RACING FORCE FEEDBACK WHEEL WITH GEARSHIFT AND PEDALS Quick Start Guide...
Page 2
RACING FORCE FEEDBACK WHEEL WITH GEARSHIFT AND PEDALS...
Page 3
ENGLISH 01-08 FRANÇAIS 09-16 DEUTSCH 17-24 ESPAÑOL 25-32 РУССКИЙ 33-40 ITALIANO 41-48 ARABIC 49-56 简体中文 57-64 繁體中文 65-72...
Page 4
ENGLISH Overview The M2X PRO RACING WHEEL is a 900-degree wired steering wheel designed for the PC, PS4, XBOX ONE and XBOX Series X/S platforms; it features a built-in intelligent drive motor and a desktop reinforcement bracket. Powered by a DC24V/2A power supply, it utilizes magnetic encoders and incorporates an automatic centering function on the racing wheel.
Page 5
M.2.X. PRO ENGLISH Button Layout / Functions 01. BREATHING LIGHT 12. R1 21. SETTING KEY FOR LED ADJUSTMENT BREATHING LIGHT 13. OPTIONS 02. PROG 22. RJ45 PORT FOR FOOT PEDALS 14. SHARE 03. L3 23. USB PORT FOR STEERING WHEEL 15.
Page 6
M.2.X. PRO ENGLISH Mounting Clamps Installation of mounting clamps: Installation of racing stand:...
Page 7
M.2.X. PRO ENGLISH Quick Installation ‒ Connection with PlayStation®4 2. Plug the PS4 controller into the USB port on 1. Plug the gearshift and foot pedals into the the side of racing wheel for bridging purposes corresponding ports on the racing wheel (the PS4 controller must be powered off...
Page 8
M.2.X. PRO ENGLISH Quick Installation ‒ Connection with XBOX® ONE™ & XB Series X/S 2. Plug the original Xbox controller into the USB 1. Plug the gearshift and foot pedals into the port on the side of the racing wheel for bridging corresponding ports on the back of the racing purposes (the Xbox controller must be powered wheel...
Page 9
M.2.X. PRO ENGLISH Quick Installation ‒ Connection with PC Platform D-INPUT mode: D-INPUT mode is set as default once power is connected; the breathing light will turn red (this mode supports the force feedback function, but also requires games that support force feedback).
Page 10
M.2.X. PRO ENGLISH Introduction to the 3-Foot Pedals • The left pedal is the clutch, the middle pedal is the brake and the right pedal is the accelerator. • If the game does not support clutch, it will have no function or be regarded a brake. •...
Page 11
M.2.X. PRO ENGLISH Troubleshooting: • If the “MODE” indicator light on the racing wheel does not light up when plugged into the console, please try re-plugging it or check if the bridging controller is working properly. • If the steering wheel does not respond and the console screen remains unchanged, please restart the console and then reconnect the steering wheel.
Page 12
FRANÇAIS Vue d’ ensemble Le volant de course M2X PRO est un volant filaire à rotation de 900 degrés conçu pour les plateformes PC, PS4, XBOX ONE et XBOX Series X/S ; il dispose d'un moteur d'entraînement intelligent intégré et d'un support de renforcement de bureau. Alimenté par une alimentation DC24V/2A, il utilise des codeurs magnétiques et intègre une fonction de recentrage...
Page 13
M.2.X. PRO FRANÇAIS Disposition des Boutons / Fonctions 01. RÉGLAGE DE LA 12. R1 21. RÉGLAGE TOUCHE POUR LUMIÈRE RESPIRANTE LED LUMIÈRE RESPIRANTE 13. OPTIONS 22. PORT RJ45 POUR PÉDALES 14. PARTAGER 02. PROG 23. PORT USB POUR VOLANT 03. L3 15.
Page 14
M.2.X. PRO FRANÇAIS Pinces de Montage Installation des pinces de montage: Installation du support de course:...
Page 15
M.2.X. PRO FRANÇAIS Installation Rapide ‒ Connexion avec PlayStation®4 2. Branchez la manette PS4 dans le port USB sur 1. Branchez le levier de vitesses et les pédales le côté du volant de course à des fins de liaison dans les ports correspondants sur le volant de (la manette PS4 doit être éteinte avant cette course.
Page 16
M.2.X. PRO FRANÇAIS Installation Rapide ‒ Connexion avec XBOX® ONE™ & XB Series X/S 2. Branchez la manette Xbox d'origine dans le 1. Branchez le levier de vitesses et les pédales port USB sur le côté du volant de course à des dans les ports correspondants à...
Page 17
M.2.X. PRO FRANÇAIS Installation Rapide ‒ Connexion avec PC Mode D-INPUT : Le mode D-INPUT est défini par défaut dès que l'alimentation est connectée ; la lumière respirante passera au rouge (ce mode prend en charge la fonction de retour de force, mais nécessite également des jeux qui prennent en charge le retour de force).
Page 18
M.2.X. PRO FRANÇAIS • Maintenez le bouton "PROG" enfoncé pendant 5 secondes et la LED respirante commencera à clignoter rapidement ; si aucune autre action n'est effectuée dans les 10 secondes qui suivent, le mode de programmation sera quitté. Ajustement de la Lumière Respirante LED sur le Volant de Course : •...
Page 19
M.2.X. PRO FRANÇAIS Dépannage: • Si le témoin lumineux "MODE" sur le volant de course ne s'allume pas lorsqu'il est branché dans la console, essayez de le rebrancher ou vérifiez si la manette de liaison fonctionne correctement. • Si le volant de direction ne répond pas et que l'écran de la console reste inchangé, redémarrez la console puis reconnectez le volant de direction.
Page 20
DEUTSCH Übersicht Das M2X PRO RACING WHEEL ist ein verkabeltes Lenkrad mit 900 Grad Drehung, das für die Plattformen PC, PS4, XBOX ONE und XBOX Series X/S entwickelt wurde. Es verfügt über einen eingebauten intelligenten Antriebsmotor und eine Desktop-Verstärkungshalterung. Mit einem DC24V/2A-Netzteil betrieben, nutzt es magnetische Encoder und integriert eine automatische Zentrierungsfunktion am Lenkrad.
Page 21
M.2.X. PRO DEUTSCH Tastenanordnung / Funktionen 01. ATMUNGSLICHT 12. R1 22. RJ45 PORT FÜR FUßPEDALE EINSTELLUNG 13. OPTIONEN 23. USB PORT FÜR LENKRAD 02. PROG 14. TEILEN 24. RJ11 PORT FÜR 03. L3 GANGSCHALTUNG 15. RECHTER PADDELSCHALTER 04. R3 25. STROMANSCHLUSS 16.
Page 22
M.2.X. PRO DEUTSCH Montageklemmen Installation der Montageklemmen: Installation des Rennlenkradständers:...
Page 23
M.2.X. PRO DEUTSCH Schnelle Installation ‒ Verbindung mit der PlayStation®4 2. Stecken Sie den PS4-Controller zum 1. Stecken Sie den Gangschaltknauf und die Überbrücken in den USB-Anschluss an der Seite Fußpedale in die entsprechenden Anschlüsse des Rennlenkrads. (Der PS4-Controller muss vor am Rennlenkrad.
Page 24
M.2.X. PRO DEUTSCH Schnelle Installation ‒ Verbindung mit der XBOX® ONE™ & XB Series X/S 2. Stecken Sie den originalen Xbox-Controller 1. Stecken Sie den Gangschaltknauf und die zum Überbrücken in den USB-Anschluss an der Fußpedale in die entsprechenden Anschlüsse Seite des Rennlenkrads.
Page 25
M.2.X. PRO DEUTSCH Schnelle Installation ‒ Verbindung mit der PC-Plattform D-INPUT-Modus: Der D-INPUT-Modus wird standardmäßig eingestellt, sobald die Stromversorgung angeschlos- sen ist; das Atemlicht wird rot (dieser Modus unterstützt die Force-Feedback-Funktion, erfordert jedoch auch Spiele, die Force-Feedback unterstützen). X-INPUT-Modus: Halten Sie die „HOME “ -Taste 3 Sekunden lang gedrückt, die LED blinkt 3 Mal auf und die Verbindung wechselt in den X-INPUT-Modus (dieser Modus hat keine Force-Feedback-Funktion), während das Atemlicht violett wird.
Page 26
M.2.X. PRO DEUTSCH Einstellen des LED-Atemlichts am Rennlenkrad: • Verfügbare Farben (Rot, Blau, Grün, Cyan, Gelb, Lila). • Halten Sie die „LED “-Taste 5 Sekunden lang gedrückt (die LED blinkt 3 Mal schnell), um die Einstellung zu starten. • Drücken Sie die „HOCH “- und „RUNTER “-Tasten an der Basis, um die Farben zu wechseln. •...
Page 27
M.2.X. PRO DEUTSCH Fehlerbehebung: • Wenn die „MODE “ -Anzeige am Rennlenkrad nicht aufleuchtet, wenn es an die Konsole angeschlossen wird, versuchen Sie bitte, es erneut einzustecken oder überprüfen Sie, ob der Überbrückungscontroller ordnungsgemäß funktioniert. • Wenn das Lenkrad nicht reagiert und der Bildschirm der Konsole unverändert bleibt, starten Sie bitte die Konsole neu und verbinden Sie dann das Lenkrad erneut.
Page 28
ESPAÑOL Resumen El VOLANTE M2X PRO es un volante con cable de 900 grados diseñado para PC, PS4, XBOX ONE y XBOX Series X/S; cuenta con un motor de accionamiento inteligente incorporado y un soporte de refuerzo de escritorio. Alimentado por una fuente de alimentación DC24V/2A, utiliza codificadores magnéticos e incorpora una función de centrado automático en el...
Page 29
M.2.X. PRO ESPAÑOL Lugar y funcionamiento de los botones 01. AJUSTE DE LUZ 12. R1 21. TECLA DE CONFIGURACIÓN PARA LA LUZ RESPIRATORIA LED 02. PROG 13. OPCIONES 22. PUERTO RJ45 PARA PEDALES 03. L3 14. COMPARTIR 23. PUERTO USB PARA EL VOLANTE 04.
Page 30
M.2.X. PRO ESPAÑOL Abrazaderas de Montaje Instalación de las abrazaderas de montaje: Instalación del soporte de carreras:...
Page 31
M.2.X. PRO ESPAÑOL Instalación rápida ‒ Conexión con PlayStation®4 2. Conecte el controlador PS4 al puerto USB en la 1. Conecte la palanca de cambios y los pedales parte lateral del volante con el propósito de al puerto correspondiente en el volante conexión puente (el controlador PS4 debe estar apagado antes de realizar esta acción).
Page 32
M.2.X. PRO ESPAÑOL Instalación rápida ‒ Conexión con XBOX® ONE™ & XB Series X/S 2. Conecte el controlador original de Xbox al 1. Conecte la palanca de cambios y los pedales puerto USB en la parte lateral del volante con en los puertos correspondientes en la parte fines de conexión puente (el controlador de Xbox trasera del volante...
Page 33
M.2.X. PRO ESPAÑOL Instalación Rápida ‒ Conexión con PC Modo D-INPUT: El modo D-INPUT se establece como predeterminado una vez que se conecta la alimentación; la luz respiratoria se volverá roja (este modo admite la función de retroalimentación de fuerza, pero también requiere juegos que admitan retroalimentación de fuerza).
Page 34
M.2.X. PRO ESPAÑOL • Mantenga pulsado el botón "PROG" durante 5 segundos y el LED de respiración comenzará a parpadear rápidamente; si no se siguen más acciones en 10 segundos, saldrá del modo de programación. Ajuste de la luz de respiración LED en el volante: •...
Page 35
M.2.X. PRO ESPAÑOL Solucionario de problemas: • Si el indicador "MODE" en el volante no se enciende al conectarlo a la consola, por favor intente volver a conectarlo o verifique si el controlador puente está funcionando correctamente. • Si el volante no responde y la pantalla de la consola permanece sin cambios, por favor reinicie la consola y luego vuelva a conectar el volante.
Page 36
M.2.X. PRO Обзор Игровой руль M2X PRO ‒ это игровой проводной руль, предназначенный для платформ PC, PS4, XBOX ONE и XBOX Series X/S.; 3 педали ‒ газ, тормоз и сцепление, 6+1 скоростей и целых 900 градусов поворота руля ‒ всё это обеспечивает подлинный гоночный опыт! В...
Page 37
РУССКИЙ M.2.X. PRO Расположение кнопок/ Основные функции 01. СВЕТОВЫЕ ИНДИКАТОРЫ 14. ПОДЕЛИТЬСЯ 22. RJ45 ПОРТ ДЛЯ ПРИСОЕДИНЕНИЯ НОЖНЫХ ПЕДАЛЕЙ 02. ПРОГРАММИРОВАНИЕ 15. ПРАВЫЙ ПОДРУЛЕВОЙ 23. USB ПОРТ ДЛЯ ПРИСОЕДИНЕНИЯ 03. L3 ПЕРЕКЛЮЧАТЕЛЬ РУЛЕВОГО КОЛЕСА 04. R3 16. R2 24. RJ11 ПОРТ ДЛЯ ПРИСОЕДИНЕНИЯ 05.
Page 38
РУССКИЙ M.2.X. PRO Зажимы Установка зажимов: Установка игрового гоночного стенда:...
Page 39
РУССКИЙ M.2.X. PRO Быстрое соединение с PlayStation®4 2. Подключите контроллер PS4 к USB-порту 1. Подключите педали и систему переключения на боковой панели игрового гоночного руля передач к соответствующим портам на задней (контроллер PS4 должен быть выключен). панели игрового гоночного руля. 3.
Page 40
РУССКИЙ M.2.X. PRO Быстрое соединение с XBOX® ONE™ & XB Series X/S 2. Подключите контроллер XBOX к USB-порту 1. Подключите педали и систему переключения на боковой панели игрового гоночного руля передач к соответствующим портам на задней (контроллер XBOX должен быть выключен). панели...
Page 41
РУССКИЙ M.2.X. PRO Быстрое соединение с ПК Platform Режим D-INPUT: Режим D-INPUT устанавливается по умолчанию после подключения питания; световой LED индикатор станет красным (этот режим поддерживает функцию обратной тактильной связи, но также требует наличия игр, поддерживающих обратную тактильную связь). Режим X-INPUT: Удерживайте...
Page 42
M.2.X. PRO РУССКИЙ • Удерживайте кнопку "PROG" в течение 5 секунд, и светодиодный LED индикатор начнет быстро мигать; если в течение 10 секунд не последовало никаких дальнейших действий, то режим программирования закроется. Настройка светового LED сигнала на игровом гоночном руле: •...
Page 43
M.2.X. PRO РУССКИЙ Возможные проблемы и их решения • Если индикатор "MODE" ("РЕЖИМ") на гоночном руле не загорается при подключении к консоли, попробуйте подключить его заново или проверьте, правильно ли работает контроллер сопряжения. • Если рулевое колесо не реагирует, а экран консоли остается неизменным, перезапустите консоль, а...
Page 44
ITALIANO Panoramica Il volante M2X PRO RACING WHEEL è uno sterzo cablato da 900 gradi progettato per PC, PS4 e per le piattaforme XBOX ONE e XBOX Serie X/S; dispone di un intelligente motore di guida integrato e di una staffa rinforzante per collegarlo alla scrivania. Alimentato da un trasformatore DC24V/2A, lo sterzo utilizza encoder magnetici e incorpora la funzione di centramento automatico.
Page 45
M.2.X. PRO ITALIANO Disposizione dei Pulsanti / Funzioni 12. R1 21. PULSANTE PER CONFIGURARE 01. REGOLAZIONE EFFETTO BREATHING LED BREATHING 13. OPZIONI 02. PULSANTE PROG 22. PORTA RJ45 PER LA PEDALIERA 14. CONDIVIDI 03. L3 23. PORTA USB DEL VOLANTE 15.
Page 46
M.2.X. PRO ITALIANO Montaggio Installazione dei morsetti: Installazione del supporto:...
Page 47
M.2.X. PRO ITALIANO Installazione Rapida ‒ Connessione con PlayStation®4 2. Collega il controller PS4 alla porta presente sul 1. Collega il cambio e la pedaliera alle porte lato del volante per connetterli (il controller PS4 corrispondenti disposte del volante. deve essere spento prima del collegamento). 3.
Page 48
M.2.X. PRO ITALIANO Installazione Rapida ‒ Connessione con XBOX® ONE™ & XB Serie X/S 2. Collega il controller originale Xbox alla porta 1. Collega il cambio e la pedaliera alle porte presente sul lato del volante per connetterli corrispondenti disposte sul retro del volante. (il controller Xbox deve essere spento prima del collegamento).
Page 49
M.2.X. PRO ITALIANO Installazione Rapida ‒ Connessione con Piattaforma PC Modalità D-INPUT: La modalità D-INPUT è impostata automaticamente quando si connette l’ alimentazione; la luce con effetto breathing diventerà rossa (questa modalità supporta la funzione “Force Feedback” ma è necessario che anche i giochi la supportino). Modalità...
Page 50
M.2.X. PRO ITALIANO • Tieni premuto il pulsante “PROG” per 5 secondi e il LED inizierà ad accendersi e spegnersi velocemente; se entro 10 secondi non viene effettuata alcuna azione, il volante uscirà dalla modalità di configurazione. Configurare il colore del LED sul Volante da Corsa: •...
Page 51
M.2.X. PRO ITALIANO Risoluzione dei Problemi: • Se la spia dell’ indicatore “MODE” sul volante non si accende quando è collegato alla console, prova a connetterli nuovamente oppure verifica il corretto funzionamento del controller. • Se il volante non risponde e lo schermo della console rimane invariato, riavvia la console e poi riconnetti il volante.
Page 52
M.2.X. PRO ARABIC M2X PRO PS4 XBOX ONE XBOX Series X / S DC24V / 2A 1 + 6 M2X PRO RACING 1* M2X PRO 1* Micro USB 1* Type C...
Page 53
M.2.X. PRO ARABIC RJ45 PROG OPTIONS SHARE RJ11 HOME MODE D-PAD XBOX A/B/X/Y...
Page 64
简体中文 M.2.X. PRO 快速安装 - 连接 XBOX® ONE™ & XB Series X/S 2. 将原版 Xbox 控制器插入赛车方向盘侧面的 USB 1. 将换挡杆和脚踏板插入赛车方向盘背面的相应 端口, 以便桥接 (在此操作前必须关闭 XBOX 控制器 接口。 的电源) 。 3. 打开 XBOX 电源后, 将赛车方向盘的 USB 数据线 4. 在 XBOX 上操作时, 短按赛车方向盘上的 插入 XBOX 主机的 USB 端口; 连接后, 赛车方向盘上 “HOME”...
Page 72
繁體中文 M.2.X. PRO 快速安裝 - 連接 XBOX® ONE™ & XB Series X/S 2. 將原版 Xbox 控製器插入賽車方向盤側面的 USB 1. 將換擋桿和腳踏板插入賽車方向盤背面的相應 端口, 以便橋接 (在此操作前必須關閉 XBOX 控製器 接口。 的電源) 。 3. 打開 XBOX 電源後, 將賽車方向盤的 USB 數據線 4. 在 XBOX 上操作時, 短按賽車方向盤上的 插入 XBOX 主機的 USB 端口; 連接後, 賽車方向盤上 “HOME”...
Page 76
FCC STATEMENTS NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
Page 77
For more information, go to www.P65Warnings.ca.gov. ATTENTION : Ce produit peut vous exposer au "Styrène", étant connu de l'état de Californie comme cause de cancer. Pour plus d'informations, rendez-vous sur www.P65Warnings.ca.gov. [型號/型号] : M.2.X. PRO 美加狮全球控股有限公司 Mad Catz Global Limited...
