Summary of Contents for Fox ESS A7300
- Page 1 7.3KW EV Charger Please read the product manual prior to installation to prevent improper operation...
- Page 2 Table of Contents 1. Notes on This Manual ....................1 1.1 Scope of Validity ....................1 1.2 Target Group .....................1 1.3 Symbols Used ....................1 2. Safety ......................... 2 3. Packing List ........................3 4. Introduction ........................ 4 5. Technical Data ......................5 6.
- Page 3 1. Notes on This Manual 1.1 Scope of Validity This manual describes the assembly, installation, commissioning, maintenance and troubleshooting of the following model(s) of Fox products: A7300P1-E-1 A7300S1-E-1 A7300P1-E-2 A7300S1-E-2 Note: Please keep this manual where it will be accessible at all times. 1.2 Target Group This manual is for qualified electricians.
- Page 4 Symbols Explanation Symbol Explanation CE mark. The charger complies with the requirements of the applicable CE guidelines. Beware of hot surface. The charger can become hot during operation. Avoid contact during operation. Danger of high voltages. Danger to life due to high voltages in the charger! Danger.
- Page 5 3. Packing List...
- Page 6 4. Introduction ①Meaning of lights •Green breathing light - standby status •Blue Steady - EV Plug inserted status •Blue breathing light - charging start status/pause •Blue running light - charging status •Green Steady - charging end status •Red Steady - Charger fault, shutdown protection •Yellow Steady - locked status ②EV Plug holder ③RS485 Communication wire...
- Page 7 5.Technical Data Model A7300 General Name AC Charger Input Input line 3P+N+PE Rated voltage 230Vac，±20% Rated current 50/60Hz Rated frequency Output Output voltage 230Vac，±20% Maximum output current Rated power 7.3kW Interaction method Charging connection method With cable/socket Card reader Mifare ISO/IEC 14443 A Start-up mode Plug&Play/RFID Card/APP...
- Page 8 6.Installation Product Handling To ensure safety, the following points should be paid attention to: All accessories are placed separately during transport or handling. Avoid violent shock and impact, and take it lightly. Avoid inversion. 6.2 Out of the box inspection Open the charging pile packaging, please check the random attachment according to the attachment list.
- Page 9 • Wall-mounted installation method: 1.Mark 4 holes according to the installation positioning card on the wall. 2.Use an 8mm drill bit to drill holes (with a hole depth of over 50mm). 3.Clean the hole position. Insert the expansion pipe (E) into the hole and fix it tightly with a rubber hammer.
- Page 10 Fix the Mounting bracket (C) onto the EV Charger with screws (J). 1.Hang the EV Charger into the Mounting backplate. 2.Tighten the screws (I) to complete the installation.
- Page 11 • Floor type / Vertical installation method: 1.Use a 12mm drill bit to drill four 60mm deep holes with a spacing of 170*120mm. 2.Drill one 60mm outlet hole in the center. 3.Clean the hole position. Install the foot screw and fix with a wrench. Router the input wire into the column hole through the ottom of the column.
- Page 12 Fix the Mounting backplate (B) to the column with screws. Fix the bracket (C) onto the EV Charger with screws (J). 1.Hang the EV Charger into the Mounting backplate. 2.Tighten the screws (I) to complete the installation.
- Page 13 Electrical Connection • A leakage protection switch needs to be installed. The leakage protection switch should use Type A, not less than 32A, and the input wire should be led out from the leakage protection switch. It is recommended to use wire diameter 6-10mm² cable. Trim all cables to 50mm (as shown in the figure) and peel off the insulation sheath to expose the conductor by about 10mm.
- Page 14 Unscrew the gland nut and puncture the wire-through hole. Open the side cover and install the cable (wire diameter φ16-22.5mm). Install the cable into the terminal block and fix it,and tighten the gland nut. Lock the side cover and complete the installation.
- Page 15 Communication wiring • Trim all cables (wire diameter 0.3mm²) to 15mm (as shown in the figure), peel off the insulation sheath to expose the conductor by about 8mm. 485A: Brown/red/green or yellow wire 485B: Blue/black wire Note: Please refer to the local cable model and color during actual installation Use crimping pliers to crimp the tubular terminal (H) and cable.
- Page 16 Install the cable into the signal terminal, tighten the screw and compress the tubular terminal. Fix the male and female ends of the signal terminal by connecting them. Lock the side cover and complete the installation.
- Page 17 7.APP download Users can scan the QR code (Android and IOS ) in the quick installation manual, or go to the App Store and Google Play to search for Elite Charger.
- Page 18 8.Operation 8.1. Charger Status Indicators LED Indicator description Definition Green Flashing Device available Blue Steady EV connected，User not authorized Blue Flashing Authorized, Wait for charging Blue marquee light Charging Blue Flashing Charging suspension Green Steady Charging Finish, Wait for unplug Yellow Steady Charging Locking Red Steady...
- Page 19 8.2. Charging mode and Operation Users can set three charging modes through the charging mode setting interface of the APP: controlled, locked, plug and charge. Plug and charge mode Charging will start automatically after EV plugged in. If you want to stop the charging, just press the stop button on the side of the charger.
- Page 20 5. Charging session started Stop Charging: • 1. Swipe card 2. Charging session end The controlled mode with APP Start Charging: • 1. Set the charger to the Controlled mode 2. Insert the charging plug into the EV 3. Click to Start the Charge on the APP 4.
- Page 21 9.Maintenance Troubleshoot by Alarm information on APP or LCD display If fault occurs, users can check the fault information on the APP or by blinks of the LED indicator light. Fault code on app Solution Set the electronic lock status to the correct position.
- Page 22 10.Decommissioning 10.1 Dismantling the charger Disconnect the charger from AC Input and AC output. Disconnect communication and optional connection wirings. Remove the charger from the bracket. Remove the bracket if necessary. 10.2 Packaging If possible, please pack the charger with the original packaging. If it is no longer available, you can also use an equivalent box that meets the following requirements.
- Page 23 The copyright of this manual belongs to FOXESS CO., LTD. Any corporation or individual should not plagiarize, partially or fully copy (including software, etc.), and no reproduction or distribution of it in any form or by any means is permitted. All rights reserved. FOXESS CO., LTD.
