ROBLAN SKYJX600 Manual

Power
SKYJX600
SKYJX1200
SKYJX150
A
Turn off the power.
C
Loosen the nut of the cable gland, put the cable
through the cable gland
E
Tighten the cable gland
G
R
100-
IK08
277V
Maxi
Linkable qty
60
20W 650
30
1220
36W
20
1560
50W
B
Insert 6mm expansion screw in the wall ,
fix the mounting bracket with M4 screw.
LED Weatherproof Luminaire SKYJX
Number of
clips
68 70 6
68 70 10
68
70
12
D
Connect the cable on the terminal block as shown below and
tighten the cable gland.
F
H
Turn on the power.
Safety Notice:
1.Electrical installation should be done by registered electrician only.
2. Disconnect the luminaire from the power supply and wait until the luminaire has
cooled down, before replacement of any parts.
3. Never touch the lamp while the luminaire is switched on.
4. The manufacturer reserves the right to refuse warranty service if the product shows
signs of damage due to incorrect maintenance or installation.
5.Surface mounted installation only.
6. In case of malfunction disconnect the luminaire from the power supply immediately.
Don't try to repair the luminaire yourself. Repair should only be done by the manufac-
turer.
