PESA SNM-35 Manual

Routing switcher manager
Hide thumbs

Advertisement

Quick Links

Download this manual
81-9059-0532-0 R
. B
EV
SNM-35 R
PESA S
S
WITCHING
YSTEMS
S
OUTING
WITCHER
, I
.
NC
SNM-35 R
S
OUTING
WITCHER
M
ANAGER
S
O
ERVICE AND
RDERING
PESA Switching Systems, Inc.
330-A Wynn Drive Northwest
Huntsville AL 35805-1961 USA
S
ERVICE
Tel: 256.726.9222 (24/7)
Toll Free: 800.323.7372
Email: service@pesa.com
N
ATIONAL
PESA Switching Systems, Inc.
35 Pinelawn Road, Suite 99-E
Melville NY 11747 USA
Toll-free: 800.328.1008
81-9059-0532-0 A Revision B
M
ANAGER
A
SSISTANCE
www.pesa.com
M
O
AIN
FFICE
Tel: 256.726.9200
Fax: 256.726.9271
D
EPARTMENT
Fax: 256.726.9268
S
O
ALES
FFICE
Tel: 631.845.5020
Fax: 631.845.5023
I

Advertisement

loading
Need help?

Need help?

Do you have a question about the SNM-35 and is the answer not in the manual?

Questions and answers

Summary of Contents for PESA SNM-35

  • Page 1 SNM-35 R OUTING WITCHER ANAGER SNM-35 R OUTING WITCHER ANAGER ERVICE AND RDERING SSISTANCE PESA Switching Systems, Inc. 330-A Wynn Drive Northwest Huntsville AL 35805-1961 USA www.pesa.com FFICE Tel: 256.726.9200 Fax: 256.726.9271 ERVICE EPARTMENT Tel: 256.726.9222 (24/7) Toll Free: 800.323.7372 Fax: 256.726.9268...
  • Page 2 System V, Tiger, Truck Link, UCI2000, VDA 3001, VDA 3002, VDA 3003, VDA 3005, VDA 3006, VDA-3100, VDARS422, Virtual Panel, VP, VPNet, Win3300, Win3500, and Win3500Plus are trademarks of PESA Switching Systems, Inc. in the United States and/or other countries.
  • Page 3 81-9059-0532-0 R SNM-35 R OUTING WITCHER ANAGER FCC Notice This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 4 ANAGER About this manual This manual provides detailed instructions for the installation, operation, and maintenance of the PESA SNM-35 Routing Switcher Manager. The manual is organized so you can quickly find information. This manual is divided into four sections: Chapter 1, Introduction, summarizes the manual and describes the system.
  • Page 5 CHAPTER 3 – OPERATION........................13 The SNM-35 Front Panel......................13 3.1.1 Keypad ..........................13 3.1.2 Rebooting the SNM-35 From the Front Panel............... 13 3.1.3 Display........................... 13 SNM-35 Configuration Menu ......................15 Setting the TCP/IP Addresses...................... 15 Logging ............................15 SNMP Communications ....................... 17 CHAPTER 4 –...
  • Page 6 SNM-35 Connectors ........................9 Figure 10. EXT SW Connector ......................... 10 Figure 11. SNM-421 Routing Switcher Expansion ................... 10 Figure 12. SNM-35 Typical Configuration....................11 Figure 13. SNM-35 Front Panel Controls and Display ................13 Tables Table 1. Ethernet LED Indicators......................6 Table 2.
  • Page 7 The SNM-35 Routing Switcher Manager is a network accessible SNMP gateway used to control and monitor as many as three PESA routing switchers. The SNM-35 provides SNMP source to destination control, lock control, and current input and lock status for each output. It is available in two configurations: one with an optional four section, 2 X 1 high frequency relay switching unit and one without.
  • Page 8 SWITCHER 3 / ALARM SWITCHER 2 / ALARM TMX / ALARM OUT / DIAG ETHERNET Figure 1. SNM-35 Routing Switcher Manager Front and Rear Views 1.2 Specifications DC Power Inputs (Redundant) Input: ...............12 VDC unregulated < 3A @ 12 VDC Power Supply:..........100-240VAC, 50-60Hz, 1.6A...
  • Page 9 • System Connections General If specified when ordered, the SNM-35 RS Manager will be configured for the intended system at the factory. Before attempting to install the RS Manager, read this section carefully. 2.3 Receipt Inspection The SNM-35 RS Manager was tested and inspected prior to leaving the factory. Upon receipt, inspect the equipment for shipping damage.
  • Page 10 ANAGER 2.4 Unpacking The SNM-35 RS Manager is comprised of a frame and two PS130 Power Supplies. Prior to discarding packing material, compare the equipment received against the packing list. Carefully inspect the layers of packing material for any components that may have been overlooked during the initial unpacking.
  • Page 11 2.8 Cabling Considerable weight will be added to the rear panel of the SNM-35 RS Manager by the control, signal, and power cables. Therefore, all cables should be strain-relieved and secured to racks or other supporting structures. Failure to provide adequate cable support can result in cables separating from connectors.
  • Page 12 Error! Not a valid link. Figure 5. SNM-35 Power and Ethernet Connectors 2.9.2 ETHERNET Connector The Ethernet connector (Figure 6) is used to connect the SNM-35 to a 10 or 100Mb/s TCP/IP network. LED indicators are provided as follows: Table 1. Ethernet LED Indicators...
  • Page 13 The SNM-35 has four DB-25M RS-232 communication ports labeled “Switcher 1”, “Switcher 2”, “Switcher 3”, and “TMX/Alarm Out/Diag”. The communication ports uses are as follows: 1. SWITCHER 1: Used to connect to the first PESA routing switcher. The switcher interface cable is supplied with the SNM-35. (Pinout in Figure 7) 2.
  • Page 14 SNM-35. A TTL source would be connected to the colored wire with +5V = “OFF” and 0V = “ON”. The SNM-35 is programmed to respond to both ON and OFF edges of each GPI input.
  • Page 15 Master override control of the SNM-35 relay switcher is available from the front panel of the SNM-35. Regardless of the current state of the switcher, an operator is able to toggle the current input from the front panel of the SNM-35. The front panel operator must select the switcher status display, then hold the LEFT pushbutton for three seconds for the switch to occur.
  • Page 16 “5” represents the switch number (5-8). The default input “A” is normally selected and is also automatically selected whenever system power is not present. Input selection (select A or select B) is controlled by the SNM-35 to which it is connected. A connection cable is provided.
  • Page 17 1. Connect the PESA Routing Switcher(s) to the Serial 1, 2 and 3 connectors (respectively) using a 25-pin RS232 cable. 2. Using a straight through RJ-45 Ethernet cable, connect the SNM-35’s Ethernet jack to a 10/100BASE-T hub or switch on the TCP/IP network.
  • Page 19 The following paragraphs discuss Front Panel operation. 3.1.1 Keypad The SNM-35 has a four-button keypad that is used to display status information and enter password-protected TCP/IP addresses. If you hold down a key for more than one second, it begins to repeat.
  • Page 20 TRAP: 192.168.93.5 Pressing the down key once displays the IP address on the bottom of the display. If the address has been changed but the SNM-35 has not been rebooted, this will show the new, not yet active address. 255.255.255.255 Pressing the down key again displays the serial number and firmware version on the bottom line of the display.
  • Page 21 A log file is limited to 10MB of space with all log files being limited to the storage space available. Two months of log files can be stored on the SNM-35. When a new month is created, the log from two months earlier is deleted.
  • Page 22 81-9059-0532-0 R SNM-35 R OUTING WITCHER ANAGER • GPI Input activity • Front panel relay switcher toggle change requests • Diagnostics • User connect information The following is an example log file: 10/01/2001 12:00:03 AM Diagnostic; Severity: 0; Created Event Log file 200010.LOG, SN:00014C, Ver:95.29.00, IP:19.73.85.53, SM:255.255.254.0,...
  • Page 23 Select new input per output • Change lock status per output Change optional relay switcher state The SNM-35 automatically generates a SNMP trap message when programmed with a valid trap TCP/IP address under the following circumstances: Traps: • SNM-35 boot •...
  • Page 24 SNM-35 power #2 fail • SNM-35 power #1 restore • SNM-35 power #2 restore • GPI input PESA #1 C1PS1 alarm • GPI input PESA #1 C1PS2 alarm • GPI input PESA #1 C2PS1 alarm • GPI input PESA #1 C2PS2 alarm •...
  • Page 25 81-9059-0532-0 R SNM-35 R OUTING WITCHER ANAGER Chapter 4 – Detailed Specifications DC Power Inputs (Redundant) Type: • Coax, pin and sleeve, with threaded collars Input: • 12 VDC unregulated • < 3A @ 12 VDC Power Supply: • 100-240VAC, 50-60Hz, 1.6A •...
  • Page 26 81-9059-0532-0 R SNM-35 R OUTING WITCHER ANAGER Configuration storage Type: • Internal non-volatile memory • Data integrity verified • Redundant data placement Elements: • IP address • Subnet mask • Gateway • Trap address • Site Information, timezone, DST •...
  • Page 27 81-9059-0532-0 R SNM-35 R OUTING WITCHER ANAGER Front panel access User interface: • Up, down, left, right-arrow pushbuttons Standard functions: • Rotate through status screens • Force optional relay switch toggle (a switch delay confirms action) Configuration Access protection: •...
  • Page 28 WITCHER ANAGER 4.10 Integrated logging Interface: • ASCII text file stored on SNM-35 flash drive, readable by popular spreadsheet programs File name: • YYYYMM.log • New file created at 12:00 AM the first day of each month File size limit: •...
  • Page 29 Telnet (set clock, configuration) • SNMP V1 Maximum simultaneous telnet and FTP connections: • Four 4.13 Mechanical SNM-35 chassis dimensions: • 1.70” H X 19.0” W X 11.0”D Weight, unit without carton or cables: • 7 lbs. 4.14 TMX Alarm Inputs •...
  • Page 30 • RS-232 DTE COM functions: • SWITCHER 1: Used to connect to the first PESA routing switcher. The switcher interface cable is supplied with the SNM-35. • SWITCHER 2: Used to connect to the second PESA routing switcher. The switcher interface cable is available as an option for the SNM-35.
  • Page 31 81-9059-0532-0 R SNM-35 R OUTING WITCHER ANAGER 4.17 Optional Relay Switching Configuration: • Four, 2 X 1 switches Input connection: • Female BNC, labeled “A” (default) and “B” (actuated) Output connection: • Female BNC, labeled “C” Switch control: • All four switches in parallel •...
  • Page 32 81-9059-0532-0 R SNM-35 R OUTING WITCHER ANAGER Switch Life: • actuation cycles Operating Voltage: • 5V, 12V, and 24V standard Switch Power Consumption: • 400 mW, failsafe; 2 mW latching driver Temperature: • -20° to +60°C Control Options: • CMOS (non-latching) •...
  • Page 33 This equipment contains static sensitive devices. It is recommended that a grounded wrist strap and mat be used while making repairs or adjustments. General There are no adjustments on the SNM-35 Routing Switcher Manager and the need for regular maintenance is minimal. Preventive Maintenance Use the following guidelines for general preventive maintenance: •...
  • Page 34 The SNM-35 Routing Switcher Manager may be returned to the factory (transportation prepaid) for repair. Refer to the Service Information page in the front of this manual. Call the PESA Service Department (the phone number is listed on the front of this manual) for a RMA number before shipping an equipment item.
