Waterless
Aroma diffuser
Model No. MJ-HBAL1GL
User Manual
For Household Use
Thank you for your purchase.
● Read this User Manual before use to ensure
correct use of the product.
● Make sure to read the Safety Advice before use.
● Keep the User Manual in an accessible place for
future reference.
This product is an aroma diffuser that uses an air
pump to deliver air and directly nebulise aroma oil
without using water.
This product is designed to be used with MUJI
Essential Oil 10 mL.
Table of Contents
Safety Advice...........................................................1
Part Names .............................................................4
Preparation ..............................................................5
How to Use ..............................................................7
Cleaning the Product ...............................................9
Troubleshooting.....................................................11
Specifications ........................................................12
Advertisement
Summary of Contents for Muji MJ-HBAL1GL
- Page 1 This product is an aroma diffuser that uses an air pump to deliver air and directly nebulise aroma oil without using water. This product is designed to be used with MUJI Essential Oil 10 mL. Table of Contents Safety Advice............1 Part Names .............4...
- Page 2 Safety Advice The cautionary information indicated here is intended to ensure correct use of the product and to prevent harm to the users and other individuals or damage to the product. Classification of the Symbol In this User Manual, the items to be followed are classified as below. WARNING Indicates a hazard with a level of risk which, if not avoided, may result in death or serious injury to the user.
- Page 3 Do not use when the USB health. connector/cable is damaged or loosely inserted. Make sure to use MUJI's Essential Otherwise it may cause an electric shock, Oil 10 mL. burn, injury, a short circuit and/or a fire. The use of other substances may give rise to a toxic or fire risk.
- Page 4 CAUTION Fit the bottle cap opener firmly in Do not use the following solvents or between the cap and the rim of the detergents when cleaning the main bottle. unit. Otherwise the bottle cap opener may Thinner, alcohol, benzene, gasoline, become displaced when pushed, causing paraffin, sprays, alkaline detergents, injury.
- Page 5 Part Names Front Back Top Cover Mist Outlet LED Light Light Switch Power Indicator USB Port Power Switch (USB Type-C) Bottom Timer Button Nozzle Cap Nozzle Cap Tube Maintenance Bottle (Included) Accessory USB Connector USB Cable Bottle Cap Opener Replacement Tube (USB Type-A →...
- Page 6 ● The maintenance bottle is empty before initial use. It is used when cleaning the WARNING main unit. Do not discard it after removing Make sure to use MUJI's Essential from the nozzle cap. Oil 10 mL. The use of other substances may give Open the lid of the essential oil to rise to a toxic or fire risk.
- Page 7 Connecting USB Cable to Attach the nozzle cap on the essential oil. Main Unit Insert the tube into the bottle of essential oil and turn the nozzle cap clockwise to Connect the USB cable to the securely fix it. main unit. Insert the USB connector (USB Type-C) of the USB cable into the USB port (USB Type-C) of the Main Unit.
- Page 8 How to Use Insert USB connector (Type-A) Turn off the power indicator to stop into a USB power source. the operation. Insert the USB connector (Type-A) of the Press the power switch 1 or more times to USB cable connected to the main unit into turn off the power indicator to stop the a USB power source.
- Page 9 Using LED Light Setting Timer Insert the USB connector (Type-A) Setting the timer will automatically turn the aroma diffuser function off 2 hours after setting. of the USB cable connected to the *The timer cannot be set for the LED light. main unit into a USB power source.
- Page 10 Cleaning the Product Nozzle Cap WARNING Do not submerge the main unit into Note water or splash water on it. ● Use commercially available anhydrous Doing so may cause an electric shock, a ethanol and the maintenance bottle short circuit, an ignition, or a fire due to (included).
- Page 11 Replacing Tube Take out the maintenance bottle from the main unit and remove the nozzle cap from the maintenance If the scent of the previously used essential oil remains strong even after cleaning, replace the bottle. tube of the nozzle cap. (Refer to ‘Preparation: Setting Essential Oil’...
- Page 12 Troubleshooting If there are any abnormalities with your product, check the following points. If the problems persist, turn off the power and contact the store of purchase. Problem Possible cause Solution Reference The USB connector Securely plug the USB (Type-A) is unplugged from connector (Type-A) into the USB power source.
- Page 13 Specifications MJ-HBAL1GL Model Number Power Source 5 V / 2 A Power Consumption Product Dimensions Approx. φ126 mm (5 in) × Approx. 203 mm (8 in) Weight Approx. 550 g (1.21 lb) (main unit) Length of USB Cable 1.8 m (70.9 in) Applicable Floor Area High: 13.20 m...
- Page 14 This symbol on the product, packaging, and/or accompanying document indicates that this product should not be disposed with normal household waste. This product shall be taken to the applicable collection point for recycling. The correct disposal of your old product will help prevent potential negative consequences for the environment and human health.
- Page 16 Ryohin Keikaku Co.,Ltd. 2-5-1 Koraku, Bunkyo-ku, Tokyo, Japan Imported to Australia by MUJI RETAIL (AUSTRALIA) PTY LTD Level 5 90 William Street Melbourne, VIC 3000, Australia...
