BULLETIN NO.
29
AUTO
RADIO
Februaty L, 1936
'INSTALLATION
AND
OPERATING
INSTRUCTIONS
MODEL
816
nn
Prrrr.co
Auro Repro Mopnr, 816
is
Philco's
newest
in
automobile
radio.
It
is a highlv
devel-
oped superheterodyne, single-unit
type
Receiver,
with
all
the
modern features required
in
such
a fine
instru-
ment.
THE NEW
RECEIVER
IS
EQUIPPED WITH
AN
ADJUSTABLE ANTENNA STAGE, WHICH
MAKES
IT
POSSIBLE
TO OPERATE
THE
RE-
CEIVER AT,MAXIMUM EFFICIENCY ON ANY
ROOF-TYPE OR UNDER-CAR TYPE ANTENNA.
Receiver, speaker and
full-wave Philco Vibrator
are
housed
in a
rugged, compact,
fully
shielded container
which
is
designed
for
quick and easy installation
on
the dash
of all
automobiles,
with two "Tee" bolts.
The
installation
in
most cars, can be easily
made above the
steering
column.
The loud
speaker faces
the front
seat,
so
that the improved Philco Electro-dynamic
Speaker
delivers
its full
toned
reproduction toward the
occupants
of the car with utmost
fidelity.
The
speaker
panel
is
easily removed so
that
tubes
and vibrator are
accessible'
for
service.
All
tubes used are
the latest Philco High
Efficiency
Tubes, designed
for
automobile
radio.
Several
of
these
tubes
perform the functions formerly requiring two
or
three tubes, thereby efrecting greater tube
economy, re-
ducing
the
number
of
tubes
necessary
for
satisfactory
operation, and also reducing the amount of current
taken
from the car battery to a
minimum.
Philco's system
of
automatic volume
control
is
used,
giving
smooth, elastic control which counteracts fading
while driving
along
under varying
conditions and
pre-
vents blasting of local
stations.
This new, all-electric
Receiver
is
equipped
with
im-
proled
interference filters. and esplcially
desigrred
shielding
to
eliminate motor interference making it
possible to install
it
quickly and
easily.
The new streamline "wide visionl' control can
be
installed on the
edge
of
the
instrument
board.
This
control
unit is
exceptionally attractive and iS
designed
to
blend harmoniously
with the
instrument
boardi of
practically all
cars.
There are only two
connections
to
make, one
to
the
antenna,
the other
to the
ammeter binding
post.
Now, more than ever,
THE
NEW PHILCO
AUTO
RADIO IS EASY TO INSTALL
and is a
PLEASURE
TO
OPERATE.
