WATER PURIFIER
OPERATION MANUAL
WHP-3200
FOR YOUR SAFETY
. . . . . . . . . . . . . . . . . . . . . . . . . 2~4
Precautions
FOR INFORMATION
. . . . . . . . . . . . . . . . . . . . . 5
Name of each part
Filtration system . . . . . . . . . . . . . . . . . . . . 6~7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Features
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Installation
How to use & Cleaning
. . . . . . . . . . . . . . . . 11~12
Filter replacement
. . . . . . . . . . . . . . . . . . . . . . 13
Troubleshooting
. . . . . . . . . . . . . . . . . . . . . . . . . 14
Specifications
For your safety and proper use of the product, please read this User's
manual befor use. Warranty card included in this manual.
. . . . . . . . . . . . . . . . . 10
Advertisement
Related Manuals for WONBONG RUHENS WHP-3200
Summary of Contents for WONBONG RUHENS WHP-3200
- Page 1 WATER PURIFIER OPERATION MANUAL WHP-3200 FOR YOUR SAFETY ......2~4 Precautions FOR INFORMATION ..... 5 Name of each part Filtration system .
- Page 2 PRECAUTIONS Please read all precautions carefully to prevent any potential dangers and/or damages. Precautions are divided into three types depending on the degree of potential danger/damage. Danger : If not observed, serious injury or even death could occur. Warining : If not observed, serious injury or property damage could occur. Caution : If not observed, slight injury of property damage could occur.
- Page 3 PRECAUTIONS Please do not apply unnecessary force Please do not attempt to repair, to the product. disassemble, or transform. Danger Danger ※ Failure to do so can cause malfunction. Precautions for use If the product has not been used for If you find any water leaking, lock the a long time, drain the water in the filters water valve and contact the service center.
- Page 4 PRECAUTIONS Never use Benzene or gasoline to clean the unit. Caution ※Failure to do so can cause discolor, peeling and damage to the unit. This appliance is not intended for use by person(including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
- Page 5 NAME OF THE PARTS Model No. WHP-3200 Water Valve Water faucet Water inlet Magnetic Drip Tray <Front> <Back> Filter Filter cover Water shut-off valve <Side> <Inside>...
- Page 6 FILTRATION SYSTEM Filtration system 1,2step S/P PLUS COMBI FILTER Sediment filter Pre-carbon filter Removes sediment particles Using activated carbon, it absorbs such as rust, dirt and sand over harmful organic chemicals such as 5 microns in size at this first stage. chlorine, removes odors and Thus protecting the stage two improves the water's taste...
- Page 7 FILTRATION SYSTEM Filtration system Reducing valve 2.5kgf/㎠ Particle Remover S/P PLUS U/P PLUS COMBI FILTER COMBI FILTER ■ When replacing filters, be sure to do flushing process for new filters. ■ Permitted water pressure : Min 142kPa Min 2.0ℓ/min Initial Setup 1.
- Page 8 FEATURES Can be operated without any electricity being supplied. ◆ It operates without using power, so no running costs. 11.5cm Slim Size ◆ 11.5cm sized to possibly increase the efficiency for using the kitchen with the slim product. Dual Combi Filters for 4 Stage Filteration Process ◆...
- Page 9 INSTALLATION 1. Place the product stood perpendicularly. 2. Close the water supply valve. water supply Open valve 90 ˚ Close 4. Connect the tubing to the water inlet in 3. Close the water shut-off valve in the side the rear. filter cover(Open →...
- Page 10 HOW TO USE & CLEANING HOW TO USE Turn the water valve clockwise to dispense water and counter-clockwise to stop. CLEANING 1. Cleaning external part of the product Internal cleaning is not required as the product does not include a water tank. 2.
- Page 11 FILTER REPLACEMENT 1. Close the Water shut-off valve ① Open the side filter cover. ② Open the side filter cover, and turn the water shut-off valve clockwise to block the water supply. (Open->Close) Water shut-off valve 2. Drain the remained water in the filters and release the internal pressure.
- Page 12 FILTER REPLACEMENT 4. Flush the inside of the replacement filter ① Please make sure that the filters have been properly flushed for approximately 10 minutes. ② Please make sure that the filters are flushed properly until all carbon dust is no longer visible. mins CAUTIONS Please make sure to change filters periodically based on the filter replacement cycle.
- Page 13 TROUBLESHOOTING ※ Check the followings before asking A/S. Problem Solution Unpleasant Replace the filters to operate the water filtration. water taste Please check if the water supply valve is locked, or the filter exchange No water period has passed, and if water is not coming out even though it is all comes out normal, apply for A/S.
- Page 14 SPECIFICATIONS No power system water purifier Name WHP-3200 Model no. None Power External dimensions 115(W) X 325(D) X 338(H) mm 1. S/P PLUS COMBI FILTER Filters 2. U/P PLUS COMBI FILTER 1. S/P PLUS COMBI FILTER - 6 months Filters ReplacementCycle 2.
- Page 15 MEMO...
- Page 16 MEMO...
