THANK
USER MANUAL
YOU!
NOTE:
To continuously improve its products,
reserves the right to
modify this information without prior notification.
For any questions regarding assembly, please watch the video on the
product page or contact our customer service. Our customer service will
Thank you for using
products in your home!
Thank You for Purchasing from
Foldable Multi-burner
Made in China
Propane Griddle
Advertisement
Summary of Contents for VIVOHOME VH1630
- Page 1 THANK USER MANUAL YOU! NOTE: To continuously improve its products, reserves the right to modify this information without prior notification. For any questions regarding assembly, please watch the video on the product page or contact our customer service. Our customer service will Thank you for using products in your home! Thank You for Purchasing from...
- Page 2 USER MANUAL HOW-TO Foldable Multi-burner Propane Griddle CONTENTS Important Safeguards ..........3 Expanded View & Hardware ........8 Assembly Instructions ..........12 Transporting & Storage Instructions ....18 Installing LP Gas Tank ..........29 Operating Instructions ..........31 Cleaning and Care ............36 Troubleshooting ............42 Warranty ................47 IMPORTANT: After each use, always season your griddle per "Seasoning Griddle"...
- Page 3 The use and installation must conform with local codes or, in the Warning absence of local codes, with either the National Fuel Gas Code, ANSI Z223.1/NFPA 54, Natural Gas and Propane Installation Code, For your safety: CSA B149.1, or Propane Storage and Handling Code, B149.2. Improper installation, adjustment, alteration, service or main- tenance can cause injury or property damage.
- Page 4 SECTION A Important Safeguards LP gas cylinder needed to operate. Only cylinders marked "propane" may be used. The LP gas cylinder must be constructed and marked in accordance with the Specifications for LP-gas Cylinders of the U.S. Department of Transportation (D.0.T.) or the National Standard of Canada, CAN/CSA-B339, Cylinders, Spheres, and Danger Tubes for the Transportation of Dangerous Goods;...
- Page 5 Never fill the cylinder beyond 80 percent full. Minimum clearance from sides and back of unit to combusti- If the information above is not followed exactly,a fire causing ble construction is 36 inches (91.4 cm). Do NOT use this appli- death or serious injury could occur.
- Page 6 Do NOT place empty cooking vessels on the appliance while After a period of storage and/or nonuse, check for leaks and burner obstructions and inspect for any abrasion, wear, or in operation. Use caution when placing anything on the griddle while the cuts to the hose.
- Page 7 Expanded View...
- Page 8 SECTION C Assembly Instructions Parts List Griddle Surface *1 14 Control Knob *4 Griddle Body *1 15 Reguloter *1 Assembly Tips Select an area where you will assemble this product. To Fireproof Board *1 16 Left Cart Frame *1 protect components, choose a smooth surface that's free of cracks or openings.
- Page 9 SECTION C SECTION C Assembly Instructions Assembly Instructions STEP 1 STEP 2 Install Wheel Using "B"pin Open Legs Caution Two (2) people will be required to lay griddles on the back. Note Open Right Legs First. 23/24...
- Page 10 SECTION C SECTION C Assembly Instructions Assembly Instructions STEP 3 STEP 4 Attach Bottom Shelf. Attach Side Handles and Insert Control Knobs. Caution Two (2) people will be required to stand griddle upright.
- Page 11 SECTION C SECTION D Assembly Instructions Transporting & Storage Instructions Warning STEP 5 Before transporting or storing this griddle: Install the left and right side shelves, then place the grill pan, and Always season the griddle per "Seasoning Griddle" section. use M6*12 screws to secure the hooks.
- Page 12 SECTION D SECTION D Transporting & Storage Transporting & Storage Instructions Instructions STEP 1 STEP 2 Remove Griddle Surface. Remove Bottom Shelf. Caution Two (2) people will be required to lay griddles on their backs.
- Page 13 SECTION D SECTION D Transporting & Storage Transporting & Storage Instructions Instructions STEP 3 STEP 4 Close Legs Unscrew the Right Leg. Note Close Left Leg First.
- Page 14 SECTION D SECTION D Transporting & Storage Transporting & Storage Instructions Instructions STEP 5 STEP 6 Pull the right leg, fixing the screw to the second hole. Place The Griddls Sureface.
- Page 15 SECTION D SECTION D Transporting & Storage Transporting & Storage Instructions Instructions STEP 7 STEP 8 Place the Griddls Sureface Transport or Store your Griddle. Close left side shelf first,then right side shelf. Caution Hold the side shelf securely while opening. Do NOT release until fully colsed.
- Page 16 Connecting The LP Gas Tank Comparison of a seal in good condition (left) to one that is dam- aged (right) Make sure the control knobs are in the " OFF" position. Figure 3 Before connecting, be sure there is no debris caught in the head of the LP gas tank, head of the regulator valve, or in the head of the burner or burner ports.
- Page 17 SECTION E Installing LP Gas Tank 2. Place the precision-filled LP gas tank upright onto the upper and lower LP gas tank supports so the tank valve is facing the gas line connection. To operate, you will need one precision-filled standard barbecue grill LP gas tank with external valve threads.
- Page 18 SECTION F Operating Instructions Tank/Gas Line Connection Make 2-3 0Z of leak detection solution by mixing one part liquid dishwashing soap with three parts water. Make sure control knobs are in the '' OFF'' position (Figure 2) Connect LP gas tank per ''Installing LP Gas Tank'' section. Checking for Leaks Turn LP gas tank valve to ''OPEN''.
- Page 19 Operating Main Burners Open side shelves Check for obstructions of airflow to the burners. Spiders, insects, and webs can clog the burner/venturi tube. A clogged First Use burner tube can lead to a fire. Make sure all labels, packaging and protective films have been All control knobs must be in the "...
- Page 20 Turning Off Minimize Flare-ups: Tum LP gas tank valve to "CLOSED" Trim excess fat from meats prior to cooking. Turn all control knobs clockwise to the " OFF" position Cook high fat content meats on (LOW) setting or indirectly. (Figure 2) Ensure that your griddle is on a hard, level, non-combustible Note: A "poof"...
- Page 21 Before Each Use: Cleaning Cart Surfaces Keep the griddle area clean and free from any combustible Wipe surfaces clean with mild dish washing detergent or materials, gasoline, and other flammable vapors and liquids. baking soda mixed with water. Do NOT obstruct the flow of the combustion of LP gas and the For stubborn surfaces, use a citrus-based degreaser and a ventilation of air.
- Page 22 Before Storing Tools needed for seasoning: Turn the LP gas tank valve to "CLOSED". Metal scraper or metal spatula. Turn all control knobs clockwise to the " OFF" position. Cooking oil, such as vegetable oil or extra virgin olive oil. Note: A "poof"...
- Page 23 The electrode is Replacement part(s) may be While the griddle is still warm, use a scraper or metal spatula cracked/broken- needed-contact VIVOHOME to remove as much rust and food residue as you can from sparks at crack at email griddle surface, inner and outer walls.
- Page 24 SECTION H SECTION H Troubleshooting Troubleshooting Problem Possible Cause Solutions Problem Possible Cause Solutions No gas flow Check if LP gas tank is empty Out of gas Exchange, refill, or replace the LP gas tank If empty, exchange, refill, or replace LP gas tank Overfilling Turn the control knobs If not, refer to "Sudden...
- Page 25 SECTION H SECTION H Troubleshooting Troubleshooting Problem Possible Cause Solutions Problem Possible Cause Solutions Food residue, Clean burner Flashback The burner and/or Clean the burners and/or grease, etc on (fire in burner burner/venturi burner/venturi tube The flame is burners tube(s)) tube are blocked yellow Poor alignment of...
- Page 26 This warranty program applies to any orders, purchases, receipts, ranty period, please contact our customer service team at our or use of any products sold by VIVOHOME and is valid for a email or via Amazon & app’s direct messaging service as soon as period of 1 year from the date of purchase.
