brel-motors MH92 Manual

Manual Brel 92mm standard motor with manual override
Read the manual before you begin the installation. If these instructions are not followed,
this may lead to defects and injury in which warranty can't be claimed.
warning:
Children cannot recognize the dangers of electrical equipment and may therefore not work with it.
It is important to follow this instruction for your own safety.
1. Do not operate the motor in humid surroundings.
2. The motor must be installed correctly.
3. The motor must be protected from direct moisture influences.
4. The motor should be installed with the motor cable down in order to prevent moisture via the motor cable is
running in the motor . See Figure 1
It is prohibited to connect two motors on a switch without using a relay control.
5.
_________________________________________________________________________________
Technical data of the motor
• Motor Voltage:
•
Power:
• Torque:
• Speed:
• Ampèrage:
•
Moisture and dust:
•
Working temperature of the motor:
o Normal use:
o Heavy use:
BREL motors is part of:
Type MH92
Type MH92-300
AC 230V
940 Watt
300 Nm
9 rpm
4.08 A
IP44
-10℃ tot +40℃
-20℃ tot +70℃
Page 1
Figure 1
