- Page 1 S Y - V L P 2 4 R...
- Page 2 Welcome Thank you for purchasing the new stand fan SY-VLP24R. Please read this manual carefully before operating the product and pay close attention to the precautions, which are mentioned below. Store this user manual in a safe place for future reference.
- Page 3 • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instructions concerning use of the appliance in a safe way and understand the hazards involved.
- Page 4 Description 1. Front grill 2. Blade cap 3. Blade 4. Plastic mounting nut 5. Rear grill locker (Plastic mounting nut) 6. Motor shaft 7. Oscillating knob 8. Speed knob 9. Connector 10. Fixing screw A 11. Upper tube 12. Fixing screw B 13.
- Page 5 Assembly diagram Base assembly • Loosen and remove the “L” type screw and washer (15) from the lower tube. • Insert the lower tube (13) into the base hole (14) and secure the “L” type screw including the washer (15). •...
- Page 6 • Push the fan blade (3) onto the motor shaft (6) by matching the slots on the base of the blade with the shaft pin. Tighten the blade cap (2) by turning it anticlockwise. Check that the fan blades rotate freely by turning with your hand. •...
- Page 7 • Make sure that no liquid gets inside the appliance. • Do not use abrasive cleaners, steel brushes or other metal accessories as they can damage and scratch the surface. • Do not use solvents, benzene, or oil-based cleaners. • After cleaning is complete, tighten all visible nuts and screws to ensure smooth operation.
- Page 8 Fax: 91 8864285 NIF: B83254763 Manufacturing country: China Description: Stand fan Sytech® SY-VLP24R complies with the following directives: Standard EMC: Directive 2014/30/EU Standard ERP: Directive 2009/125/EC Standard LVD: Directive 2014/35/EU Standard ROHS: 2011/65/EU and its amendment (EU) 2015/863. Restriction of hazardous substances.
