- Page 1 OCEAN COMPACT CRADLE Owner’s Manual REV01 YOUR SAFETY OUR WORLD...
- Page 2 CONTENTS INTRODUCTION Introduction Warning Safety Strapping PREPARATION Fixing pack Tools required Positioning the cradle CONSTRUCTION MOUNTING STRAPPING MANUALLY RELEASING THE LIFERAFT CARE & MAINTENANCE Owner’s Manual...
- Page 3 ALWAYS use a drill that is suitable for the surface that is being drilled. DO NOT use abrasive or chemical cleaners as these may damage the product. 1.4 Ocean Safety recommend the use of Ocean Safety strapping products to secure the raft into the cradle (these are not included).
- Page 4 2.0 PREPARATION 2.1 FIXING PACK A. Feet x4 B. Length beam x2 C. Width beam x2 D. Long strap with two bar buckle x1 (Not included) E. Long strap x1 (Not included) F. Short strap x1 G. M12X25 bolt x8 H.
- Page 5 fitting or usage of the cradle. 2.3.2 If the cradle is fitted on top of or affected by an obstruction, Ocean Safety will not be liable for any failure of the product or its operation.
- Page 6 3.0 CONSTRUCTION 3.1 Bolt the length beam (B) onto two 3.2 Thread the strap loops (E) through the separate feet (A) using the bolt (G) and D shackles (J) and attach the shackle onto nut (H). Tighten using a 17mm spanner. the outer holes of the beam.
- Page 7 3.7 Position the liferaft into the assembled cradle. Ensure the gap between the raft and the cradle feet does not exceed 2-5mm on all sides. If it does not fit within the cradle as described, contact Ocean Safety or your local approved service centre. 2-5mm gap...
- Page 8 4.0 MOUNTING NOTE: FIXINGS FOR MOUNTING ARE NOT SUPPLIED. THEY WILL VARY ON THE DECK THE CRADLE IS FIXED TO. OCEAN SAFETY WILL NOT TAKE RESPONSIBILITY FOR INCORRECT FIXINGS. 4.1 Position the cradle onto the desired area of flat deck 4.2 Mark x8 foot holes on...
- Page 9 5.0 STRAPPING 5.1. Once the cradle is secured to the deck, position the lifraft in the cradle. Secure by pulling the two longest straps over the top of the container. Straps fed around the top of the cradle. 5.2 If fitting a Hammar Hydrostatic release unit, go to step 5.4 otherwise follow step 5.3. 5.3 Attach the D shackle to the pelican hook.
- Page 10 5.0 STRAPPING 5.5 Take the end of the strap that had been fed through the D shackle back up to the buckle, ensuring it is not twisted. Feed the strap through the buckle. Ensure the strap is fed through the buckle as per the diagram below. Cross section of buckle and strapping feed.
- Page 11 6.0 MANUALLY RELEASING THE LIFERAFT NOTE: THE LIFERAFT MUST ONLY BE REMOVED FROM THE CRADLE IN AN EMERGENCY OR TO BE SERVICED. 6.1 The raft is manually released by pushing down the ring on the pelican hook. Once complete the liferaft can be lifted out the cradle. Push ring off the hook.
- Page 12 Check the cradle has not moved or fixings have not loosened Check the deck it is fitted to has not weakened If any concerns contact your nearest Ocean Safety service station If any part of the product is damaged or faulty replace immediately...
- Page 13 OCEAN SAFETY Saxon Wharf Lower York Street Southampton Hampshire SO14 5QF Tel: +44 (0)2380 720800 Email: info@oceansafety.com Web: www.oceansafety.com YOUR SAFETY ZZZOSL8121 REV01 OUR WORLD...
