Summary of Contents for TR-Electronic TRsystems notion.D.computer 21.5
- Page 1 Operating instructions notion.D.computer 21.5 Original manual | eng Industry computer Series: notion.D.computer 21.5 Universal HMI system...
- Page 2 About this guide TRsystems GmbH is a company of TR Electronic GmbH. The products, names, specifications and logos mentioned are for information purposes only and may be trademarks of their respective owners without specific identification. Exclusively for industrial environment! This documentation was created with machine support. WEEE Reg.
- Page 3 Table of contents Content TABLE OF CONTENTS .......................... 3 ABOUT THIS GUIDE........................5 Target group ..........................6 Explanation of terms ......................... 6 FOR YOUR SAFETY ........................7 STRUCTURE AND INTERFACES ....................12 Interfaces: Pin assignment ....................... 13 COMMISSIONING ........................18 Unpacking ..........................
- Page 4 About this guide TECHNICAL DRAWINGS ......................20 Grounding the system ......................21 Connect cables and power supply .................... 22 DECOMMISSIONING ........................23 Repair ............................. 25 Detergent ..........................25 ESD PROTECTION FOR WORK ON THE BATTERY ................. 27 Professional disposal of hazardous materials ................28 APPENDIX ..........................
- Page 5 About this guide This description is intended exclusively for trained specialists in control and automation technology who are familiar with the standards and laws applicable at the place of operation. For installation and commissioning of the components it is absolutely necessary to observe the following notes and explanations.
- Page 6 About this guide Release The intended use of the product Aim of the instruction 05.06.2023 Author Creation date 05.06.2023 Release by Release on TRS-DOC-001842 Document number Change index On this page of the document, the current version status is noted with the associated date and author. Drawings that may be in the appendix are provided with their own change index.
- Page 7 For your safety The safety chapter explains the safety symbols used and their meanings. They receive basic safety instructions that are necessary to prevent personal injury and property damage. are essential. Disclaimer In case of non-observance of this documentation and thus the use of the devices outside the documented operating conditions, TRsystems GmbH is excluded from liability.
- Page 8 For your safety Classification of the hints These operating instructions contain information that you must observe for your personal safety and to avoid damage to property. A distinction is made between basic safety instructions and warning instructions. Nature and source of the hazard Misapplication Warning signs according to the following table.
- Page 9 Warning structure The SAFE method is a procedure for the systematic design of safety instructions. Severity of the hazard (signal word) Nature and source of the hazard Consequences of disregarding the danger Danger of cutting due to sharp-edged Escape (measures to avert the danger) metal sheets.
- Page 10 For your safety Intended use The product is designed exclusively for industrial use in machine and plant engineering. Use not in accordance with the intended purpose Do not use the system outside the documented operating conditions Basic safety method The following safety instructions must be observed when handling the device. Conditions of use Do not use the device in extreme ambient conditions.
- Page 11 Note on information security The user is responsible for preventing unauthorized access by third parties to its equipment, systems, machines and networks. The latter should only be connected to the corporate network or the Internet if appropriate protective measures have been set up.
- Page 12 Structure and interfaces Structure and interfaces notion.D.computer 21.5 Front view Rear view Position Description Display and touch screen Input/output unit VESA mount Support arm mounting (VESA75) Battery cover Access to the battery (Battery SL-350/S 3.6V 1.2Ah 1/2AA; Art.-No.: 63100456A) Ground connection Earth Connection room Installation space for electrical connections...
- Page 13 Interfaces: Pin assignment Interface position 6 X 01 X01 Power supply / Power Note the orientation of the interface on the system Signal 24 VDC (+20 / -15 %) CPUps: 24 VDC approx. 2 A CPU11: 24 VDC approx. 4 A TRsystems GmbH is a company of TR Electronic GmbH.
- Page 14 Structure and interfaces Interface position 7 (CPUps) X 10 X 11 X 53 X 40 X 27 X 26 X 26.1 X 52 X 27.1 Interface - Pos. Naming Function 7 (CPUps) Ethernet0 (eth0) Ethernet1 (eth1) USB 3.0 X26.1 USB 3.0 USB 3.0 X27.1 USB 3.0...
- Page 15 X10, X11 (LAN) Note the orientation of the interface on the system Signal T2 + T2 - T3 + T1 + T3 - T4 + T4 - X20 (USB2.0) Note the orientation of the interface on the system Signal Ground Data+ Data- Power (5VDC)
- Page 16 Structure and interfaces X40 (COM1) Note the orientation of the interface on the system Signal TXD- TXD+ RTS- RTS+ RXD- RXD+ CTS+ X52 (HDMI) Note the orientation of the interface on the system Signal TMDS Data 2+ TMDS Data 2 Shielding TMDS Data 2- TMDS Data 1+ TMDS Data 1 Shielding...
- Page 17 X53, X55 (DisplayPort) Note the orientation of the interface on the system Signal LVDS - Line 0+ Mass LVDS - line 0- LVDS - Line 1+ Mass LVDS - Line 1- LVDS - Line 2+ Mass LVDS - Line 2- LVDS - Line 3+ Mass LVDS - line 3-...
- Page 18 Commissioning Commissioning To be able to use the system, you must first put the system into operation. This includes in the first step is the transport and unpacking of the device. This is followed by the assembly of the device on the support arm or in a corresponding cutout.
- Page 19 Assembly and weight Falling damage, risk of injury During assembly, the device may fall on the foot. ► Wear safety shoes ► Secure the device against falling out during installation ► Use transport aids to the final assembly site Damage to property due to incorrect handling The device may be mechanically damaged during installation.
- Page 20 Technical drawings Technical drawings notion.D.computer 21.5 Structural dimensions for recessed mounting TRsystems GmbH is a company of TR Electronic GmbH. The products, names, specifications and logos mentioned are for information purposes only and may be trademarks of their respective owners without specific identification.
- Page 21 Mounting cutout for recessed mounting Switching the Panel PC on and off Grounding the system Grounding or equipotential bonding of electronic devices minimizes different electrical potentials (potential differences) and discharges electrical currents into the ground. This is to avoid dangerous touch voltages and electromagnetic interference. The grounding bolt, via which the functional grounding of the system is ensured, is located in the interface shaft.
- Page 22 Technical drawings Connect cables and power supply Incorrect procedure for connection Incorrect procedures when connecting the cables and the power supply can cause damage to property. ► Follow the documented procedure for connecting the lines and the power supply. ► Always connect all lines first and only then switch on the power supply.
- Page 23 Decommissioning Falling damage, risk of injury During disassembly, the device may fall onto the foot. ► Wear safety shoes ► Secure the device against falling out when removing it ► Use transport aids to the final storage location Damage to property due to incorrect handling The device may be damaged during disassembly.
- Page 24 Decommissioning Disconnect power supply and lines Risk of electric shock Disconnecting the Panel PC during a thunderstorm can cause electric shocks. ► Never disconnect the cables of the Panel PC during a thunderstorm. Before disassembling the Panel PC, you must disconnect the power supply and the cables. To do this, follow the steps below: Shut down the Panel PC.
- Page 25 Dismantling and disposal In order to be able to dismantle the system from a support arm, you must first disconnect the power supply and have disconnected the lines (see chapter Disconnecting power supply and lines). Repair Repairs to the device may only be carried out by the manufacturer. In case of repair, contact TRsystems "Service and Support".
- Page 26 Decommissioning Maintenance Use of incorrect spare parts The use of spare parts not ordered through TRsystems Service may result in unsafe and incorrect operation. ► Only use spare parts that you have ordered via TRsystems Service. TRsystems GmbH systems are manufactured, selected and tested from components of the highest quality and robustness for best interoperability, long-term availability and reliable function under the specified environmental conditions.
- Page 27 ESD protection for work on the battery Electrostatic discharge The use of spare parts not ordered through TRsystems Service may result in unsafe and incorrect operation. ► If possible, apply ESD protection measures during maintenance work. When working (e.g. replacing the battery) on electronic devices, there is a risk of damage due to ESD (electrostatic discharge), which can result in functional impairment or destruction of the device.
- Page 28 ESD protection for work on the battery Battery replacement Wrong battery type Using any other battery may cause fire or explosion. ► Replace the battery only with a replacement battery (battery SL- 350/S 3.6V 1.2Ah 1/2AA) from TRsystems Service (part number 63100456A).
- Page 29 Index Description TRsystems GmbH Eglishalde 16 Address D-78647 Trossingen 07425/228-0 Model notion.D CP/N Custom Product Number (Customer number, if available) Product Number (item / product number) Version Article version (Note: will be inserted as necessary). Index Description Production order number (8 digits) Consecutive number within the production lot, refers to production order (4 digits), set as Serial...
- Page 30 Appendix Appendix Service and support TRsystems offers comprehensive service and support, providing fast and competent assistance for all questions regarding TRsystems products and system solutions. TRsystems Service and Support The service supports you around the after-sales service: On-site service Repair service Spare parts service Telephone support The support offers you a comprehensive technical support, which will help you not only with the application...
