Med-Fit

Medi-Boost TENS & EMS

Please read this Quick Guide

before using your Medi-Boost

med

fit

Tel: 0161 429 7330

email sales@med-fit.co.uk

Pain Relief

TENS Machine

Muscle Stimulation

Improve Lower Leg

Blood Circulation

18 CLINICALLY

APPROVED PROGRAMMES

DRUG

CLASS IIA

MEDICAL

FREE

DEVICE

2862

Need help?

Do you have a question about the Medi-Boost KTR-402 and is the answer not in the manual?

Questions and answers

Summary of Contents for Med-Fit Medi-Boost KTR-402

Page 1 Pain Relief TENS Machine Muscle Stimulation Improve Lower Leg Medi-Boost TENS & EMS Blood Circulation 2862 Please read this Quick Guide 18 CLINICALLY APPROVED PROGRAMMES before using your Medi-Boost DRUG CLASS IIA MEDICAL FREE DEVICE Tel: 0161 429 7330 email sales@med-fit.co.uk...
Page 2 Contents Product Overview ..............3 What is inside the box ..............4 Controls ..................5 Preparation before using the Medi-Boost ........6 Setting up the Medi-Boost for the first time ........6 Charging your Medi-Boost ............6 Using your Medi-boost - Foot Plate ..........8 Using your Medi-Boost Body Electrodes ........
Page 3 As a registered medical company, we are always here to help. If you require more details on using your Medi-Boost please email sales@med-fit.co.uk or call us at 0161 429 7330 Monday to Friday 7.30 am - 3.30 pm. We try to answer all emails within one hour.
Page 4 What is inside the box? When opening the box, please check that the following components are provided. If you think anything is missing, please get in touch with us by telephone or email see the back page for contact details. Medi-Boost Base 2 x Rectangle Electrodes 10cm x 8cm Foot...
Page 5 Foot Plates Electrode Lead Socket for use with the body electrodes USB Power Adaptor Socket Remote Control Battery Indicator Time Screen Programme Selector Programme Setting Foot Intensity Controls Body Intensity Controls Foot Body Power On / Off Button Intensity Setting www.med-fit.store...
Page 6 Preparation before using the Medi-Boost Setting up the Medi-Boost for the first time Remove all parts from the box: 1 x Medi-Boost foot platform 1 x Remote control 1 x Mains adaptor 1 x USB charging cable 2 x AAA batteries (for the remote control) 2 x Rectangle electrodes 10cm x 8cm 1 x Small butterfly electrodes 15cm x 9cm 1 x Large butterfly electrodes 20cm x 10cm...
Page 7 It is important to follow these instructions as very high skin resistance due to dry skin can cause a barrier where stimulation will not be felt even at high-intensity levels. www.med-fit.store...
Page 8 Using your Medi-boost - Foot Plate Foot Body STEP 1 Press the ON/OFF button once on your Medi-Boost, a blue light will flash continuously. Please note, the device will turn off automatically after 30 seconds if not activated. If this happens simply press the ON/OFF button to activate. STEP 2 Press and hold the On/Off button on your remote control whilst pointing the remote control at the square receiver window on...
Page 9 If you feel pain or discomfort, remove one or both feet from the foot plate to stop the stimulation. Foot Body Lower the intensity of the foot plate using the [-] intensity control on the remote control before replacing your feet. www.med-fit.store...
Page 10 Using your Medi-Boost Body Electrodes Foot Body STEP 1 Press the ON/OFF button once on your Medi-Boost, a blue light will flash continuously. Please note, the device will turn off automatically after 30 seconds if not activated. If this happens simply press the ON/OFF button to activate. STEP 2 Press and hold the On/Off button on your remote control whilst pointing the remote control at the square receiver window on...
Page 11 Press the body intensity [+] button, continue to increase the intensity until you can feel the stimulation. You can decrease the intensity by pressing the [-] button. If you feel pain or discomfort, lower the intensity by using the [-] intensity control on the remote control. Foot Body www.med-fit.store...
Page 12 TENS Body Programmes The Medi-Boost has a choice of 9 TENS body programmes. TENS Body Programmes TENS - Body Programmes are ideal for treating and relieving pain and discomfort. Modes 1, 2 & 3: - These modes offer the most pain relief on joint conditions ideal for: Ankle, Knee, elbow, shoulder and also helpful for those with hip pain.
Page 13 TENS & EMS Technology This Medi-Boost utilises (TENS & EMS) technology to gently stimulate the nerves in your feet and ankles, improving blood flow and alleviating discomfort. It’s important to note that TENS & EMS can be used as frequently as needed. www.med-fit.store...
Page 14 Helpful Tips for Successful TENS Treatment Once you have familiarised yourself with the controls and features of your TENS device, it is important to place the TENS electrodes in a position which gives the most pain relief. This may take 3 or 4 attempts to find the most suitable position for maximum pain relief.
Page 15 Body Electrode Placement Frozen Shoulder Lower Back Pain Shoulder Pain Hip Neuralgia Degenerative Arthritis: Cervical and Lumbar Phantom Limb, Lower Extremity Chronic Hip Pain Sciatica www.med-fit.store...
Page 16 Body Electrode Placement Low Extremity Pain Lower Leg Pain Degenerative Arthritis - Knee Pain Cervical Placement Carpal Tunnel Syndrome Chronic Cervical Strain Wrist, Elbow & Forearm Pain Knee Pain - Post-Op Telephone: 0161 429 7330...
Page 17 If this happens, reduce the • Applying electrodes to the head, face, neck, or chest intensity and duration of treatment. If symptoms can cause serious health issues, and in rare cases, persist, consult your doctor. could lead to death. www.med-fit.store...
Page 18 Safety Precautions Cautions • If the unit is not functioning properly or if you feel Important Precautions When Applying Stimulation: discomfort, immediately stop using the unit. There are times you should not use the Medi-Boost. • If you experience any issues with your body or skin, Avoid using the Medi-Boost in the following situations, consult your doctor.
Page 19 (50°F - 104°F). Allow it to return to normal • In case of malfunction, disconnect the device from temperature before use if exposed to heat or cold. the power source immediately and contact Med-Fit • Avoid spilling liquids on the device or its accessories. customer service for assistance.
Page 20 Symbols Notation Meaning Batch/lot number Serial No. Manufacturer European authorised representative UK authorised representative Date of manufacture Warning Type BF applied part Medical device Warning on danger Category II medical device It means prohibition (something that must be prohibited) It means compulsory execution (something that must be followed) Indoor use only No sun exposure No rainwater...
Page 21 The Transcutaneous Electrical Nerve Stimulator is suitable for use in all establishments, including domestic establishments and Harmonic emissions IEC those directly connected to the public low-voltage power supply 61000-3-2 network that supplies buildings used for domestic purposes. Voltage fluctuations/ flicker emissions IEC 61000-3-3 www.med-fit.store...
Page 22 Appendix Guidance and manufactures declaration – electromagnetic immunity The Transcutaneous Electrical Nerve Stimulator is intended for use in the electromagnetic environment specified below. The buyer or user of Transcutaneous Electrical Nerve Stimulator should assure that it is used in such an environment. Immunity test IEC 60601 test level Compliance level...
Page 23 P is the maximum output rated power of transmitter provided by its manufacturer, the unit is watt (W). NOTE 1 When under 80MHz and 800MHz, use equation of higher frequency. NOTE 2 These guidelines couldn’t possibly fit all situations. Electromagnetic transmission is affected by buildings, objects, the absorption and reflection of human body. www.med-fit.store...
Page 24 Troubleshooting Problem Possible Causes Solution The On-Off button on the Not placing both bare feet on the Both feet must be on the footplates Medi-Boost has changed to a solid Medi-Boost at the same time. as shown in Step 3 page 8. blue light as described in Step Your feet could be to dry.
Page 25 2. Please store the product in a place far away from direct sunlight, high temperature or humidity. 3. Please store the product in a dry and well-ventilated place. 4. Please never disassemble, repair or modify the product by yourself, otherwise a malfunction or accident may occur. www.med-fit.store...
Page 26 Order Code: RC800 - available in packs of 4, 8 and 12 electrodes To place an order go to www.med-fit.store or call 0161 429 7330. Telephone: 0161 429 7330...
Page 27 USB Charging please AC Adaptor Order Code: MBCL10 Order Code: MBAC20 Electrode Leads Electrode TENS Patient Lead to be used with the body electrodes. Order Code: MBPL30 To place an order go to www.med-fit.store or call 0161 429 7330. www.med-fit.store...
Page 28 NW Business Complex, 1 Beraghmore Road,Derry, BT48 8SE, Northen Ireland. Med-Fit UK Ltd. Unit 8 Martel Court, S. Park Business Park, Hamilton Road, Stockport, SK1 2AF Tel: 0161 429 7330 | Fax: 0161 427 0215 Email: sales@med-fit.co.uk | www.med-fit.store Company registration number 08758741 | Vat registration number 308286105...
