Over-Bed Table with Four Castors - BED294
Assembly Instructions and User Guide
Thank you for choosing a MedeQuip Over-bed Table. This user guide should be read carefully before you use
the over-bed table, as it contains important information regarding the product, including the safe operation
and maintenance of it.
Package Contents
Before attempting to assemble this product check that all parts are present and complete. If any parts are
missing please contact your supplier.
Assembly
1) Screw all four castors into the base and tighten with a spanner. (Supplied)
2) Remove the "E Clip" from each leg.
3) Place each leg over the base spigots.
4) Re-insert the "E Clips" to attach the legs to the spigots.
5) Unfold the support legs outwards. One support leg must be re-positioned before proceeding. Press the
spring button and slide it under the clip.
6) Slacken off the hand wheels and insert the support legs into the legs on the base. Tighten the hand wheels
to fix the table top at the required height and angle. Adjusting the angle when the table is in use the hand
wheels only require slackening a turn or two they do not need removing.
Medequip Assistive Technology Ltd Unit 2, Heathrow Summit Centre, Skyport Drive, Harmondsworth, UB7 0LJ
Tel: +44 (0) 208 750 1580 Fax: +44 (0) 208 759 2345 website: www.medequipuk.com
Product Dimensions
Width (mm) Length (mm)
410 680
Height
(From floor to top of table)
680mm – 980mm
