460 Southport Commerce Blvd.
Spartanburg SC 29306
Phone: 864-574-6004
Toll Free: 1-888-532-2816
sales@ojedausainc.com
service@ojedausainc.com
www.ojedausa.com
NBH-series
Installation and
Operation Manual
NBH-28
NBH-34
NBH-43
NBH-51
NBH-60
NBH-68
NBH-34
NBH-51
www.ojedausa.com
Part Number 100330101
Advertisement
Related Manuals for Ojeda NBH-34
Summary of Contents for Ojeda NBH-34
- Page 1 460 Southport Commerce Blvd. Spartanburg SC 29306 Phone: 864-574-6004 Toll Free: 1-888-532-2816 sales@ojedausainc.com service@ojedausainc.com www.ojedausa.com NBH-series Installation and Operation Manual NBH-28 NBH-34 NBH-43 NBH-51 NBH-60 NBH-68 NBH-34 NBH-51 www.ojedausa.com Part Number 100330101...
- Page 2 You have selected one of the finest commercial refrigeration units made. It is manufactured under strict quality controls with only the best quality materials available. Your Ojeda cooler when installed correctly and properly maintained will give you many years of trouble-free operation.
- Page 3 This manual provides instructions in how to best locate, operate, and maintain this equipment. It is recommended to keep this manual for any future reference. Detailed Warranty Guidelines can be found on the Ojeda website. APPLICATION The NBH-series of freezers have a sanitation listing permitting the merchandising of packaged food product.
- Page 4 DIRECTIONS FOR STORAGE AND HANDLING THE EQUIPMENT STORAGE OF THE EQUIPMENT If the equipment will be kept in storage, it is suggested to keep it in its original packing. In case you need your equipment to be inactive for a long period of time after being used, verify that it has been unplugged.
- Page 5 ENERGY SAVINGS IDEAS The location of the cooler must be kept away from sources of heat and humidity including direct sunlight, toasters, ovens, co ee warmers, other appliances condenser air discharge, infrared heaters, or other heat generating appliances. Overloading the freezer forces the compressor to run longer. Do not exceed the load limit according to labels fixed on the inner cabinet (which corresponds to the baskets height).
- Page 6 The use of extension cords is not permitted and will void the warranty. Voltage Current Circuit NEMA Model Required (A) Config. NBH-28 5-15P NBH-34 5-15P NBH-43 5-15P NBH-51 5-15P NBH-60 5-15P NBH-68 5-15P Before connecting your equipment, check that the electrical data on the data plate match your electrical output.
- Page 7 UNIT OPERATIONS SETTING THE TEMPERATURE CONTROL To access the temperature control, the right side grill should be removed using a Phillips screw driver. The temperature control is factory pre-set to provide satisfactory product storage products. However, the temperature control is adjustable to provide a range of temperatures for your personal satisfaction.
- Page 8 SERVICE CHECKLIST Before calling for service, review this list. It may save you both time and expense. This list includes common occurrences that are not the result of detective workmanship or materials in this appliance. OCCURRENCE SOLUTION Freezer does not run Check to ensure that freezer is not plugged into a circuit that has ground fault interrupt.
- Page 9 PRESCRIPTIONS, PROHIBITIONS AND OTHER USES FOR THE EQUIPMENT The equipment has been exclusively designed to maintain the proper temperature of packaged food products. Because the unit is not designed to cool the product down quickly, the product must be loaded at its appropriate temperature. Displaying pharmaceutical products in this unit is prohibited.
- Page 10 MAINTENANCE GUIDELINES Regularly and carefully cleaning and defrosting the equipment prevents deterioration and product alteration. REMOVAL OF FROST It is recommended to remove the frost accumulated before reloading the freezer or anytime when one quarter inch of frost has accumulated. The unit will have to be manually defrosted.
- Page 11 MAINTENANCE GUIDELINES CLEANING THE INSIDE WARNING! DAMP OBJECTS STICK TO COLD METAL SURFACES. DO NOT TOUCH THE INTERIOR METAL SURFACES WITH WET OR DAMP HANDS. After defrosting, wash the inside surfaces of the freezer with a solution of two tablespoons of baking soda in one quarter of a gallon (1.1 liters) warm water.
- Page 12 MAINTENANCE GUIDELINES LID REMOVAL If lids must be removed: 1. Stand in front of the freezer (Fig.1) 2. Assure that the lower lid is totally closed to the left side of the freezer (Fig.2) 3. To remove the top lid, run it open to its maximum, handling it by both sides push it to the back (Fig.3).
- Page 13 TECHNICAL ASSISTANCE If technical personnel assistance is required, you must immediately contact your distributor, specifying the kind of problem and clearly indicating the equipment model and serial number. If replacing parts is required, do it through your distributor. WARNING: Always ask for original spare parts AUTHORIZED DISTRIBUTOR: _______________________________________ COMMERCIAL NAME:...
