WTD128 Hot Water System
Revision ：OR
th
Revised date: 9
April 2024
Thank you for choosing our hot water system! This user manual is designed to provide you with all the
information you need to operate and maintain your hot water system effectively. Please read this manual
carefully before using the product.
0 / 12
More information https://www.caravansplus.com.au
Advertisement
Summary of Contents for Global WTD128
- Page 1 User manual WTD128 Hot Water System Revision ：OR Revised date: 9 April 2024 Thank you for choosing our hot water system! This user manual is designed to provide you with all the information you need to operate and maintain your hot water system effectively. Please read this manual carefully before using the product.
- Page 2 Safety Precautions: ........................................2 System Overview: ......................................... 2 Operating Instructions: ........................................ 2 Electric heating (Campsite, Home) ....................................3 Gas heating (Off grid camping) ...................................... 3 Electric / Gas combined heating....................................3 Maintenance and Cleaning: ...................................... 3 Regular Inspections:........................................... 3 Draining operation &...
- Page 3 Safety Precautions: ▪ Read and understand the entire manual before operating the hot water system. ▪ Ensure proper ventilation when using gas-powered systems. ▪ Do not touch hot surfaces during or immediately after operation. ▪ Keep children and pets away from the hot water system. ▪...
- Page 4 Electric heating (Campsite, Home) ▪ When main power is connected ▪ Turn the Electric element switch ON. ▪ The heater will automatically start heating the water until reaching the preset temperature. ▪ Water heater will automatically maintain the water temperature. Gas heating (Off grid camping) ▪...
- Page 5 Drain the water heater at regular intervals to remove sediment buildup (at least one time during the year). Your WTD128 water heater is fitted with a sacrificial anode rod which helps preventing corrosion by attracting corrosive elements. The anode rod needs to be replaced periodically.
- Page 6 ▪ Rumbling or Booming Sounds: These sounds can indicate excessive pressure or overheating. Adjust the thermostat to a lower setting if needed or check the pressure relief valve. Pilot light keeps going out: • Thermocouple Issues: A malfunctioning thermocouple may cause the pilot light to go out. Replace the thermocouple if necessary.
- Page 7 The water heater exhaust can exceed 300 °C (572 °F) at the vent and GLOBAL HERITAGE suggests the installer review the specific application when maintaining distances less than the recommended clearances.
- Page 8 ▪ DANGER: The operation of the thermal cut-out indicates a possibly dangerous situation. Do not reset the thermal cut-out until the water heater has been serviced by a qualified person. ▪ DANGER: Failure to operate the relief valve easing gear at least once every six months may result in the water heater exploding.
- Page 9 Connect the copper pipe to the connector 5/8” -18 UNF. ▪ Installation to meet AS/NZS5601 requirements. ▪ Check for gas leak. ▪ Check gas pressure. Appliance control panel installation ▪ Install the internal control panel on a partition wall. Diameter access hole D=60mm ▪...
- Page 10 7.10 Secure the unit. ▪ Fasten the appliance by screwing the flange to the wall at the 17 screwing positions. ▪ Apply silicon bead against the foam tape to ensure waterproofing. ▪ Screw the fixation brackets to both sides. (Approximately100mm from the tank end) ▪...
- Page 11 7.12 Wiring diagram 10 / 12 More information https://www.caravansplus.com.au...
- Page 12 This warranty only applies to a new water heater, purchased, and used in Australia. The warranty period is 12 months in Australia following the date of original purchase. During the Warranty Period, Global Heritage will, at no extra charge, repair or replace any parts which it considers to be defective.
