Toshiba REGZA CV51 Series Manual

Toshiba REGZA CV51 Series Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Série
CV51*
XV51*
DIGITAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the REGZA CV51 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Toshiba REGZA CV51 Series

Summary of Contents for Toshiba REGZA CV51 Series

  • Page 1 Série CV51* XV51* DIGITAL...
  • Page 3 Contents INSTALLING YOUR TV Picture still ............. 26 Panel lock ............26 Safety Precautions ..........4 The timers ............27 Installation and important information ....5 Programme Timers – digital only ....27 The remote control ..........6 Sleep Timer ........... 27 Inserting batteries and effective range of the Digital on-screen information and Programme remote ............7 Guide ...............
  • Page 4 INSTALLING YOUR TV Safety Precautions DO NOT REMOVE ANY FIXED COVERS AS THIS WILL EXPOSE DANGEROUS AND 'LIVE' PARTS. This equipment has been designed and manufactured THE MAINS PLUG IS USED AS A DISCONNECTING to meet international safety standards but, like any DEVICE AND THEREFORE SHOULD BE READILY electrical equipment, care must be taken to obtain the OPERABLE.
  • Page 5 Furthermore, under no circumstances shall Toshiba be liable for any consequential loss and/or damage including but not limited to the following, loss of profit, interruption of business, the loss of recorded data whether caused during normal operation or misuse of the product.
  • Page 6 INSTALLING YOUR TV The remote control To mute the TV sound (T/R/D) 10 On-screen menus (T) Simple at-a-glance reference of your remote DVD menus (R/D) control. 11 To exit menus (T) To return to previous menu (R/D) 12 When using menus the arrows move the cursor on the screen up, down, left or right.
  • Page 7 INSTALLING YOUR TV Inserting batteries and effective range of the remote Remove the back cover to reveal the battery compartment and make sure the batteries are inserted the right way round. Suitable battery types for this remote are AAA, IEC R03 1.5V. Do not combine a used, old battery with a new one or mix battery types.
  • Page 8 CONNECTING YOUR TV Connecting external equipment Before connecting any external equipment, turn off all main power switches. If there is no switch remove the mains plug from the wall socket. OPTICAL DIGITAL AUDIO OUTPUT HDMI™ INPUT SOCKETS COMPONENT VIDEO INPUT (EXT3) SCART 2 (EXT2) SCART 1 (EXT1) FIXING STRAP...
  • Page 9 CONNECTING YOUR TV Connecting an HDMI™ or DVI To connect a DVI device device to the HDMI input Connect an HDMI-to-DVI adapter cable (HDMI type A connector) to the HDMI1 terminal and audio cables to the PC/ The HDMI input on your television receives digital HDMI1 (AUDIO) socket (see illustration).
  • Page 10 • For proper operation, it is recommended that you use HDMI by the HDMI standard. cables with the HDMI Logo ( • This feature is limited to models incorporating Toshiba’s • The HDMI3 terminal is located at the side of the television. REGZA-LINK. However, Toshiba is not liable for those operations.
  • Page 11 CONNECTING YOUR TV Connecting a computer • A band may appear at the edges of the screen or parts of the picture may be obscured. This is due to scaling of the picture by the set, it is not a malfunction. With either the RGB/PC or an HDMI connection, •...
  • Page 12 CONNECTING YOUR TV Controls and input connections A wide variety of external equipment can be connected to the input sockets on the side of the television. Whilst all the necessary adjustments and controls for the television are made using the remote control, the buttons on the television may be used for some functions.
  • Page 13 SETTING UP YOUR TV Startup Application Press to view the DTV (digital channel) or ATV (analogue channel) lists. Before switching on the television put your decoder and media recorder to Standby if they are Auto Tuning connected. Prog. Name Type To set up the television use the buttons on the remote control as detailed on page 6.
  • Page 14 SETTING UP YOUR TV Auto Tuning Auto Programme Update If the Auto Programme Update is set to On, when the TV is NOTE: As new services are broadcast it will be necessary to re- in standby mode, the Digital Tuning is automatically executed tune the television in order to view them.
  • Page 15 SETTING UP YOUR TV DTV Settings Press to store your move. Repeat as necessary, then press Programmes The Skip setting for the highlighted programme can be switched between “Set/Not Set” by pressing the RED The station order may be changed to suit your personal button on the remote control.
  • Page 16 SETTING UP YOUR TV ATV Manual Tuning Press and using select the SETUP menu. With highlight ATV Manual Tuning and press to select. Tuning The television can be tuned-in manually using ATV Manual Tuning. For example: if the television cannot be connected to SETUP a media recorder/decoder with a SCART lead or to tune-in a Menu Language...
  • Page 17 SETTING UP YOUR TV Programme skip Each signal will show on the television, if it is not your media recorder, press again to restart the To prevent certain programmes from being viewed, the search. programme position can be skipped. The remote control must be removed as the channels will still be available using the When your media recorder signal is found, press number buttons.
  • Page 18 SETTING UP YOUR TV Sorting programme positions Channels may be moved and stored to the programme position of your choice. Select ATV Manual Tuning from the SETUP menu. With the list of stations now showing use highlight the station you want to move and press The selected station will be moved to the right of the screen.
  • Page 19 CONTROLS AND FEATURES General controls Sound controls Selecting programme positions Volume controls and mute sound To select a programme position use the numbered buttons on Volume the remote control. Press to adjust the volume. Programme positions can also be selected using P and P Sound Mute Press...
  • Page 20 CONTROLS AND FEATURES When an active Super Woofer is connected to the Woofer Out Stable Sound ® connection on the back of the television, select AV Connection in the SETUP menu, press to highlight Woofer The Stable Sound feature limits high volume levels on the TV and use to select External.
  • Page 21 CONTROLS AND FEATURES Widescreen viewing Depending on the type of broadcast being transmitted, programmes can be viewed in a number of formats. Press repeatedly to select between Exact Scan, Native, Wide, Super Live 2, Cinema 2, 4:3, Super Live 1, Cinema 1, Subtitle and 14:9. SUPER LIVE 1 This setting will enlarge a 4:3 image to fit the screen by stretching the...
  • Page 22 CONTROLS AND FEATURES Use this setting when watching a widescreen DVD, widescreen video tape or a 16:9 broadcast (when WIDE available). Due to the range of widescreen formats (16:9, 14:9, 20:9 etc.) black bars may be visible on the top and bottom of the screen. Use this setting to view a true 4:3 broadcast.
  • Page 23 CONTROLS AND FEATURES Press to display the list of available widescreen formats. Press to select an option, then to highlight the required format and Q to adjust the settings. select. The options alter depending on currently selected AV format PC format widescreen format and the input signal.
  • Page 24 CONTROLS AND FEATURES Picture preferences Cinema Mode This television offers the choice of personalising the picture If there are lines or jagged edges in the film or programme style. Press to view the different styles available: being viewed, selecting Cinema Mode can help correct this by smoothing out the picture.
  • Page 25 CONTROLS AND FEATURES 3D Colour Management Active Backlight Control When 3D Colour Management is set to On it allows the ‘Base When Active Backlight Control is activated it will Colour Adjustment’ feature to become available. automatically optimise the backlighting levels for dark scenes. In the PICTURE menu press to select 3D Colour In the PICTURE menu press...
  • Page 26 CONTROLS AND FEATURES Automatic Format (Widescreen) Picture still When this television receives a true Widescreen picture and This feature is used to hold a still image on the screen. Auto format is On, it will automatically be displayed in Press to hold an image on the screen, press Widescreen format, irrespective of the television’s previous again to cancel.
  • Page 27 CONTROLS AND FEATURES The timers Sleep Timer The television can be set to turn itself Off after a certain length of time. Programme Timers – digital only Press to select the TIMERS menu. This feature will set the television to go to a specific channel at a certain time.
  • Page 28 CONTROLS AND FEATURES Digital on-screen On-screen Information icons information and Programme Icon Description Guide Service info Service type (TV, Radio) Skip Audio info Mono When viewing in digital mode, the on-screen Stereo information and programme guide give access to Dual mono programme details for all available channels.
  • Page 29 CONTROLS AND FEATURES Guide Genre selection/searching From the guide screen, you can use the genre selection and Select the on-screen guide by pressing GUIDE, the search features. guide screen will appear highlighting details of the programme and event currently being viewed. This Press the YELLOW button from the guide screen.
  • Page 30 CONTROLS AND FEATURES Digital settings – parental Parental Setup control The Parental Control feature allows you to block programmes according to their rating levels. If a PIN has been set, you will In order to prevent viewing of unsuitable films and need to enter it before adjusting the level.
  • Page 31 CONTROLS AND FEATURES Digital settings – Programme Locking programmes Options Locking Programmes stops the viewing of digital channels, they can only be accessed by entering the PIN. Selecting favourite programmes From the DTV Settings menu press to select Programme Options and press Favourite Programmes creates a list of the digital programmes that are watched most.
  • Page 32 CONTROLS AND FEATURES Digital settings – other Common Interface settings The Common Interface Slot, situated on the side of the television, enables the insertion of a CAM (Conditional Access Module) and card. These are purchased from a service provider Subtitles and allow additional subscription broadcasts to be viewed.
  • Page 33 CONTROLS AND FEATURES Software Upgrade Searching for New Software If preferred, software upgrades can be searched for manually using Search for New Software. Version In the Software Upgrade menu press This feature can be used to check the version of software select Search for New Software.
  • Page 34 CONTROLS AND FEATURES PC settings Sampling Clock Adjusting the Sampling Clock alters the number of pulses per scan, this will clear vertical lines on the screen. Horizontal and Vertical Position In the SETUP menu press until PC Settings is Connect the PC (as shown in the ‘Connecting a PC’ section) and highlighted.
  • Page 35 CONTROLS AND FEATURES Input selection and AV INPUT signal selection connections This specifies the type of signal going into SCART 2 (EXT2) on the back of the television. Please refer to the manufacturers See page 8 for a clear view of the back connection instructions for the connected equipment.
  • Page 36 CONTROLS AND FEATURES PC Audio Lip Sync Latency In order to receive sound from a connected PC, plug the audio Lip Sync can synchronize the sound and picture. This feature is cable into the back of the television (as shown in ‘Connecting a only available for HDMI equipment compatible with Lip Sync.
  • Page 37 When Amplifier Control is set to On, it allows the “Speaker This is a new feature that uses CEC technology and Preference” feature to become available. allows you to control Toshiba REGZA-LINK compatible devices from the television remote In the REGZA-LINK menu press to highlight control via HDMI connection (page 10).
  • Page 38 CONTROLS AND FEATURES NOTE: REGZA-LINK system standby • These functions depend on the device connected. • If you select the REGZA-LINK input source from the popup If the television is turned off (standby mode), the television will window, some REGZA-LINK devices may automatically turn send a message to turn off (standby mode) all of the REGZA- LINK devices connected to the television.
  • Page 39 For further information on your particular text system(s), see Selecting modes the broadcast text index page or, consult your local Toshiba dealer. The text character set will be automatically chosen by the language setting in the SETUP menu.
  • Page 40 TEXT SERVICES Control buttons Below is a guide to the functions of the remote control text buttons. k To display the index/initial page: Press to access the index/initial page. The one displayed is dependant on the broadcaster. TEXT To display a page of text: Press TEXT to display text.
  • Page 41 Check the correct input has been chosen, S-VIDEO or common queries. AV. See AV Connections on page 35. For more information go to www.toshiba.co.uk What else can cause a poor picture? Why is there no sound or picture? Interference or a weak signal. Try a different television Check the television is not in standby mode.
  • Page 42 PROBLEM SOLVING Why are some of the digital subscription channels Why are there no analogue text sub-pages? unavailable? Your subscription needs upgrading. Contact your There are none broadcast or they have not yet loaded. service provider. Press the button to access. (See text section).
  • Page 43 PROBLEM SOLVING Why are the LEDs on the front of the television Why don't the devices connected via HDMI operate flashing? properly? Check the table below. Make sure to use cables with the HDMI logo (see page 9). Some early HDMI equipment may not work properly with the latest HDMI TV products, due to new standard LED indication Condition...
  • Page 44 INFORMATION Notes For your own records Cleaning the screen and cabinet… Turn off the power, clean the screen and cabinet with a soft, dry cloth. We recommend that you do not use any proprietary polishes or solvents on the screen or cabinet as this may cause damage. Disposal…...
  • Page 45 INFORMATION For your own records...
  • Page 46 INFORMATION Information Before connecting any external equipment, turn off all main power switches. If there is no switch remove the mains plug from the wall socket. Signal information for Mini D-sub 15 pin connector Pin No. Signal name Pin No. Signal name Pin No.
  • Page 47 INFORMATION Acceptable video or PC signals through HDMI terminals Format Resolution V. Frequency H. Frequency Pixel Clock Frequency 480i 720 × 480i 59.940/60.000Hz 15.734/15.750kHz 27.000/27.027MHz 576i 720 × 576i 50.000Hz 15.625kHz 27.000MHz 480p 720 × 480p 59.940/60.000Hz 31.469/31.500kHz 27.000/27.027MHz 576p 720 ×...
  • Page 48 DVB is a registered trademark of the DVB Project Printed on recycled paper. 100% Chlorine free. © Toshiba Information Systems (U.K.) Limited All rights reserved. Reproduction in whole or part without written permission is strictly prohibited. Toshiba Information Systems (U.K.) Limited...
