Eagle Eye 12v Solar Kit Manual

12v Solar Kit
* Always follow all safety rules
when operating power tools and
when working at heights.
Do not perform the assembly
and installation process without
the necessary safety qualifications.
3
Push the wire from the solar panel
through the pipe and insert the
pipe into the mounting bracket.
Leave approximately 1ft of wire
outside the top of the pipe to be
connected to the Eagle Eye unit.
1
Measure the length of wire needed
and push it through the opening
in the mounting bracket.
The wire is already connected to
the solar panel.
Keep the wire as short as possible
for best performance.
4
Strip the wire and place the red
connector on the wire with the
black line (+).
Place the blue connector on
the unmarked wire (-) and secure
the connectors in place with a
crimping tool.
2
Use the straight pipe to install
the Eagle Eye unit on a
horizontal surface or the bent
pipe for an installation against
a vertical surface.
5
Insert the red connector into the
red plug and the blue
connector into the blue plug
on the Eagle Eye unit.
