Summary of Contents for Measurement Systems International MSI5200
- Page 1 MSI5200 BANTAM User PORTABLE VEHICLE Guide WEIGHING SYSTEM WITH 4 CHANNEL Quality SELECTOR BOX Industrial Weighing and Force Measurement Equipment Measurement Systems International...
- Page 2 M E A S U R E M E N T S Y S T E M S I N T E R N A T I O N A L TABLE OF CONTENTS Installation ................... 3 Meter ....................3 How to Set Up and Operate the System ..........
- Page 3 M E A S U R E M E N T S Y S T E M S I N T E R N A T I O N A L THE BANTUM WHEEL WEIGHER SYSTEM Carrying Case: Used to transport and store the entire system when not in use. Weigh Pad Cable: Used to interconnect weigh pads.
- Page 4 M E A S U R E M E N T S Y S T E M S I N T E R N A T I O N A L Span Control Screw and Cap: Used only during system calibration (see Calibration Procedure). Cap should be left in place during normal operation.
- Page 5 M E A S U R E M E N T S Y S T E M S I N T E R N A T I O N A L HOW TO SET UP AND OPERATE THE SYSTEM Note: Typical six pad arrangement (Figure 2) allows for easy weighing of both two and three axle vehicles.
- Page 6 M E A S U R E M E N T S Y S T E M S I N T E R N A T I O N A L The system is now ready for weighing operation. Use two weigh pads per axle.
- Page 7 M E A S U R E M E N T S Y S T E M S I N T E R N A T I O N A L Operate the system as in Battery Operation steps 1-8. Note: The engine of the vehicle to which the system is connected should be running to ensure constant 12 Volt power availability.
- Page 8 2 through 10 if the meter does not return to 0. 12) Replace the cap screw. 13) Repeat steps 2 through 12 for each pad. Note: Measurement Systems International, Inc., will calibrate, for a fixed charge, systems that are returned to the factory. Systems must be returned freight prepaid.
- Page 9 M E A S U R E M E N T S Y S T E M S I N T E R N A T I O N A L The internal battery may be allowed to charge continuously. A fully discharged battery will reach 80-90% of full capacity within 16 hours if the ON/OFF switch is in the OFF position.
- Page 10 M E A S U R E M E N T S Y S T E M S I N T E R N A T I O N A L TROUBLESHOOTING GUIDE SYMPTOM: POSSIBLE CAUSE: ACTION: Meter display is blank without Discharged Battery.
- Page 11 M E A S U R E M E N T S Y S T E M S I N T E R N A T I O N A L SYMPTOM: POSSIBLE CAUSE: ACTION: Meter reading is erratic or drifting Loose or disconnected weigh pad Check cables.
- Page 12 M E A S U R E M E N T S Y S T E M S I N T E R N A T I O N A L FIGURES ACCESS PLUG SEAL Figure 1: Access to calibration port. METER Figure 2: Six-pad system configuration.
- Page 13 M E A S U R E M E N T S Y S T E M S I N T E R N A T I O N A L 14' or 24' 14' or 24' METER Figure 3: Four-pad system configuration. METER Figure 4: Two-pad system configuration.
- Page 14 I N T E R N A T I O N A L THE MSI LIMITED WARRANTY MEASUREMENT SYSTEMS INTERNATIONAL, INC., WARRANTS load sensing elements and meters against defects in workmanship and materials for a period of one year from date of purchase and warrants electrical cables and batteries against the same defects for a period of ninety (90) days from date of purchase.
- Page 15 M E A S U R E M E N T S Y S T E M S I N T E R N A T I O N A L MSI-5200 Bantam Vehicle Weighing System • User Guide Page 15...
- Page 16 MADE IN THE Measurement Systems I N T E R N A T I O N A L 14240 INTERURBAN AVENUE SOUTH ©1997 by Measurement Systems International Page 16 MSI-5200 Bantam Wheel Weigher • User Guide PUB.258-03-97 SEATTLE, WASHINGTON 98168-4660 U.S.A.
