the studs and placed against the back wall. 2. Place the BWS-110 near its final position and attach the + and - speaker cables. Make sure no split wires stand out or touch each other.
- Page 8 Technical Drawings Steinway & Sons BWS-110 Installer manual...
- Page 9 Steinway & Sons BWS-110 Installer manual...
- Page 10 Technical Specifications Description: Passive in-wall woofer Woofer: 1 x 10-inch, dual aluminum cone, 4-layer voice coil, neodymium magnet Enclosure: MDF with internal bracing, 19mm and 16mm Frequency range: 30 – 200 Hz (-3 dB) Nominal Impedance: 4 Ohm Power handling: 300 W (IEC long term power handling) Maximum SPL: 109 dB (60 V / 1 m)
- Page 11 Service Information Service and Warranty To obtain warranty service, you must contact the Steinway & Sons distributor of the region or country where you are located. If you have trouble locating an authorized representative, please find contact information at www.steinwaylyngdorf.com SL Audio A/S Rævevej 3 DK-7800 Skive...
- Page 12 Steinway & Sons BWS-110 Installer manual SL AUDIO A/S • RÆVEVEJ 3 • 7800 SKIVE • DENMARK • WWW.STEINWAYLYNGDORF.COM...
