DIEMMEBI URBANTIME Cabana 015 Assembly Instructions

1
Call someone to help, you
better be two people!
First, take the 4 T-sleeves,
clean the internal surface
with the 3M wipes, use the 3M
cigarette primer, and after
some minutes apply two
pieces of adhesive for each
sleeve.
Assembly instructions
015. Cabana
Five steps procedure
2
Fix the benches and table to Then insert the vertical
the sled tubes, using 4 BHSS uprights and fix them at the
M8x14 for each product. bottom with 4 headless set
screw M8x30 (they must not
Insert the 4 T-sleeves ont the protrude beyond the surface
ends of the sled tubes. of the pipe).
Assemble 2 corner transoms,
fixing them to the top of the
uprights with 4 headless set
screw M8x30.
3 4
Now insert the 4 oblique
uprights and close the frame
at the top with the third
corner transom,
5
Spread the cloth on the frame
and insert the 2 cloth
transoms into the end
pockets.
Fix the transoms and the T-
sleeves using 4 headless set
screw M8x30.
Done!
