Megaflo
Reverse Osmosis Water Filtration System
Installation and Operation Manual
WARNING
Please read this manual carefully before using your product, and keep it for future
reference. As the appliance is kept upgrading, it may differ between the actual
appliance and the one in the manual. Please refer to the actual product.
Advertisement
Summary of Contents for Mizudo Megaflo WP800A0G
- Page 1 Megaflo Reverse Osmosis Water Filtration System Installation and Operation Manual WARNING Please read this manual carefully before using your product, and keep it for future reference. As the appliance is kept upgrading, it may differ between the actual appliance and the one in the manual. Please refer to the actual product.
- Page 3 WARNING Please use municipal tap water as the water source. Do not use water that is Ÿ microbiologically unsafe or of unknown quality without adequate disinfection before or after the system. Be sure to handle the system gently and carefully. Do not attempt to modify or Ÿ...
- Page 4 CONTENTS 1 Explanation of Symbols and Safety Instructions 1.1 Recognize Safety Information 1.2 Understand Signal Words 1.3 Important Safety Messages 1.4 Installation Tips 2 General Information 2.1 Product Specification 2.2 Product Overview and Installation Illustration 3 Installation 3.1 Installation Instructions 3.2 Selecting the Faucet Location 3.3 Install the Angle Stop Valve for the feed water 3.4 Install the RO Faucet...
- Page 5 Check the packing list to confirm all accessories are included in the package. Contact Mizudo customer service 1.1 Recognize Safety Information if any components are missing or damaged This is the safety alert symbol. It is used to during shipping.
- Page 6 General Information 2 General Information 2.1 Product Specification Model WP800A0G WP1000A0G 800 GPD 1000 GPD Daily Production Capacity Operating Water Temperatures 40-100 °F (5-38 °C) Operating Water Pressure 15-100 psi (0.1-0.7 MPa) Power Specifications Input:110-240V AC Output:24V DC Feed Water Requirement Municipal Tap Water pH Parameters 2-11...
- Page 7 General Information 2.2 Product Overview and Installation Illustration RO system Faucet 3/8" White PE pipe 1/4" White PE pipe 1/4" Red PE pipe Angle stop valve Power adapter Drain connector 1/4”Clips 3/8"Clips Quick-connector fitting Hot line Drain outlet pipe Cold line Reverse Osmosis System Angle Stop Valve Faucet power cord...
- Page 8 Installation 3 Installation Tools and Materials Required Hand or electric drill(cordless preferred) Ÿ 3.1 Installation Instructions Adjustable wrenches Ÿ Slotted and Phillips screwdrivers Read all installation and operating instructions Ÿ before installing and using your RO system. Utility knife or scissors Ÿ...
- Page 9 Installation There is an existing mark at the end of the PE 3.2 Selecting the Faucet Location Ÿ pipe for you to confirm if the PE pipe is fully Most sinks have pre-drilled holes designed for inserted into the fitting. spray hoses.
- Page 10 Installation (C) Install the Angle Stop Valve on the cold water valve and tighten it with an adjustable wrench. Please don’t miss the gasket inside the angle stop adapter during installation. Pilot Hole NOTICE If the cold water pipe is 1/2", screw the conversion adaptor upper the Angle Stop Valve.
- Page 11 Installation 3.5 Install RO drain connector 1. Identify drain outlet location. 2. Knock out the center hole on the foam seal (④). 3. Use the hole in the foam seal (④) as a template to locate your drilling position above the drain tap.
- Page 12 Installation 3.6 Connecting the PE Pipe to the (c) Connect the Pure Water and the Faucet. System Insert one end of the 1/4" white PE pipe into the Pure Water hole. Secure the pipe with a 1/4" clip. Insert another end of the 1/4" white PE pipe into the quick-connector fitting of the Faucet.
- Page 13 Operation 3.7 Connecting the Power Cord (d) Connect the Drain Water and the Drain Connector Insert one end of the 1/4" Red PE pipe into the Drain Water hole. Use a 1/4" clip to secure the pipe. Insert another end of the 1/4" Red PE pipe into the Drain connection.
- Page 14 Operation NOTICE Initially, the water may appear cloudy. This is a result of air trapped in the RO filter. It is not harmful and will disappear in a matter of minutes. It may take up to a week after installing a new RO filter for the trapped air to dissipate.
- Page 15 Operation RO Faucet Indicator Indicator Indication Status Constant white light Power on Flash white light Flush mode Flash red light Malfunction Power off Constant white light Lifetime > 95% Flash red light 0 < Lifetime ≤ 5% Constant red light Lifetime = 0 Power off Constant white light...
- Page 16 Maintenance 5 Maintenance average, the actual lifetime of the cartridge would differ from the recommended replacement cycle. If the filter cartridge is blocked, please replace it. If you plan on not using the system for one week or longer, take out the filter and seal it with plastic Filter cartridge replacement wrap.
- Page 17 Troubleshooting 5.2 Automatic Flushing The system will be flushed automatically in one of the following situations: 1. Flush for Power Restore When power is restored after a blackout, the system will be forced to be flushed automatically for 30 seconds. While flushing, the flush indicator will flash a blue light.
- Page 18 Troubleshooting Problem Possible cause Solution System indicators all The system has been filtering water Unplug the system, wait for 1 minute, flash, the buzzer continuously for 2 hours. and plug in again to shoot the trouble. keeps beeping. RO faucet screen The PCB board is damaged.
- Page 20 Tel: 877-216-1818 E-mail: us.mizudo@fogatti.com...
