Summary of Contents for Hearst Communications GOOD HOUSEKEEPING 73038-BK
- Page 1 Plug-in Heater Owner's Manual Model 73038-BK 73038-WH...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction ..............Safety and Warnings ............Important Instructions ............. Grounding Instruction ............. Parts of the Heater ............Operating Instructions ............ Thermal Cut-Off Protection System ......Cleaning and Maintenance ..........Storage ................Trouble Shooting ............Technical Support ............ -
Page 3: Introduction
INTRODUCTION Thank you for choosing the Good Housekeeping Ceramic Heater. This manual gives you complete instructions for using your heater. SAFETY AND WARNINGS READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE OR MAINTAIN THE PRODUCT DESCRIBED. PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY INFORMATION. - Page 4 5. Do not operate heater with a damaged plug, or if the heater has been dropped or damaged in any manner. Discard heater or return to an authorized service facility for examination and/or repair. 6. Do not use outdoors. 7. This heater is not intended for use in bathrooms, laundry areas and similar indoor locations.
- Page 5 18. Check the heater plug connections. A loose fitting outlet can cause the plug to overheat or cause a fire. Be sure plug fits tight in the outlet. Check frequently during use to make sure plug and outlet are not hot. If so, discontinue using heater and have the outlet replaced by a qualified electrician.
-
Page 6: Grounding Instruction
GROUNDING INSTRUCTIONS Grounded Plug This appliance is for household use only and may be plugged into any 120-volt AC electrical outlet (ordinary household current). DO NOT use any other type of outlet. WARNING: This unit is suitable for grounded receptacle use only. -
Page 7: Parts Of The Heater
PARTS OF THE HEATER Parts of the Heater Symbols 1. Control Panel Power Button 2. LED Display Plus Button 3. Safety Grill Minus Button Timer Button 4. On/Off Switch 5. Power Light Figure 3 (Figure 3) (Figure 4) OPERATING INSTRUCTIONS Operation 1. - Page 8 Timer Button once more will reset the heater to run continuously. The heater will turn off when the set time has elapsed. The unit can be turned back on by pressing the Power Button . Pressing the Timer Button to 0 hour will cancel the timer function.
-
Page 9: Thermal Cut-Off Protection System
THERMAL CUT-OFF PROTECTION SYSTEM This heater includes an Overheat Protection System that shuts the unit off permanently when a potential overheat temperature is reached. If this occurs, the heater can only resume its normal operation after resetting it. To reset the heater: 1. -
Page 10: Trouble Shooting
TROUBLE SHOOTING If your heater fails to operate: Make sure the electrical outlet or circuit breaker is working. Check for obstructions. If you find an obstruction, turn the heater OFF, and UNPLUG THE UNIT. Carefully remove the obstruction and follow the reset instructions. - Page 11 IF THE USER OR CONSUMER PURCHASER CEASES TO OWN THE HEATER, THIS WARRANTY AND ANY IMPLIED WARRANTY WHICH THEN REMAINS IN EFFECT, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE VOIDED. NO WARRANTY, EXPRESSED OR IMPLIED, INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, IS MADE IN RESPECT...
- Page 12 LEGAL RIGHTS AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE. 980 Cobb Place Boulevard NW, Suite 100, Kennesaw, GA 30144 GOOD HOUSEKEEPING is a trademark of Hearst Communications, Inc. 2022 Hearst Communications, Inc. All Rights Reserved. Printed in China 82502-01 R20230919...
