MANUAL FOR YOUR NEW ANKERMANN PC

Congratulations on the purchase of your new machine! We strive for content customers, so we want

to help you get to know your new acquisition well. This manual is intended to help you with that.

As a basic guide for the first steps with the PC, we enclose this manual, which contains all

information about the connections of your PC and the initial setup of Windows 10 and Windows 11.

The following connections are explained:



Graphics interfaces



Sound interfaces



USB- and S-ATA-interfaces

In addition, there are step-by-step instructions for the first setup of Windows 10 and 11, so that you

can start right away with your new Ankermann PC even without having expert knowledge.

In addition, we illustrate the installation of a RAM bar, of a SSD/hard drive and of a graphics card

with and without additional power connection.

We also address the packaging of your PC and its peculiarities.

Table of Contents

MANUAL FOR YOUR NEW ANKERMANN PC ........................................................................................... 1

THE PACKAGING ...................................................................................................................................... 2

CONNECTORS – GRAPHICS ...................................................................................................................... 3

CONNECTORS – SOUND .......................................................................................................................... 5

CONNECTORS – USB and S-ATA .............................................................................................................. 6

Setting up Windows 10 on the PC ........................................................................................................... 7

Setting up Windows 11 on the PC ........................................................................................................... 9

BASICS MAINBOARD .............................................................................................................................. 11

INSTALLATION OF A RAM BAR IN YOUR PC ........................................................................................... 12

INSTALLATION OF A SSD/HDD IN YOUR COMPUTER ............................................................................ 13

INSTALLATION OF A GRAPHICS CARD WITH/WITHOUT POWER CONNECTOR ..................................... 14

FINAL WORDS ........................................................................................................................................ 15

OUR LINKTREE WITH THIS PDF (MULTI-LANGUAGE), VIDEOTUTORIALS AND MORE: .......................... 15

APPENDIX - DECLARATIONS OF CONFORMITY, ETC. ............................................................................. 16

Need help?

Do you have a question about the 8754-255 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ankermann 8754-255

Page 1 In addition, there are step-by-step instructions for the first setup of Windows 10 and 11, so that you can start right away with your new Ankermann PC even without having expert knowledge. In addition, we illustrate the installation of a RAM bar, of a SSD/hard drive and of a graphics card with and without additional power connection.
Page 2 THE PACKAGING We pack our PCs in an inner and an outer carton, the space in between is filled with recyclable packing chips. The PCs are housed in a plastic bag and held in the inner carton by two large, precisely fitting pieces of Styrofoam.
Page 3 CONNECTORS – GRAPHICS The graphics connectors are used for image output and are connected to the monitor via a cable. There are ANALOG graphic interfaces like the VGA connector and DIGITAL graphic interfaces like the HDMI connector, the DisplayPort connector and the DVI connector. Digital graphics interfaces offer superior image quality compared to analog signals and should therefore be preferred.
Page 4 DVI-D cable and DVI-D connector: Digital image signals can be transmitted via the DVI-D interface. The maximum image resolution depends on whether it is a Single Link or Dual Link connection, Dual Link can transmit resolutions up to 2560 x 1600 at 60 Hz / 1920 x 1080 at 144 Hz. Single Link can transmit resolutions of up to 1920 x 1200 at 60 Hz.
Page 5 CONNECTORS – SOUND The standard audio ports are used for stereo sound output (light green), connecting a microphone or headset (pink) and connecting an external sound source via 3.5mm jack plugs (light blue). These connections are usually on the back of the PC, but can also be on the front or top. There are additional connections for multi-channel sound systems: A connector for rear speakers (black), a connector for the subwoofer (orange) and a connector for the center speakers (gray/silver).
Page 6 CONNECTORS – USB and S-ATA The USB interface is the most common connection between PC and external devices such as hard drives, keyboards, memory sticks and many more. This interface was introduced as version USB 1.0 in 1996 and has always been developed further. In 2019, USB 4 was introduced as the latest version so far.
Page 7 Setting up Windows 10 on the PC Please make sure what operating system you are using before setting up your PC for the first time. The following steps apply to Windows 10 only. After your PC is properly connected to the monitor and you have made sure that the power plug is housed power outlet,...
Page 8 9) Now you have the choice whether to accept the Microsoft license agreement and continue with the setup or to reject the license agreement and look for another operating system. Unfortunately, the installation will only continue if you accept the following. 10) Here you can specify whether you use the PC primarily yourself or whether it belongs to an organization (library, school, business, etc.).
Page 9 Setting up Windows 11 on the PC Before setting up your PC for the first time, please make sure what operating system is installed. The following steps apply to Windows 11 only. After your PC is properly connected to the monitor and you have made sure that the power plug is properly housed in a power outlet, you can turn it on for the first time.
Page 10 15) In the next screen, you can select personal recommendations that will be displayed to you. For example, there are Entertainment / Gaming and many other categories. 16) Now we come to a big innovation: in this step you can connect an Android phone to Windows 11 (optional).
Page 11 BASICS MAINBOARD 1. Free RAM slots 2. Free S-ATA connectors 3. PCI-Express slot 4. RAM-bar...
Page 12 INSTALLATION OF A RAM BAR IN YOUR PC While installing a RAM bar into the computer, it is important to note the following steps: 1. Ensure that the RAM bar is inserted the right way round. The notch marked in red in the picture must match the plastic nose in the memory bank.
Page 13 INSTALLATION OF A SSD/HDD IN YOUR COMPUTER Requires an SSD or hard disk, a free S-ATA port and a free power connection. 1) Insert the S-ATA cable with a plug into a free S-ATA port on the mainboard. 2) Take the SSD/hard disk in hand and prepare power connector and S-ATA connector. 3) House the free plug of the S-ATA cable and the power plug into the SSD 4) Ensure that the two plugs are well housed.
Page 14 INSTALLATION OF A GRAPHICS CARD WITH/WITHOUT POWER CONNECTOR Requires a graphics card, a free PCI-Express slot, a free power cable (if required) and screws for fastening the graphics card as well as a screwdriver. 1) Prepare the installation: Remove or open any expansion card locks / slot bezels on the back of the PC so that the graphics card can be easily placed in the PCI-E slot.
Page 15 FINAL WORDS We have put a lot of effort into providing you with a flawless, high quality product. This accompanying manual is designed to provide basic computer knowledge and to help you perform the most common tasks on your own. If problems should nevertheless arise: ...
Page 16 Technische Daten nach EU-Verordnung Nr. 617/2013 Geräteart Desktop-Computer Kategorie D Produktgruppe Basic Gaming PC Modellnummer 1525-238 Hersteller Ankermann Computer e.K. Alemannenstr. 2 79331 Teningen Herstellungsjahr 2022 Jährlicher Gesamtenergieverbrauch (E 133,46 kWh/a Energieverbrauch (ohne aktivierte Wake On 37,5 W (Leerlauf) 1,4 W (Ruhezustand) 0,3 W...
Page 17 Technische Daten nach EU-Verordnung Nr. 617/2013 Geräteart Desktop-Computer Kategorie D Produktgruppe Enthusiast Gaming PC Modellnummer 4315-844 Hersteller Ankermann Computer e.K. Alemannenstr. 2 79331 Teningen Herstellungsjahr 2022 Jährlicher Gesamtenergieverbrauch (E 194,38 kWh/a Energieverbrauch (ohne aktivierte Wake On 54,4 W (Leerlauf) 3,1 W (Ruhezustand) 0,4 W...
Page 18 Erreichen eines stabilen Stromverbrauchs Gerät einschalten, hochfahren, ggf. anmelden und warten bis alle Aktivitäten des Betriebssystems zum Start ausgeführt wurden. Ruhezustand und/oder Ausb-Zustand Falls der PC mit einem Betriebssystem ausgeliefert wurde, wurden sämtliche Energiespareinstellungen gemäß Vorgaben der Verordnung (EU) 617/2013 bereits durch den Hersteller voreingestellt.
Page 19 Technische Daten nach EU-Verordnung Nr. 617/2013 Geräteart Desktop-Computer Kategorie D Produktgruppe Midrange Gaming PC Modellnummer 8754-255 Hersteller Ankermann Computer e.K. Alemannenstr. 2 79331 Teningen Herstellungsjahr 2022 Jährlicher Gesamtenergieverbrauch (E 166,75 kWh/a Energieverbrauch (ohne aktivierte Wake On 46,8 W (Leerlauf) 1,9 W (Ruhezustand) 0,3 W...
Page 20 den Ruhezustand erfüllt werden Dauer, nach der der Computer im Anschluss an 15 min (je nach Einstellung im Betriebssystem) eine Phase der Inaktivität automatisch in einen Verbrauchsmodus mit geringerem Stromverbrauch als im Ruhezustand wechselt Dauer bei Inaktivität, bis der Ruhezustand des 15 min (je nach Einstellung im Betriebssystem) Displays aktiviert wird Energiesparmöglichkeiten der...
Page 21 Ruhezustand und/oder Aus-Zustand Falls der PC mit einem Betriebssystem ausgeliefert wurde, wurden sämtliche Energiespareinstellungen gemäß Vorgaben der Verordnung (EU) 617/2013 bereits durch den Hersteller voreingestellt. Das Gerät wird ausgeschaltet, indem die Ein/Aus-Taste am Gerät gedrückt wird. Über das BIOS-Setup des Mainboards kann die EuP-Einstellung verändert werden.
Page 22 Technische Daten nach EU-Verordnung Nr. 617/2013 Geräteart Desktop-Computer Kategorie D Produktgruppe Office PC ohne dGfx Modellnummer 2554-397 Hersteller Ankermann Computer e.K. Alemannenstr. 2 79331 Teningen Herstellungsjahr 2022 Jährlicher Gesamtenergieverbrauch (E 74,72 kWh/Jahr Energieverbrauch (ohne aktivierte Wake On 20,5 W (Leerlauf) 1,1 W (Ruhezustand) 0,2 W...
Page 23 den Ruhezustand erfüllt werden Dauer, nach der der Computer im Anschluss an 15 min (je nach Einstellung im Betriebssystem) eine Phase der Inaktivität automatisch in einen Verbrauchsmodus mit geringerem Stromverbrauch als im Ruhezustand wechselt Dauer bei Inaktivität, bis der Ruhezustand des 15 min (je nach Einstellung im Betriebssystem) Displays aktiviert wird Energiesparmöglichkeiten der...
