Summary of Contents for Würth 2609051183000
Page 1
SER MANUAL VALUATION IT FOR RADIO MODULE ETIS 2609051183000 ERSION 27, 2024 EPTEMBER...
Page 2
*************** MUST READ Check for firmware updates Before using the product, make sure you use the most recent firmware version, data sheet, and user manual. This is especially important for Wireless Connectivity products that were not purchased directly from Würth Elektronik eiSos. A firmware update on these respective products may be required.
Page 3
WIRELESS CONNECTIVITY & SENSORS Evaluation board user manual Revision history Manual Notes Date version version September 2024 Initial version The table shows hardware version of the EV board. For the actual version of the module refer to [1]. Metis-e Version 1.0, September 2024 www.we-online.com/wcs...
Page 4
WIRELESS CONNECTIVITY & SENSORS Evaluation board user manual Abbreviations Abbreviation Name Description COM Port Communication Port EV (Board) Evaluation (Board) Electro Static Discharge Future Technology FTDI USB to serial converter chip. Devices International Ground General Purpose GPIO Input/Output HIGH High signal level JTAG Joint Test Action Group Flash und debug interface.
Page 5
WIRELESS CONNECTIVITY & SENSORS Evaluation board user manual Contents 1 Supported radio modules 2 Functional description Taking into operation ....... . . 3 Development board Block diagram .
Page 6
1 Supported radio modules The evaluation board described in this manual can be used to evaluate the following product: WE order code Description 2609051183000 Metis-e radio module Table 1: Compatibility The EV-Kit can be ordered using the following order code:...
Page 7
WIRELESS CONNECTIVITY & SENSORS Evaluation board user manual Figure 1: EV kit containing evaluation board, 868 MHz antenna and a USB data cable Metis-e Version 1.0, September 2024 www.we-online.com/wcs...
Page 8
WIRELESS CONNECTIVITY & SENSORS Evaluation board user manual 2 Functional description The evaluation board offers the user the possibility to develop hard- and software for the mounted radio module. It can be connected to a USB port of a PC. For the connection to a microcontroller system, the development board is equipped with a multi- pin connector, which is connected to all pins of the radio module.
Page 9
WIRELESS CONNECTIVITY & SENSORS Evaluation board user manual 3 Development board 3.1 Block diagram Evaluation board External Pin header power supply RF Filter & 50 Ω SMA antenna matching connector 50 Ω Voltage Radio module regulator FTDI USB converter chip Connectors Buttons LEDs...
Page 10
WIRELESS CONNECTIVITY & SENSORS Evaluation board user manual 3.2 Jumpers Figure 3: Jumpers, default placement Metis-e Version 1.0, September 2024 www.we-online.com/wcs...
Page 11
WIRELESS CONNECTIVITY & SENSORS Evaluation board user manual Jumper set Pin (Module Function) (default) 1, 2 /RESET to CBUS0-FTDI 3, 4 Current consumption measurement bridge 5, 6 DIO_0 to pull down to change boot mode DIO_7 to pull up for change operating 7, 8 mode 9, 10...
Page 12
WIRELESS CONNECTIVITY & SENSORS Evaluation board user manual 3.3 Connectors and pin headers Figure 4: Connectors Metis-e Version 1.0, September 2024 www.we-online.com/wcs...
Page 13
WIRELESS CONNECTIVITY & SENSORS Evaluation board user manual Connector Function CON1 Micro-USB connector for host connection and VDD bus supply CON2 SMA connector for external antenna CON3 2×10 JTAG/SWD connector CON4 External power supply VDD (not mounted) CON5 External power supply GND (not mounted) Table 6: Connector overview When using external power supply Jumper JP2 Pin 1-2 shall be removed to avoid applying voltage to the output of the LDO.
Page 14
WIRELESS CONNECTIVITY & SENSORS Evaluation board user manual 3.3.2 CON2 Connector CON2 (SMA connector) is used to connect an external antenna. For example, the 868 MHz antenna Hermippe-III 2600130086 can be used. CON2 Function Inner RF signal Outer The EV board allows the possibility to either connect directly to an antenna, or to go through a SAW filter.
Page 15
WIRELESS CONNECTIVITY & SENSORS Evaluation board user manual To facilitate testing with additional filtering, a SAW filter is already assembled. Some soldering is needed to remove C6 and place C19 and C20 as shown in figure 6 . Figure 6: Example with filtering Metis-e Version 1.0, September 2024 www.we-online.com/wcs...
Page 16
WIRELESS CONNECTIVITY & SENSORS Evaluation board user manual 3.3.3 CON3 Connector CON3 is the JTAG debugging interface. CON3 CC1310 Function JTAG_TMS Test2 JTAG_TCK Test1 RESET_N /RESET 4,6,8,10,12,14,16,18,20 Not connected 2,3,5,11,13,17,19 Table 7: Connector CON3 3.3.4 CON4 Pin header CON4 is a 3x1 pin header with 2.54 mm grid connected to MOD_VDD in the PCB. CON4 shall be used for external power supply.
Page 17
WIRELESS CONNECTIVITY & SENSORS Evaluation board user manual 3.4 Buttons Figure 7: Buttons Metis-e Version 1.0, September 2024 www.we-online.com/wcs...
Page 18
WIRELESS CONNECTIVITY & SENSORS Evaluation board user manual 3.4.1 RESET button Internally, the active low reset input of the microprocessor is connected via a RC combination with the power supply to ensure a proper startup of the module. The module provides this /RESET pin.
Page 19
WIRELESS CONNECTIVITY & SENSORS Evaluation board user manual pulled up while inactive and during module boot-up). The host must adhere to the I/O level compatibility values stated in the module’s manual. 3.5.5 LFXO crystal The standard Metis-e firmware does not use an external low-frequency crystal. Nevertheless, it is possible to mount one on the EV board.
Page 20
WIRELESS CONNECTIVITY & SENSORS Evaluation board user manual 3.6 Schematic Figure 9: Reference design: Schematic Metis-e Version 1.0, September 2024 www.we-online.com/wcs...
Page 21
WIRELESS CONNECTIVITY & SENSORS Evaluation board user manual 3.7 Layout Figure 10: From left to right and from up to down : Top layer, bottom layer, 2nd Layer, 3rd Layer Metis-e Version 1.0, September 2024 www.we-online.com/wcs...
Page 22
WIRELESS CONNECTIVITY & SENSORS Evaluation board user manual Figure 11: Assembly diagram Metis-e Version 1.0, September 2024 www.we-online.com/wcs...
Page 23
WIRELESS CONNECTIVITY & SENSORS Evaluation board user manual 3.8 Bill of materials Part Value PACK MANUFACTURER 100nF 0402 885012205037 Würth Elektronik 100nF 0402 885012205037 Würth Elektronik 10 F 0402 885012105020 Würth Elektronik 47 F 0402 885012105008 Würth Elektronik 0402 885012105012 Würth Elektronik 68pF 0402...
Page 24
7427927311 Würth Elektronik LED1 yellow 0805 150080YS75000 Würth Elektronik LED2 blue 0805 150080BS75000 Würth Elektronik LED3 0805 150080RS75000 Würth Elektronik MOD1 2609051183000 2609051181000 Würth Elektronik n.m. Würth Elektronik Table 9: Bill of materials cont. Metis-e Version 1.0, September 2024 www.we-online.com/wcs...
Page 25
WIRELESS CONNECTIVITY & SENSORS Evaluation board user manual 4 Marking 4.1 Lot number The 15 digit lot number is printed in numerical digits as well as in form of a machine readable bar code. It is divided into 5 blocks as shown in the following picture and can be translated according to the following table.
Page 26
WIRELESS CONNECTIVITY & SENSORS Evaluation board user manual 5 Regulatory compliance information 5.1 European Conformity Pursuant to Article 1 (2.) of the EU directive 2014/53/EU, Article 1 (2.) the directive does not apply to equipment listed in Annex I (4.): custom-built evaluation kits designed for professionals to be used solely at research and development facilities for such purposes.
Page 27
WIRELESS CONNECTIVITY & SENSORS Evaluation board user manual 6 References [1] Würth Elektronik. Metis-e user manual. https://www.we-online.de/katalog/de/manual/ 2609051183000 . https://www. [2] Würth Elektronik. WE UART Terminal PC tool (Smart Commander). we-online.com/SmartCommander . Metis-e Version 1.0, September 2024 www.we-online.com/wcs...
Page 28
WIRELESS CONNECTIVITY & SENSORS Evaluation board user manual 7 Important notes The following conditions apply to all goods within the wireless connectivity and sensors product range of Würth Elektronik eiSos GmbH & Co. KG: General customer responsibility Some goods within the product range of Würth Elektronik eiSos GmbH & Co. KG contain statements regarding general suitability for certain application areas.
Page 29
WIRELESS CONNECTIVITY & SENSORS Evaluation board user manual provided information related to their accuracy, correctness, completeness, usage of the products and/or usability for customer applications. Information published by Würth Elektronik eiSos GmbH & Co. KG regarding third-party products or services does not constitute a license to use such products or services or a warranty or endorsement thereof.
Page 30
WIRELESS CONNECTIVITY & SENSORS Evaluation board user manual The incorporated firmware created by Würth Elektronik eiSos is and will remain the exclusive property of Würth Elektronik eiSos. Firmware update(s) You have the opportunity to request the current and actual firmware for a bought wireless connectivity product within the time of warranty. However, Würth Elektronik eiSos has no obligation to update a modules firmware in their production facilities, but can offer this as a service on request.
Page 31
WIRELESS CONNECTIVITY & SENSORS Evaluation board user manual List of Figures EV kit containing evaluation board, 868 MHz antenna and a USB data cable . . . Block diagram ........Jumpers, default placement .
