Guide: Battery Replacement

LMP Battery MacBook Pro 14", M1/M2, Thunderbolt 4

10/21, built–in, Li–Ion Polymer, 11.46 V, 70 Wh

P/N 25913

SUPPORTED APPLE DEVICES:

MacBook Pro (14-inch, 2021) / MacBook Pro (14-inch, 2023) /

MacBook Pro (14-inch, M3 Pro or M3 Max, Nov 2023) / MacBook Pro (14-inch, M3, Nov 2023)

Page 1

Need help?

Do you have a question about the 25913 and is the answer not in the manual?

Questions and answers

Summary of Contents for lmp 25913

Page 1 Guide: Battery Replacement LMP Battery MacBook Pro 14“, M1/M2, Thunderbolt 4 10/21, built–in, Li–Ion Polymer, 11.46 V, 70 Wh P/N 25913 SUPPORTED APPLE DEVICES: MacBook Pro (14-inch, 2021) / MacBook Pro (14-inch, 2023) / MacBook Pro (14-inch, M3 Pro or M3 Max, Nov 2023) / MacBook Pro (14-inch, M3, Nov 2023)
Page 2 Introduction It is highly recommended that this procedure is carried out by an experienced technician. LMP accepts no responsibility or liability in the event of any damage or injury caused while performing this procedure. It is the responsibility of the person performing the procedure to ensure that they have the requisite technical skills to competently carry out the battery replacement.
Page 3 Step 1 Before you start ensure that the MacBook Pro is completely turned off. Close the display and place the MacBook Pro upside down on a soft cloth or similar to protect the display housing. Remove the 8 screws securing the bottom case using a Pentalobe P5 screwdriver. four long screws four short screws.
Page 4 Step 2 Place the suction cup on the left hand bottom of the backside and gently pull up until you can hear the clips on the inside seperate. Repeat the same procedure for the right side. Page 4...
Page 5 Step 3 Gently pull the bottom case towards you as shown in the picture. Make sure to keep a flat angle while pulling to avoid internal damages. Page 5...
Page 6 Step 4 Remove the two screws that secure the cowling of the trackpadcable and remove said cowling. Page 6...
Page 7 Step 5 Use the flat side of a black stick to carefully lift out the trackpadcable connector. Use the picture above as placement reference. Page 7...
Page 8 Step 6 Push up the lever of the battery cable with your fingers or the black stick. Be as gentle as possible to prevent breaking or dislocating said lever. Page 8...
Page 9 Step 7 Pull the batterycable out of the connector towards you. Be careful not to damage or rip it. Page 9...
Page 10 Step 9 Remove the T5 batteryscrew to completely disconnect the battery from the rest of the hardware. Page 10...
Page 11 Step 10 Remove the screw securing the battery. Leaving this step out might cause the battery to get damaged later on. Page 11...
Page 12 Step 11 Remove the 10 T5 screws, holding the trackpad in place. Page 12...
Page 13 Step 12 Gently lift the top case up and get the trackpad out. Be carefull not to damage the trackpad flexcable in the process. Page 13...
Page 14 Step 13 You can now start to peel out the battery adhesives. There are two located under every batterycell, the exact position is shown in the picture above. Page 14...
Page 15 Step 14 If you can’t get the adhesives out with your fingers, try using a tweezer by spinning the adhesive around it as shown in the picture. Be careful not to puncture or otherwise damage the battery though. Page 15...
Page 16 Step 15 Repeat the same process for the adhesives under the trackpad. Again, watch out for battery leaks or other damages. Page 16...
Page 17 Step 16 You can lift out the battery once all adhesive has been removed. Place the adhesive in the package on the new battery as shown in the picture. Page 17...
Page 18 Step 17 Put the new battery into the device and gently push it down to firmly stick it to the topcase. Be sure the battery doesn’t move, there could be complications afterwards otherwise. Page 18...
Page 19 Step 18 Follow the disassembly steps in reverse order to reassemble the MacBook Pro. It is highly recommend that the battery is fully calibrated after being replaced. To do this charge the MacBook Pro fully to 100% and then keep on charge for a further 2 to 3 hours. Then use the MacBook Pro on battery power only until the MacBook Pro enters sleep mode due to low battery charge.
