by WHYNTER
PROTECH Commercial Freestanding/Built-in Beverage Merchandiser
Display Refrigerator with Self-Closing Lockable Door and Mobility Wheels
MODELS: CDM-600BW (6.0 cu. ft.)
CDM-710BW (7.1 cu. ft.)
CDM-850BW (8.5 cu. ft.)
CDM-600BW
CDM-710BW
CDM-850BW
Congratulations on your new PROTECH product. To ensure proper operation, please read this User
Manual carefully before using this product. Keep this manual in a safe place for future reference.
Advertisement
Related Manuals for Whynter PROTECH CDM-600BW
Summary of Contents for Whynter PROTECH CDM-600BW
- Page 1 WHYNTER PROTECH Commercial Freestanding/Built-in Beverage Merchandiser Display Refrigerator with Self-Closing Lockable Door and Mobility Wheels MODELS: CDM-600BW (6.0 cu. ft.) CDM-710BW (7.1 cu. ft.) CDM-850BW (8.5 cu. ft.) CDM-600BW CDM-710BW CDM-850BW Congratulations on your new PROTECH product. To ensure proper operation, please read this User...
- Page 2 DISPOSAL INFORMATION Thank you for choosing PROTECH. Please follow the instructions provided in this user manual to obtain the very best performance from your refrigerator. We trust that your PROTECH refrigerator will provide the performance and reliability that we stand for. Please keep this user manual in a safe place for future reference.
- Page 3 SAFETY PRECAUTIONS To prevent death or injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation due to ignoring of instructions may cause death, harm or damage. Read all instructions before using the refrigerator. Never clean refrigerator parts with flammable fluids.
- Page 4 INSTALLATION To reduce the risk of fire, electrical shock, or injury when using your refrigerator, follow these basic precautions: GENERAL SAFETY PRECAUTIONS Read all instructions before using the refrigerator. Never allow children to operate, play with, or crawl inside the refrigerator. FIRE HAZARD PRECAUTIONS DANGER: An empty refrigerator can be hazardous for children or small pets.
- Page 5 INSTALLATION INSIDE CABINET Do not pack refrigerator so full that air cannot circulate. The refrigerated air is discharged at the top rear of the unit. It is important to allow for proper air flow from the top rear to the bottom of the unit. Obstructions to this air flow can cause evaporator coil freeze ups and loss of temperature or overflow of water from the evaporator drip tray.
- Page 6 SPECIFICATIONS Model CDM-600BW CDM-710BW CDM-850BW Color Black Black Black Built-in | Freestanding Built-in | Freestanding Built-in | Freestanding Installation Type Storage Capacity 6.0 cu. ft. (170 L) 7.1 cu. ft. (200 L) 8.5 cu. ft. (240 L) Cabinet 161 standard 12 oz. can 191 standard 12 oz.
- Page 7 IDENTIFICATION OF PARTS 12 (rear) Part Description Internal Fan Door Lock Door Handle Exhaust Vents Interior Cabinet Light Temperature Control Knob Internal Light Switch Double Pane Tempered Glass Door Adjustable Wire Shelves Drain Hole Leveling legs (2) + Mobile wheels (4) Drip Tray Page 7...
- Page 8 OPERATION It is recommended to install the refrigerator in an area where the ambient temperature ranges between 60°F (16°C) and below 90°F (32°C). If the ambient temperature exceeds or falls below these recommended ranges, it may affect the performance of the refrigerator. For instance, placing the refrigerator in extremely cold or hot conditions can lead to fluctuations in interior temperatures.
- Page 9 OPERATION MOVING THE REFRIGERATOR The refrigerator comes equipped with fours wheels, making it easier to move from one location to another when needed. CAUTION: To ensure safe handling and prevent damage, it is recommended to have an additional person assist when moving the refrigerator.
- Page 10 OPERATION / LOADING PLAN Please note that an individual’s perception of noise is directly influenced by the environment in which the refrigerator is situated. Our refrigerators adhere to international standards for such equipment and incorporate the latest technical advancements. It's important to understand that some level of noise from the compressor and coolant circulating in the system is inevitable.
- Page 11 CARE AND MAINTENANCE PREPARING FOR STORAGE If the refrigerator will not be used for an extended period or is to be moved to another location, it's necessary to defrost the unit and dry the interior. Disconnect the refrigerator from the power supply by unplugging the power plug from the wall socket. WARNING: Do not touch the power plug with wet hands.
- Page 12 TROUBLESHOOTING Many common refrigerator problems are easily resolved. Try the troubleshooting suggestions below to see if the problems can be resolved before having to contact the service department. PROBLEM POSSIBLE CAUSES SOLUTIONS There is a power failure Ensure the refrigerator is The refrigerator is not plugged in and the power plugged in...
- Page 13 TROUBLESHOOTING Many common refrigerator problems are easily resolved. Try the troubleshooting suggestions below to see if the problems can be resolved before having to contact the service department. PROBLEM POSSIBLE CAUSES SOLUTIONS The noise may come from the It is normal that as each flow of the refrigerant and cooling cycle ends, you may expansion of the inside walls...
- Page 14 EXCLUSIONS MAY NOT APPLY TO YOU. THIS WRITTEN WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE. To obtain service or information, contact PROTECH via email at support@whynter.com or call 866-WHYNTER. Product contents and specifications may change without notice.
