Summary of Contents for Delixi CDKU-S200
- Page 1 CDKU-S200-350 Ultra-Thin Switching Power Supply User Manual Standard: Q/DLX 173 □ Please read the product instructions carefully before the installation and operation of the product, and keep those instructions properly for reference later...
- Page 2 1. Features and Purposes CDKU-S series product is a single group output enclosed switching power supply with 30mm ultra- thin appearance design, and the whole series of products use new technology, significantly reducing no-load power consumption and improving product efficiency, with efficiency up to 90%. It can be widely used in many fields such as communications, LED display, industrial control, radio and television, computer networks, medical apparatus and instruments, and intelligent monitoring.
- Page 3 4. Working Principle The switching power supply is used to control the switch tube through the circuit for high-speed turn-on and turn-off, thus generating required one set or multiple sets of voltage in the secondary stage of the switching transformer. 5.
- Page 4 Fig. 1 Output Derating Curve Ambient temp. (℃) Fig. 2 Output Derating Curve (Switch Selection) Input voltage (VAC) 50Hz/60Hz Fig. 3 Output Derating Curve (Full Range) Input voltage (VAC) 50Hz/60Hz...
- Page 5 Input DC Output current (A) Function Outlet Note 1 Note 2 Picture (bak 2) CDKU-S200 ABCK CDKU-S350 23.2 14.6 ABCDK Note 1: 85-132/170-264VAC is optional Note 2: Function A: Overload (overcurrent) short circuit protection; B: Output overvoltage protection; C: Over temperature protection;...
- Page 6 8. Outline Structure Fig. F1: Fig. F2: 9. Description of Common Icons and Symbols Symbol Description Only suitable for safe use in non-tropical climates Only suitable for safe use at the 2000m and below altitude Caution! Safety For indoor use only Earthed High voltage hazards! Danger! electric shock Warning!
- Page 7 Standard: Q/DLX 173 Inspector: Check 03 DELIXI ELECTRIC LTD Date of production: See the Product No. Zhejiang DELIXI Electrical Co., Ltd. Address: No. 155, Zhenzhan East Road, Liush Town, Yueqing City, Zhejiang Province 325604 Tel: (86-577)6177 8888 Fax: (86-577)6177 8000 Customer service hotline: 400-826-8008 www.delixi-electric.com...
