Gledopto LEDLUMI GL-RC-006Z Quick Start Manual

RGB+CCT Remote Control (GL-Rc--0osz1
This manual describes RGB+CCT remote control used for our RGB+CCT products
Remote control can control the LED lights up to six different Zones,change the
color,dim/brighten the lights,warm/cool white,different programs.In this manual,
you will learn.
Indicator
, _ j, ;� �� ?;::- t
Brightness---+
Master OFF
Zone ON
Zone OFF
�- � r _ -_-----i ----f 'lIT] GB- +
60s off delay
Modes(9 Programs)
Battery Installation
Please take the remote control and carefully press the battery cover and push
it away in a downward motion.Install two AAA batteries,exactly match the
negative ( - } pole of each battery to the largest spring.Don't touch the color ring
when you install the batteries.Place the battery cover back and install tightly.
Auto-transfer
Technical data:
Size:18x55xl30mm
Material:PC
Color Ring
Transmitting Power:6dB
Slider
Modulation Method:GFSK
CC T
Programs:9 kinds
Brightness+
Power:3V(AAA battery*2pcs)
Standby power:lSµA
Master ON
6x(un)link light
Working Temp:-20
Max control Range: 20m
RF Frequency:2.4GHz
Spee d-
Warranty:2 Years
Speed+
:,; ' <20m <20m
,?i'i ,?i'i
, 2 o
,- -
rr0
-
<20m
<20m
,?i'i ,?i'i
.;'
, 2 0 �
½1 ½1
<20m <20m
;!
How to link & use
1. Within 3 seconds after power on, dick the "on" button of the group to conduct
code matching, and the LED light turns green, indicating successful code matching.
2. Long press the ·off" button of the remote control to enter the night light mode,
and the brightness and color can still be adjusted at this time.
3. long press the small moon key to enter the 60 seconds delay shutdown state.
4. Long press M key to enter automatic mode.
How to unlink
1. If the LED is still connected to the Zigßee gateway, long press the "on" button on
the remote control within 3 seconds after power on or press the button for 5 times
continuously, the light will flash for 5 times in the current color;
° °
C~60 C
2. If the LED is not connected in the ZigBee gateway state, long press the "on·
button on the remote control within 3 seconds after power on or press the button
for 5 times continuously, then the LED light will be fully bright and flashing for 5
times;
Mode description
Mode 1: Static warm light (warm light alone)
Mode 2: Static white light (cold light and warm light are equally bright)
Mode 3: Static cold light {cold light alone)
Mode 4: Static red light
Mode 5: Static green light
Mode 6: Static blue light
Mode 7: RGB fade in fade out (Color fade in fade out from red to green, then to
blue, then to red, and so on, speed adjustable.)
Mode 8: RGB flash {Color flash from red to green, then to blue, then to red, and
so on, speed adjustable.)
Mode 9: Color breathing (In this mode, the brightness of current color will cycle
from from 100%-0%, then from 0%-100%. At the same time, you can
switch the color and have a cycle repeatedly. Pressing switch /mode
button to exit this mode.)
