DSW DSM-208CN User's And Installer's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INDEX
CHAPTER 1- SUMMARY OF USER'S COMMANDS ................................ 3
CHAPTER 2 - ABOUT THE KEYPAD.......................................................... 4
1. Setting/Changing and Deleting User's Code ................................... 7
2. Setting Date and Time......................................................................... 9
3. Displaying System Date and Time..................................................... 9
4. Setting Follow-me Number ................................................................. 9
5. Quick Arming....................................................................................... 10
6. Code Arming ....................................................................................... 10
7. Bell Squawk on Arming ..................................................................... 10
8. Disarming ............................................................................................ 11
9. On/Off Audible kiss-off....................................................................... 11
10. Duress Disarming ............................................................................ 11
11. Cutting off Sounder and Stop Auto-dialing ................................... 12
12. Bypassing/ Un-bypassing a Zone.................................................. 12
13. Escape Key [ESC] ........................................................................... 13
14. Emergency Keys .............................................................................. 13
15. Entry and Exit Delays ...................................................................... 13
16. 24-Hour Zone ................................................................................... 13
17. Trouble Display................................................................................. 13
18. Zone Features .................................................................................. 14
19. Get Events from Event Logger....................................................... 15
20. On/Off Door Chime .......................................................................... 15
CHAPTER 3 - INSTALLATION .................................................................... 16
DSM-208CN User's and Installer's Manual
) ............................................................................. 4
EYPAD
.................................................................................. 5
.................................................................................. 7
...................................................................................... 16
............................................................................................. 17
................................................................ 21
......................................................................... 21
............................................................... 16
Page 1, Total 52

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DSM-208CN and is the answer not in the manual?

Questions and answers

Summary of Contents for DSW DSM-208CN

  • Page 1: Table Of Contents

    CHAPTER 3 - INSTALLATION ..............16 ..................16 EFORE NSTALLATION FAQ..............16 NSTALLATION AND OLUTION ..................... 17 OARD ..............21 NSTALL ONTROL ANEL AND EYPAD ................. 21 ONNECT THE ELEPHONE DSM-208CN User’s and Installer’s Manual Page 1, Total 52...
  • Page 2 31 ..............43 ：L ERIODIC OCATION 32-94 ........43 ：L OMMUNICATOR EPORTING ODES OCATIONS REPORTING CODES FOR ALARM EVENTS: ......... 43 DSM208CN CONTROL PANEL CONTACT ID REPORTING CODES.. 47 DSW’S WARRANT..................52 DSM-208CN User’s and Installer’s Manual Page 2, Total 52...

  • Page 3: Chapter 1- Summary Of User's Commands

    The Backup Battery Power is low. AC Power AC Power is lost. Trouble Table No Clock Clock have not been set No Communication The Communication is in trouble. No Siren The Siren connection is in trouble. DSM-208CN User’s and Installer’s Manual Page 3, Total 52...

  • Page 4: Chapter 2 - About The Keypad

    Fig.1 Layout of the DSM208KCL Keypad Instruction 1－Power 5－Bypass 2－LCD Display 6－Fire 3－Arm 7- Tamper 4－Disarm 8－Arm key-press DSM-208CN User’s and Installer’s Manual Page 4, Total 52...

  • Page 5: Led Indication And Keys

    The LCD Display on DSM208KCL indicate the status of each of the system, including zones Triggered, Armed/Disarmed system, Trouble, Time and other programming information. If there is only “DSW” on the display, which means all the zones are not triggered. When Z1, Z2, Z3, Z4, Z5, Z6, Z7 or Z8 is/are...
  • Page 6 Home Arming arms the perimeter detectors (e.g. door and windows), while leaving interior detectors (e.g. motion detectors) disarmed (bypassed). When [STAY] key is depressed, the interior zones will not be armed. 10. Exit/Delete [ESC] DSM-208CN User’s and Installer’s Manual Page 6, Total 52...

  • Page 7: Function And Operation

    Master Code, and /or to set up User Coeds, follow the steps. Make sure the system is disarmed when setting the code. The User’s Codes are only for Arming and Disarming the system Functions of the Master Code: Adding, changing and deleting User’s Code DSM-208CN User’s and Installer’s Manual Page 7, Total 52...
  • Page 8 The selected User Code is now in effect. Deleting User’s Codes At times, it may be desirable to completely delete a User Code. Note that it is impossible to delete the Master Code (although it can be changed). DSM-208CN User’s and Installer’s Manual Page 8, Total 52...

  • Page 9: Setting Date And Time

    The Follow-Me function can support four phone numbers for each system. Make sure the numbers are all correct; then enter [#]. Operate as: Set Follow-Me Phone NO.1: [*]+[7]+[1]+[MASTER CODE]+Phone NO.1+[#] DSM-208CN User’s and Installer’s Manual Page 9, Total 52...

  • Page 10: Quick Arming

    + [Master Code] to arm or stay arm. 7. Bell Squawk on Arming If selected, Bell Squawk on Arming will produce a brief confirmation "chirp" from the system's external sounder(s) once the system is armed and the Exit DSM-208CN User’s and Installer’s Manual Page 10, Total...

  • Page 11: Disarming

    User code =1-2-3-4; duress code is 1-2-3-5 User code =5-6-7-8; duress code is 5-6-7-9 User code= 7-8-9-0; duress code is 7-8-9-1 Note: Under no circumstances must the Duress Code be used haphazardly or DSM-208CN User’s and Installer’s Manual Page 11, Total...

  • Page 12: Cutting Off Sounder And Stop Auto-Dialing

    When Zone 3 is un-bypassed, Cancel BP Z3 will be displayed on the LCD. Code Bypassing: If DSM208CN was programmed as code bypassing, then press: [*]+[1]+[Disarming Code]+[Zone No] to bypass the zone. Use the same DSM-208CN User’s and Installer’s Manual Page 12, Total...

  • Page 13: Escape Key [Esc]

    When the keypad sends out three short beep regularly, indicating that the system exists some troubles. When get rid of the troubles, the system will restore to normal status and stop beeping. Troubles include Battery Low, AC DSM-208CN User’s and Installer’s Manual Page 13, Total...

  • Page 14: Zone Features

    For user’s convenience, all DSM208CN zones have been defaulted as following: Zone 1: Entry/Exit Delay Zone; Zone 2: Instant (Intrusion) Zone; Zone 3: Instant (Intrusion) Zone; Zone 4: Panic Zone; Zone 5: Fire Zone; Zone 6: Tamper Zone; DSM-208CN User’s and Installer’s Manual Page 14, Total...

  • Page 15: Get Events From Event Logger

    When alarm occurs during armed system only the external sounder will be activated. Enter [*]+[8]+[Master Code]+[2] to turn on/ off the door chime. DSM-208CN User’s and Installer’s Manual Page 15, Total...

  • Page 16: Chapter 3 - Installation

    CHAPTER 3 - INSTALLATION The Series of Control Panel Which is Designed and Produced by DSW Integrate Perfect Function and Advanced Technology. DSW’s Control Panels Use the Separated Control Keypads and Has Strong Ability to Prevent Destroy. All Zones Are Programmable, Have Built-in Digital Communicator, Flexible Connecting to Alarm Centre, Compatible to All Popular Communication Format, Attached Duress Code, Consecutive Output.

  • Page 17: The Main Board

    5―the connector for the voice module 6－the type and version number 7－eligible label and production serial number 8－ “AUX” safety for assistant power, 0.5A 9― “BELL” safety for siren power, 1A 10－“BAT” safety for standby power, 2A DSM-208CN User’s and Installer’s Manual Page 17, Total...
  • Page 18 34－“YRL” the port should connect to the yellow line on the keypad. 35－“BLK” the port should connect to the black line on the keypad. 36－“RED” the port should connect to the red line on the keypad. DSM-208CN User’s and Installer’s Manual Page 18, Total...
  • Page 19 Fig.2 DSM208MB DSM-208CN User’s and Installer’s Manual Page 19, Total 52...
  • Page 20 Fig.3 Connection Instruction DSM-208CN User’s and Installer’s Manual Page 20, Total 52...

  • Page 21: Install Control Panel And Keypad

    -voltage, do not mix with blue which is the low-voltage. Don't power the system before the installation finished well. Connect Siren The port BELL is used for connect siren. Please watch for cathode and anode when connecting. DSM-208CN User’s and Installer’s Manual Page 21, Total 52...

  • Page 22: Connect Detector(S)

    As Fig.4, connecting voice module just need to insert it into the connector on the control panel. 1(record)－recording button 2(play)-test record button 3 － the eligible label including production serial number, tester number, production type and version number. 4－recording microphone DSM-208CN User’s and Installer’s Manual Page 22, Total 52...

  • Page 23: Connect Wireless Module

    The function and the port of DSM208EW4 expansion wireless module： 12VDC Power Zone-1 Indicating Light Set Aside Zone-2 Indicating Light Remote Armed Zone-3 Indicating Light Set Aside Zone-4 Indicating Light Trouble Output Receive Data Indicating Light DSM-208CN User’s and Installer’s Manual Page 23, Total 52...
  • Page 24 3. When using remote controller, the port 3 should connect switch lock zone of DSM208CN 4. In normal, the dial 1 and 2 on the dial switch 10 should be set at the position Please refer to DSM208EW4 User's Manual for more details. DSM-208CN User’s and Installer’s Manual Page 24, Total 52...
  • Page 25 Fig.6 The Wireless Receiver DSM-208CN User’s and Installer’s Manual Page 25, Total 52...

  • Page 26: Chapter 4 - Function And Technical Data

    Disarm by Remote Controller Disarm By Duress Code LCD Display Bypassing and Not-ready Zones Quick Arm Quick Arm by Code Quick Stay Arm Stay Arm by Code Bypass zone quickly Bypass zone by Code DSM-208CN User’s and Installer’s Manual Page 26, Total 52...

  • Page 27: Main Features Of Dsm208Mb

    1 Master Code, this Code Can Create Duress Code Automatically 9 User Codes, Each Code Can Create Duress Code Automatically Periodic Test Offer Testing Report to Alarm Center Automatically Every Day Peripheral Equipment DSM-208CN User’s and Installer’s Manual Page 27, Total 52...
  • Page 28 22 in Chapter 5 for details) Charging of Standby Battery Main Board attaches charging circuit, the Standby Battery can be charged via BAT port TECHNICAL DATA Main Board Input power 16.5VAC 25VA via transformer DSM-208CN User’s and Installer’s Manual Page 28, Total 52...
  • Page 29 Bell/LS Power 1A Fuse BAT Battery Power 2A Dimension/weight 80*167mm/0.17kg Keypads LCD Keypad Current consumption 90mA typical, 130mA max Control panel connections 4-wire up to 1000M from panel Dimensions 110*130*25mm Weight 0.23kg DSM-208CN User’s and Installer’s Manual Page 29, Total 52...

  • Page 30: Chapter 5 - Programming Direction

    Check Location Data Check location data need in the state of program mode. LCD display the relative information after enter to the location which need to be checked, but the Code won’t display. DSM-208CN User’s and Installer’s Manual Page 30, Total 52...

  • Page 31: Entry/Exit Program

    (error) beep will sound after pressing [#] Check the data stored The data display [5678] in Location"08" on the LCD DSM-208CN User’s and Installer’s Manual Page 31, Total 52...

  • Page 32: General System Parameters: Locations 00-07

    PURPOSE: to assign the system's Central Station Account Number. Hexadecimal account numbers (those using 0 through 9 and A through F) are accepted by DSM208CN. Use the key combinations below to enter hexadecimal digits "A" through "F" DSM-208CN User’s and Installer’s Manual Page 32, Total 52...

  • Page 33: Installer Code：location 08-10

    Location 11 is used to set the time of exit delay, which unit is second. The time of delay is made up of 3 digits, 1 second at least, 255 second at most. For example, DSM-208CN User’s and Installer’s Manual Page 33, Total 52...

  • Page 34: Intrusion Zone Types And Zone Sounds ：Locations 14-21

    If the system is armed to AWAY (ARM) mode: this type of zone behaves like the Entry Follower, described above If the system is armed to the STAY mode: this type of zone will be bypassed. DSM-208CN User’s and Installer’s Manual Page 34, Total 52...
  • Page 35 Sounder When Armed/keypad Sounder When Disarmed Related to 24H Zones. When alarm during disarm, the keypad's buzzer will be activated When alarm during armed system, the external sounder will be activated. DSM-208CN User’s and Installer’s Manual Page 35, Total 52...
  • Page 36 If the zone was programmed as Tamper, in violation, a Tamper Code report will be sent and the Tamper LED on the keypad will light up. DSM-208CN User’s and Installer’s Manual Page 36, Total 52...

  • Page 37: Utility Outputs - Event And Result ：Locations 22, Default 00

    UO is activated immediately when a Fire alarm is triggered by a violation of zone 5, defined as Fire, or by pressing the keypad's [4] and [5] keys simultaneously for two seconds, UO is deactivated when the system is disarmed. DSM-208CN User’s and Installer’s Manual Page 37, Total 52...
  • Page 38 Zone 3 Alarm Follow(Pulse) Zone 4 Alarm Follow(Latched) Zone 4 Alarm Follow(Pulse) Zone 5 Alarm Follow(Latched) Zone 5 Alarm Follow(Pulse) Zone 6 Alarm Follow(Latched) Zone 6 Alarm Follow(Pulse) Zone 7 Alarm Follow(Latched) DSM-208CN User’s and Installer’s Manual Page 38, Total 52...

  • Page 39: Communication Parameters：locations26-29

    Central Station Protocols：Location 27, Default: 00 To understand and modify the Code format according to a specific central station see the following First digit: determine the number corresponding to the desired combination of: DSM-208CN User’s and Installer’s Manual Page 39, Total 52...
  • Page 40 33 pulses/sec 650ms 1900Hz 20 pulses/sec 650ms 1900Hz 10 pulses/sec 650ms 1900Hz (PPS) Kiss off/ Inter Digit Code Format Name Validation pulses/sec Handshake Time Format Silent Dual Knight/ADEMCO 1400Hz round Slow DSM-208CN User’s and Installer’s Manual Page 40, Total 52...

  • Page 41: Cs Protocols : Location 28, Default : 03

    When selecting 03 (the Pulsed Protocol) the default for all the reported codes will be "00"and any other code should be entered manually follow the CMS software. Digit Format Name Inter-digit Time Date Frequency Contact ID 03(default) DSM-208CN User’s and Installer’s Manual Page 41, Total 52...
  • Page 42 First digit: determine the number(or letter)corresponding to the choices involving Quick Arm/Quick Bypass/Loudspeaker/Bell-Siren Second digit: determine the number (or letter)corresponding to the use of silent Panic/Bell Squawk on Arming /3 Minute Bypass DSM-208CN User’s and Installer’s Manual Page 42, Total 52...

  • Page 43: Periodic Test Time ：Location 31

    Reporting Codes for Alarm Events: To program the codes that will be transmitted by the DSM208CN to the Central Station. To prevent the corresponding event from being reported, use a "double-zero"(00, DSM-208CN User’s and Installer’s Manual Page 43, Total 52...
  • Page 44 Keypad Special Emergency Reporting code Zone 1 Restore code Zone 2 Restore code Zone 3 Restore code Zone 4 Restore code Zone 5 Restore code Zone 6 Restore code Zone 7 Restore code DSM-208CN User’s and Installer’s Manual Page 44, Total 52...
  • Page 45 Loss of AC Power(for at least 15 min) Reporting code Fire zone trouble Reporting code Bell Loop Interrupted Reporting code Low Battery restore Reporting code Loss of AC Power restore Reporting code Fire zone trouble restore Reporting code DSM-208CN User’s and Installer’s Manual Page 45, Total 52...
  • Page 46 Zone 5 Bypass / Restore Reporting ABCD code Zone 6 Bypass / Restore Reporting ABCD code Zone 7 Bypass / Restore Reporting ABCD code Zone 8 Bypass / Restore Reporting ABCD code DSM-208CN User’s and Installer’s Manual Page 46, Total 52...

  • Page 47: Dsm208Cn Control Panel Contact Id Reporting Codes

    Restore Low temperature zone alarm/Restore temperature dissipate alarm/Restore Liquid leak alarm Liquid leak Restore Oil leak alarm/Restore Gas leak alarm/Restore High temperature alarm/Restore temperature dissipate alarm/Restore Airflow unsteady alarm DSM-208CN User’s and Installer’s Manual Page 47, Total 52...
  • Page 48 Battery power low Battery power Restore Warning sign fault Warning sign Restore Fire zone fault Fire zone Restore On/off reporting User arm User unarm User 0 quick arm/unarm Force arm periodic test DSM-208CN User’s and Installer’s Manual Page 48, Total 52...
  • Page 49 Zone 6 Settings Zone 7 Settings Zone 8 Settings Utility Output Dialer Controls CS Protocols 1 CS Protocols 2 System Controls Periodic Time Set Zone 1 Alarm Zone 2 Alarm Zone 3 Alarm DSM-208CN User’s and Installer’s Manual Page 49, Total 52...
  • Page 50 User 6 disarm User 7 disarm User 8 disarm User 9 disarm Auto ARM Forced arm Stay Arm Duress Disarm Daily test Report Rpt Code Low Bat Rpt Code AC Loss DSM-208CN User’s and Installer’s Manual Page 50, Total 52...
  • Page 51 Zone 3 Bypass / Restore Zone 4 Bypass / Restore Zone 5 Bypass / Restore Zone 6 Bypass / Restore Zone 7 Bypass / Restore Zone 8 Bypass / Restore Phone1 Phone2 DSM-208CN User’s and Installer’s Manual Page 51, Total 52...

  • Page 52: Dsw's Warrant

    DSW’s Warrant DSW Electronics Ltd., and its Subsidiaries and Affiliates ("Seller") warrants its products to be free from defects in materials and workmanship under normal use for 18 months from the date of production. Because of Seller does not install or...
