- Page 1 English HONBDA-BTTY- 100-NG Battery Backup Unit User Manual UM-0355 / Rv.04...
- Page 2 Document History Description Revision Date Issued Original version May 09th, 2024...
- Page 3 About this manual This manual describes installation, commissioning, operation, and maintenance of the Fiplex by Honeywell Battery Backup Unit (BBU). The first part of the manual describes the BBU hardware, and the second part describes the software. Hardware and software mentioned in this manual are subjected to continuous development and improvement.
- Page 4 Abbreviations Automatic Gain Control Base Station, BS antenna = towards the base station Direct Current Downlink signal direction (from base station via Signal Booster / Master / Remote to mobile station) DPLX Duplex filter EEPROM Electrical Erasable Programmable Read Only Memory ETSI European Telecommunications Standard Institute Fiplex Control Software...
- Page 5 This manual lists a set of rules and warnings to be followed when installing, commissioning and operating a Battery Backup Unit from Fiplex by Honeywell. Any omission may result in damage and/ or injuries to the System and/or the System Operators or Users.
- Page 6 Failure to comply with these precautions or specific warnings elsewhere in the guide violates the safety standards of design, manufacture, and intended use of equipment. Fiplex by Honeywell assumes no liability for the customer's or user's failure to comply with these requirements: •...
- Page 7 Product Description The Battery Backup Unit or BBU Series are easy to install and operate devices. Designed to work via an easy/quick connector to the Signal Boosters Series that can provide 24hrs of battery. The model designator for the Battery Backup Unit is HONBDA-BTTY-100-NG. Please refer to the datasheet on www.Fiplex.com for further details.
- Page 8 Mechanical specifications Product Parts Figure: Product Parts...
- Page 9 Parameter Specifications Notes Size 20 x 24 x 11.21 in 508 x 609.6 x 284 mm Internal connection by user. Refer Connectors AC Power in to Wiring Diagram section. Dedicated two pole circular DC (Battery) Power In connector Frame Ground Lug Ground USB Cable Local Management...
- Page 10 Product Dimensions Figure: Dimensions...
- Page 11 Clearance Figure: Clearance...
- Page 12 Installation Fiplex by Honeywell BBU series is designed for indoor/outdoor usage with a weatherproof outdoor NEMA 4 cabinet that can be mounted without any kind of shelter from rain, snow or hail. To improve reliability, it is recommended to mount the BBU on a site with shelter from direct exposure to sun, rain, snow and hailing.
- Page 14 Max. Screw Diameter 3/8” / Recommended Length: 3” Recommended fasteners: Steel Stud Anchor for Concrete, 3/8” Diameter, 3” Long. QTY.4 Stainless Steel Serrated Flange Locknut, 3/8”. QTY.4...
- Page 15 Important Installation Guidelines The following guidelines should be carefully observed for all installations of HONBDA-BTTY series of BBU. • The unit shall be installed by QUALIFIED SERVICE PERSONNEL only. • The BBU shall be installed in a restricted access location. •...
- Page 16 Commissioning- wiring AC/Alarms external cables DC to Signal Booster RJ45 to Signal Booster AC Main (Provided by user – Refer to Wiring diagram) Figure: Port Connection WARNING: To maintain the NEMA 4 rating the unused cord grips and conduit connectors must be properly sealed. Power Specifications Nominal Main Power Input Voltage: 120 VAC, 6A, 60Hz.
- Page 17 Power Wiring Diagram AC Main Power Connect GROUND (G), NEUTRAL (N) and LINE (L) as indicated in this image. Image: AC power supply cable MAIN AC SUPPLY CIRCUIT: 120VAC, 6A, 60Hz...
- Page 18 EPO switch Step 1: To connect the EPO switch, you need to disconnect the cable installed in the last two terminals of the main connection terminal blocks on the device Step 2: install the EPO switch connecting the button in the terminals...
- Page 19 Battery Installation Place the batteries inside the cabinet as shown in the following images Figure: Battery placement inside the BBU enclosure.
- Page 20 connect the batteries as shown in the following image. Use the provided protection cups on the batteries and install the temperature sensor as shown in the next step.
- Page 21 Temperature sensor installation The temperature sensor must be installed in all the back up batteries as the following instructions: • HONBA-BTTY-100-NG Step 1: Connect the cable to the terminal in the PCB and the battery:...
- Page 22 Step 2: Connect the cable in the plate of the battery’s terminals: Note: Washer, Screw and plate are in the accessories bag Installation Warning Failure to install the temperature sensor per manual guidelines will void your product warranty. Follow instructions to ensure optimal performance.
- Page 23 Buzzer muting To mute the buzzer the user must open the enclosure door and press the below indicated button. Figure: MUTE button. Figure: MUTE button location inside the BBU cabinet. Test button The MUTE button can also be used as a Test Button for all the LEDs. To activate the test the user has to press the MUTE button for longer than 10s.
- Page 24 Annunciator LED panel There is an LED annunciator panel located on the front door of the BBU. This LED panel works as a status monitor indicating alarms. This panel can be changed depending on the standard used in the installation, there is 4 types of frontal label: 1) NFPA 1221 standard label 2) NFPA 1221 standard label with Oscillation Alarm 3) NFPA 1225 standard label...
- Page 25 2) NFPA 1221 LED panel has ten LEDs: Colour code: Alarm Not OK AC Power Normal Green AC Fail – Battery Active Battery Capacity < 30% Battery Charger Fail Donor Antenna Disconnect Donor Antenna Malfunction RF Emitter Fail System Component Fail Oscillation RF Emitting Device Extra configurable Alarm...
- Page 26 3) NFPA 1225 LED panel has ten LEDs: Colour code: Alarm Not OK AC Power Normal Green AC Fail – Battery Active Battery Capacity < 30% Battery Charger Fail Signal Source Malfunction RF Emitter Fail System Component Fail Extra configurable Alarm Extra configurable Alarm Extra configurable Alarm...
- Page 27 4) Fully Customizable Alarm Colour code: Alarm Not OK AC Power Normal Green AC Fail – Battery Active Extra configurable Alarm Extra configurable Alarm Extra configurable Alarm Extra configurable Alarm Extra configurable Alarm Extra configurable Alarm Extra configurable Alarm Extra configurable Alarm...
- Page 28 Fire monitor module Installation Step 1: Install the 47k Ohm resistors in the monitor module in the terminal blocks T4 and T2: Note: Cut the terminals from the resistors to install them. Step 2: Install the cables with 47k Ohm resistors, they must be connected in a specific order with the resistor in the monitor module.
- Page 29 Step 3: With all the cables and the resistors installed in the monitor module PCB with 2 screws: Note: Screws must be 4-40 Phillip head...
- Page 30 Step 4: Connect the monitor module with the FIP519 PCB in the HONBDA-BTTY-100: Is recommended to use the resistors in the PCB in all cases Dangerous Voltage Warning Any personnel involved in installation, operation or service of Battery Backup Unit must understand and obey the following: The power supply unit contains dangerous voltage level, which can cause electric shock.
- Page 31 Ventilation Kit The ventilation kit consists of components that allow air to flow and maintain the temperature inside the cabinet. This system must not be blocked, and the seals cannot be changed or uninstalled for other purposes.
- Page 32 Wiring BDA/Master Connection To connect the BDA/Master to the BBU with the following terminal, remember dry contacts are not needed anymore: RJ45 connector Cable Required Use the General-purpose cord-grip to install the Cat5/6 cable with the RJ45 connector to the BDA/master unit, remember that the Dry contact cable and connector is not need anymore.
- Page 33 Software Introduction From factory, this BBU is configured to operate under the UL2524 standard. If the user needs to change a Relay Output, LED or Buzzer assignment the software Fiplex control software (FCS) must be used. The FCS is a PC software that connects to the BBU. It can be downloaded at www.Fiplex.com Communication Connection RJ45 Cable Required...
- Page 34 USB Software FCS (Fiplex control Software) General Tab-sheet Run the FCS and click on status to see all BBU Alarms and the General Alarms, also from this view is accessible to the BDA/Master/Remote Alarms. This tab-sheet contains the Serial Number, firmware information and the Digital Output summary.
- Page 35 Alarm Tab-sheet The alarm Tab-sheet contains more detailed information about the status of the Alarm configuration. In this Tab-Sheet the user can disable alarms, detach the Buzzer form alarms or detach alarms from the LED Panel. The user can also configure: The Mute Time of the Buzzer.
