Summary of Contents for UNI-TROL PO-14 S
- Page 1 English INSTRUCTIONS BOOKLET RIM PRESS PO-14 S Грузик - все для шиномонтажа www.gruzik.com.ua...
- Page 2 Year from date of it is sold. Our company Uni-trol Co. Ltd. is not responsible for the damages or defects due to damages occured by faulty used and out of purpose of use.
- Page 3 IMPORTANT NOTICE The presents instructions booklet is an integral part of the product. Carefully study the warnings and instructions contained in it. This information is important for safe use and maintenance. Conserve this booklet carefully for further consultation. THIS MACHINE Is a rim pres to repair defective rims.
- Page 4 INTRODUCTION WARNING THIS MANUAL HAS BEEN PREPARED FOR WORKSHOP PERSONNEL EXPERT IN THE USE OF THE MACHINE (OPERATOR) AND TECHNICIANS RESPONSIBLE FOR ROUTINE MAINTENANCE (MAINTENANCE FITTER); READ THE MANUAL BEFORE CARRYING OUT ANY OPERATION WITH THE RIM REPAIR AND/OR PACKING . THIS MANUAL CONTAINS IMPORTANT INFORMATION REGARDING : RIM REPAIR MACHINES SAFETY THE PERSONNEL SAFETY OF OPERATORS AND MAINTENANCE WORKERS...
- Page 5 OPERATION CONNECTING THE DEFECTIVE RIM TO THE FLANSH Clean the muds and the balance weights from the rim Choose suitable sized 3. Tight the connecting flansh and fasten Rotate the flansh connecting flansh for the rim. to the suitable canals on the flansh. ...
- Page 6 OPERATION SOME EXAMPLES OF THE REPAIR If the defect is on the front surface to the outer side of the rim If the defect is from inner to the outer side of the rim If the defect is from outer to the inner side of the rim.
- Page 7 ROUTINE MAINTENANCE To gurantee the efficiency of the machine and for its correct functioning is essential to carry out routine cleaning and maintenance. Routine maintenance must be carried out by the user according to the maker’s instruction. Before starting any cleaning or maintenance switch off the main switch and remove the mains plug from socket. EVERY DAY...
- Page 8 MACHINE ASSEMBLY AND SET UP When you open the case of the machıne check the machıne ıs there any damage or mıssıng parts because of the transport. take care of the naıl, wıre and stampıng materıal on the package when you dısassemblıng the packıng. Грузик...
- Page 9 ELECTRIC DIAGRAM Грузик - все для шиномонтажа www.gruzik.com.ua...
- Page 10 DEMONTAGE PLAN Грузик - все для шиномонтажа www.gruzik.com.ua...
- Page 11 < Грузик - все для шиномонтажа www.gruzik.com.ua...
- Page 12 SPARE PARTS LIST FOR PO-14 S COD NUMBER DESCRIPTION 01 0047 03 Allen Head Set 15 29 000 Support Set With Miles Complete 15 29 001a Angular Supports 15 29 001b Angular Supports 15 29 001c Sguare Supports 15 29 001d...
- Page 13 SPARE PARTS LIST FOR PO-14 S COD NUMBER DESCRIPTION 14S 05 000 Magnetic gauge stick 14S 05 002 Stick connection plastic 01 0008 63 Spiral hose 26 10 001 Center flange 01 0024 040-2 O-ring Rim to center washer – 54 26 10 054.0...
- Page 14 Account : for EURO : ALIOR BANK SA for EURO: no. PL 96 2490 0005 0000 4600 4784 6179 (swift code: ALBPPLPW) EU Declaration of Conformity in accordance with directives : 2006/42/EU, 2014/35/EU, 2014/30/EU Uni-Trol Co. Ltd. Ul. Estrady 56 01-932 Warsaw Poland...
- Page 15 The technical documentation mentioned product, as specified in Annex VII A, point 1 of the Machinery Directive, is located in the headquarters Uni-trol Ltd. (address as above) and will be made available to the competent national authorities for at least ten years from the date of the last piece.
