Page 2
Power Door Locks Walk-Away Auto Lock Function Transmitter Battery Saving Function Keyless Entry Using Auxiliary Key Rear Door Child Safety Locks Operation Theft-Deterrent System Link Seat & Climate Control Temperatures Web-Based Training Courses Item Service Information Fuse to be Installed at PDI Fuse F27 (25A) is removed from the engine compartment fuse block and is stored on the engine compartment fuse block lid.
Page 3
NOTE: • Key machine software update coming soon to support the CX-50. CX-50, 4 digit key code and a Except CX-50, 5 digit key code plastic bar code tag • Disgard the plastic bar code tag during PDI. The plastic bar code tag is used during vehicle production and is not needed by the customer.
Page 4
• If additional auxiliary metal keys are needed, the key machine will require a 5-digit code. Just add “5” as the 1st digit to make the 4-digit to 5-digit. The auxiliary keys need to be inserted into the key transmitters during PDI. Remove the transmitter lower cover by sliding the knob in the direction shown and then sliding the cover in...
Page 5
Owner's Manual -> When Driving -> Start/ Stop Engine -> i-stop MGSS Service Highlights -> i-stop -> stop CONTROL i-stop* Indicator Light The i-stop function automatically stops the engine when the vehicle is Green stopped at a traffic light or stuck in traffic, and then restarts the engine automatically to resume driving.
Page 6
2. Scan or enter VIN manually 3. Change Cranking Units to CCA 4. Edit Battery Info, then Select Continue • Battery Type - I-ELOOP • Cranking Units - CCA • Cranking Rating - 622 • Post Location - Top Post •...
Page 7
Smart Brake Support (SBS) -> Reverse drive detection Driver Monitoring (DM) System* Owner's Manual -> MAZDA CONNECT System determines that the driver is not paying attention to the road using the OWNER'S MANUAL -> Settings -> Safety driver monitoring camera and it determines that there is the possibility of a Setting ->...
Page 8
A - Driver Monitoring Camera B - Driver Monitoring Camera LED C - Driver Monitoring Unit Driver Attention Alert (DAA)* The DAA is a system which detects driver fatigue and decreased attentiveness, and encourages the driver to take a rest. When the vehicle is driven inside traffic lane lines at about 65 to 140 km/h (41 to 86 mph), the DAA estimates the amount of accumulated fatigue and decreased attentiveness of the driver based on the information from the Forward...
Page 9
Prevents error messages being sent to the customer during vehicle service. Cancel Restricted Transmitting Mode after completing vehicle service. Mazda Connected Vehicle Viewer (MCVV) MAZDA CONNECTED VEHICLE VIEWER USER GUIDE (MCVV) The Mazda Connected Vehicle Viewer (MCVV) enhances the Mazda Page 04/20/2022 07:29 AM cciz...
Page 10
Mazda Service Advisors, Technicians and Call Center Associates access to real-time vehicle status information alerts for applicable Mazda connected vehicles. This powerful tool allows you to proactively understand and diagnose customer concerns and resolve potential issues, demonstrating how well you know the customer’s vehicle while establishing your readiness and...
Page 11
This mode suppresses the reduction of driving performance due to increased weight during trailer towing and promotes vehicle stability. Use this mode when towing a trailer. * if equipped Owner's Manual -> MAZDA CONNECT OWNER'S MANAUL -> Touch Panel Wireless Apple Carplay™ / Android Auto™...
Page 12
See Owner's Manual -> Interior Features - > Interior Equipment -> Wireless Charger (Qi) Illumination Infotainment Wireless Qi Charger* Icon Status flash pattern indication You can charge mobile devices such as Smartphones which comply with the Qi Wireless Charging standard. Indicates Only use mobile devices that have a maximum power consumption of 5 W, or Does not turn...
Page 13
(Qi) and it needs to be repaired. Consult Authorized Mazda Dealer. Remote Power Window Operation The windows can be opened for ventilating the cabin before getting in the vehicle. Press the unlock button on the key quickly and briefly 3 times and then immediately afterwards, press and hold the unlock button to open the See Owner's Manual ->...
Page 14
The panorama sunroof can be opened or closed when operating the overhead tilt/slide switch (1) in the front roof console. Electric Parking Brake (EPB) Parking Brake Auto Operation Change When the ignition is switched OFF, the parking brake will be applied automatically.
Page 15
The brake pedal is being depressed Front Radar Sensor The location of the front radar sensor has changed. It is now located below the front grill instead of behind the Mazda emblem in the grill. MGSS FRONT RADAR SENSOR REMOVAL/INSTALLATION See Owner's Manual ->...
Page 16
(see Service Information). DO NOT use the wiper arms as markers when in dealer inventory. MAZDA CONNECT Power Off Function See Owner's Manual -> MAZDA CONNECT OWNER'S MANUAL -> Basic • Audio Mute: Short press the volume knob (press again to cancel) Operations ->...
Page 17
The walk-away auto lock function does not close the power windows. Operational Range See Owner's Manual -> MAZDA CONNECT OWNER'S MANUAL -> Settings -> Vehicle Settings -...
Page 18
are closed. • Depending on the key transmitter holder’s distance to the antenna when he/she is closing the driver side rear door, the walk- away lock may or may not function. • If standing closer to Key transmitter Be mindful of the the rear bumper holder area when closing...
Page 19
that by the time the door is completely shut, the key transmitter holder is already out of operational range because she/ he is moving away too fast, causing walk-away lock to not function. Transmitter Battery Saving Function (Key Fob) The CX-50 has a "power saving" function built into the keyless entry system where some key fob functions are disabled.
Page 20
door child safety locks. 1. Auxiliary Key 2. Lock 3. Unlock Theft-Deterrent System The CX-50 is not equipped with a Theft-Deterrent System. CAUTION: DO NOT use MDARS to enable: • Burglar Alarm • Intrusion Sensor The CX-50 does not have the necessary Theft-Deterrent System hardware to function if enabled using MDARS, and MDARS cannot disable the Theft- Deterrent System after it has been enabled.
Page 21
(turned on and off) by the climate control system, depending on the set temperature. Auto Mode 1. Go to MAZDA CONNECT home screen and select "Settings" 2. Select “Vehicle Settings”. 3. Enable “Link Seat & Climate Control Temperatures”.
