AZIMUT DVSUK2 Manual

Sensor functionality statement kit dvs-pss 2024

Advertisement

Quick Links

SENSOR
FUNCTIONALITY
STATEMENT
KIT DVS-PSS 2024

Advertisement

loading
Need help?

Need help?

Do you have a question about the DVSUK2 and is the answer not in the manual?

Questions and answers

Summary of Contents for AZIMUT DVSUK2

  • Page 1 SENSOR FUNCTIONALITY STATEMENT KIT DVS-PSS 2024...
  • Page 2 Content ......................1. Introduction ....................2. Product introduction ....................2.1.Product brief introduction .......................... 2.2.Parts list ................3. Product func3on introduction ....................1. func4on introduction ..................2. Product working logic diagram ................ 1. DM70MR Display func4on description ............2. Failure mode list and Troubleshooting method ..........................
  • Page 3 1. INTRODUCTION Thank you for purchasing a Blind Spot Information and Moving Off Information System with integrated Camera Monitoring System. In order to ensure the correct installation and use of the device, please read the installation instructions and other important information. Disclaimer The content of this manual will be updated from time to time without prior notice;...
  • Page 4 Our DVSUK2 Kit is a perfect entry level solution for the operator who wishes to meet the standards of the Progressive Safe System.
  • Page 5 2.2.Parts list DM70MR 3- channel display CS50RA-180 Front Camera...
  • Page 6 CS5ORA-180 Side Camera AP103A GPS receiver AP120 visual LED light...
  • Page 7 3. PRODUCT FUNCTION INTRODUCTION 1. func3on introduction The Blind Spot Information System (BSIS provides blind spot information and active detection and identification around the vehicle (side. Traffic accidents due to vehicle size and dead line of sight. Blind Spot Information System (BSIS is a set of camera AI algorithm to provide drivers with auxiliary information when driving BSIS effectively eliminates vehicle blind spots and reduces accidents due to blind eye angles on the side of vehicles.
  • Page 8 DM70MR AP120 Audio Warning Regulation Warning Type (Monitor) (LED light) (DM70MR Output) Detec4on area yellow Steady on red BSIS translucent base map below (SIDE) 2.1.2. Vehicle Dynamic (V=0Km/h & No Brake Signal) or (1Km/h≤V≤35Km/h).
  • Page 9 DM70MR AP120 Audio Warning Regulation Warning Type (Monitor) (LED light) (DM70MR Output) Detec4on area yellow Steady on red BSIS translucent base map below (SIDE) DM70MR AP120 Audio Warning Regulation Warning Type (Monitor) (LED light) (DM70MR Output) Detec4on area red Flashing red Cau4on.
  • Page 10 2.1.3. Vehicle Dynamic (0Km/h≤V≤35Km/h) & (No Brake Signal) & (Turning signal is on). DM70MR AP120 Audio Warning Regulation Warning Type (Monitor) (LED light) (DM70MR Output) Detec4on area red Flashing red Cau4on. Side BSIS translucent base map below (SIDE) Pedestrian. 2.1.4. Vehicle Dynamic V>35Km/h, Detection Off.
  • Page 11 2.2. DVS/PSS MOIS Detect 2.2.1. Vehicle Sta4c V=0Km/h & Brake Signal. DM70MR AP120 Audio Warning Regulation Warning Type (Monitor) (LED light) (DM70MR Output) Detec4on area Steady on red yellow MOIS above translucent base map (FRONT) 2.2.2. Vehicle Dynamic (V=0Km/h & No Brake Signal) or (1Km/h≤V≤10Km/h).
  • Page 12 DM70MR AP120 Audio Warning Regulation Warning Type (Monitor) (LED light) (DM70MR Output) Detec4on area red Flashing red Cau4on. Front MOIS translucent base map above Pedestrian. (FRONT) 2.2.3. Vehicle Dynamic V>10Km/h, Detection Off.
  • Page 13 2.3. DVS/PSS BSIS & MOIS Detect 2.3.1. BSIS & MOIS IS DM70MR AP120 Audio Warning Regulation Warning Type (Monitor) (LED light) (DM70MR Output) BSIS + MOIS BSIS & MOIS Steady on red Detection (SIDE & FRONT) area yellow translucent base map...
  • Page 14 2.3.2. BSIS WS & MOIS IS DM70MR AP120 Audio Warning Regulation Warning Type (Monitor) (LED light) (DM70MR Output) Detec4on area Steady on red MOIS yellow above translucent base map (FRONT) Detec4on area red Flashing red Cau4on. Side BSIS translucent base map below (SIDE) Pedestrian.
  • Page 15 2.3.3. BSIS IS & MOIS WS DM70MR AP120 Audio Warning Regulation Warning Type (Monitor) (LED light) (DM70MR Output) Detec4on area red Flashing red Cau4on. Front MOIS translucent base map above Pedestrian. (FRONT) Detec4on area Steady on red BSIS yellow translucent below (SIDE) base map...
  • Page 16 2.3.4. BSIS & MOIS WS DM70MR AP120 Audio Warning Warning Type Regulation (Monitor) (LED light) (DM70MR Output) BSIS & MOIS Flashing red BSIS Cau4on. Front Detec4on area red (SIDE & and Side translucent base map FRONT) Pedestrian.
  • Page 17 3. DM70MR DISPLAY FUNCTION DESCRIPTION 3.1. Basic func4on : Support 3-channel camera input, CH1 as the PSS side camera, CH2 as the PSS front camera, CH3 as ● the rear camera, they all support pedestrian detec4on and alarm func4ons. 3-channel video recording func4on is supported, aHer inser4ng an empty TF card and formabng it ●...
  • Page 18 4. Failure mode list and Troubleshoo3ng method No camera signal - Front/Rear ● Troubleshooting method: Check the camera connection. Insufficient illumina4on, detec4on OFF - Front/Rear ● Troubleshooting mode: None: This alarm is triggered when the scene brightness is too low. Low image quality, detec4on OFF - Front/Rear ●...
  • Page 19 4. COMMON PROBLEMS AND TEST MAINTENANCE GUIDE 4.1.APer startup, the system automa3cally checks. The display send failure message when the system fails. ▪ Check all parts of the system, whether the connec4on is normal or dirty 4.2.Power failure ▪ Check the power supply voltage. The standard opera4ng voltage is 24V ▪...
  • Page 20 5. PRODUCT CLEANING AND MAINTENANCE Regular cleaning can ensure that the camera lens maintain the best performance, the use of high-quality and safe cleaning agents and soft cloth, can effectively remove stains and debris on the lens. When the camera is automatically heated, it can effectively vaporize the surface of fog and frost and snow.
