Safe Fleet MP-1144 Quick Installation Manual

Mounting the Media Player
3. Connect device wiring as required,
according to the diagrams on the
previous pages:
• Run the HDMI cable through the
front plate cable tie and into the
HDMI Out port, as shown.
• Assemble the GPIO Terminal Block
and run door trigger and power/
ground wires through the rear plate
cable tie as shown.
4. Tighten the cable ties on the front and
rear mounting plates until the HDMI and
GPIO connectors are supported and
secure.
Status LEDs
LED Color Indication
Pwr Green Displays when device powered up and not in reset mode (flashes during
firmware updates).
Bsy Green Flashes when there is file-system activity (on any storage device).
Blue Flashes when the player is connecting to the wireless network. Displays when

connected.
WiFi
Err Red Flashes a certain number of times to indicate an error. Please contact Technical
Support for flash code details.
Service & Support
If your media player is to be returned for service, please contact the Safe Fleet technical support team, provide
the part and serial # of your unit, and ask for a Return Merchandise Authorization (RMA) number.
An RMA # allows the support team to better track your product when it comes in for service. Please show the
RMA # on the outside of the package.
ANY PRODUCT SENT WITHOUT AN RMA# MAY BE REFUSED!
Documentation and Warranty
Additional copies of this guide along with other documentation
and product warranty can be found on the Safe Fleet
Community website: https://community.safefleet.net
2002/96/EC (WEEE directive): This product cannot be disposed of as unsorted municipal waste in the Europe-
an Union. For proper recycling, return the product to your local supplier upon the purchase of equivalent new
equipment, or dispose of it at designated collection points, for more information, see www.recyclethis.info.
2006/66/EC (battery directive): This product does not contain batteries.
(continued)
Tip: Small Screwdriver
LIGHTBUL
GPIO Terminal Block assembly
requires a precision screwdriver with
a small slotted tip.
Technical Support
Phone: 1.844.899.7366
Email: PTsupport@safefleet.net
This Guide describes installation of the MP-1144
media player.
Information is subject to change without notice.
For the latest documentation, please visit the Safe
Fleet Community at https://community.safefleet.net.
Kit Contents (Typical installation † )
Check the package and contents for visible damage.
If any components are damaged or missing, contact
the Safe Fleet Service team and request an RMA
(Return Material Authorization).
• MP-1144 Media Player (Part #: 080-1092)
• HDMI Mounting Plate (Part #: 660-1114)
• GPIO Mounting Plate (Part #: 660-1115)
• MP-1144 Power Harness - 2-conductor,
6ft./1.83m (Part #: 060-1302)
• Power Conditioner Power Harness -
2-conductor, 20ft./6.1m (Part #: 415-0015G)
• Mounting Screws - #8 x 3/4, self-drilling, Qty 4
• Cable Ties, Qty 4
• 12VDC to 12VDC Voltage Regulator/Power
Conditioner (Part #: 085-1116)
• GPIO Terminal Block, 6-pin * (Part#: 444-1077)
• Fuse, 1A, 32V (Part #: 420-0009G)
• Fuse Holder (Part #: 470-0012G)
• Connectors, Butt-splice
(Part #: 444-0071G), Qty 5
• Micro SD Card, 32GB (Part #: SDCARDM32)
Pre-inserted in the media player
• Wall Plug Power Adapter - optional
(Part # : 085-1157)
*
MP-1144 can accommodate a total of two
6-pin GPIO Terminal Blocks. One is supplied with
the MP-1144. Contact Safe Fleet to purchase
additional 6-pin GPIO Terminal Blocks.
© Safe Fleet | All rights reserved
MP-1144 Media Player
Quick Installation Guide
† Some installations may include the following
modifications to typical Kit contents:
• GPIO Mounting Plate and Mounting Screws
(#8 x 3/4, self-drilling, Qty 4) removed.
• HDMI Mounting Plate hardware added:
8-32 x 3/8 pan head Phillips screws and locknuts
(Qty. 2 each)
• Cable ties, Qty. 2 (versus 4)
• Hook and Loop Adhesive Strips, Qty. 4
Installation Environment
• Install electrical wiring carefully. This should be
done by qualified service personnel.
• Route wiring and cables away from sharp edges
that might damage insulation. Avoid sharp
bends in cables.
IMPORTANT: Exposure to Humidity

Exposing a cold player to warm air at high relative humidity
may cause water to condense inside the player, leading to
component failure. If a player is cold, allow several hours for it
to acclimatize to ambient conditions before applying power.
System Documentation
Product documentation is available from
https://community.safefleet.net (search for your
device on the Safe Fleet Passenger Transportation
Solutions page).
Scannable QR code linking to
Safe Fleet Community for more
product information.
2022 | Part #: 700-1202 R4
