- Page 1 INSTRUCTION MANUAL 3-Piece Oval Dining Set SKY8101 + SKY8102 + SKY8103 + SKY8104 + SKY8105 + SKY8106 SKY8107 + SKY8108 + SKY8109 Ver. 1...
- Page 2 NOTICE Please retain these instructions for future reference. • Please do not exceed the weight limitations of this item. • Do not stand on or use any part of this item as a step ladder. • Firmly secure all bolts, screws and knobs before use. •...
- Page 3 PARTS TABLE SUPPORT BACKREST BACK SUPPORT (BOTTOM) 1 PC 2 PCS 2 PCS CHAIR LEGS (TOP) CHAIR LEGS (BOTTOM) SEAT 2 PCS 2 PCS 2 PCS CHAIR SUPPORT BAR CHAIR SUPPORT BAR (LEFT) (RIGHT) 2 PCS 2 PCS...
- Page 4 TABLE ASSEMBLY Attach two part 2 table legs to the part 3 table support (top) with four part A bolts, two bolts per leg. Attach two part 2 table legs to the part 4 table support (bottom) with four part A bolts, two bolts per leg.
- Page 5 TABLE ASSEMBLY Insert one part B bolt sleeve into the center fastener hole of the part 3 table support (top). Place the part 4 table support (bottom) under the part 3 table support (top), then connect the two by threading one part A bolt into the part B bolt sleeve. Place the part A tabletop top-side down on a flat, level surface, then attach the four part 2 Place the part A tabletop top-side down on a flat, level surface, then attach the four part 2 table legs to the bottom of the tabletop with sixteen part A bolts, four bolts per leg.
- Page 6 CHAIR ASSEMBLY Place one set of part 7 chair legs on top of the part 8 chair legs, then interlock them by attaching one part 10 and one part 11 chair support bar with four part A bolts, two bolts per support. Place one part 9 seat top side down on a flat, level surface, then attach the part 7 and 8 chair Place one part 9 seat top side down on a flat, level surface, then attach the part 7 and 8 chair legs to the bottom of the seat with five part C bolts.
- Page 7 CHAIR ASSEMBLY Flip the leg assembly upright, then attach one part 6 back support to the receivers on the part 7 and 8 chair legs, and secure with four part A bolts. Attach the part 5 backrest to the part 6 back support with two part A bolts, and Attach the part 5 backrest to the part 6 back support with two part A bolts, and two part C bolts.
- Page 8 HELP CENTER Question about your product? We're here to help. Visit us at: help.bestchoiceproducts.com CHAT Chat Support Product Inquiry Orders FAQ Product Assembly Returns & Refunds PRODUCT WARRANTY INFORMATION All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the item is returned in its original product packaging and all accessories from its original shipment are included.
