Summary of Contents for POWEROLOGY P25CMAPBK
- Page 1 Powerology Super Compact Tire Inflator SKU: P25CMAPBK...
- Page 2 Table of Contents Schematic View Usage Warning Instructions for Use Charging and Battery Indicator Usage of Accessories Pressure Detection Recommended Pressure Mode Switching Pressure Adjustment Start Inflation Stop Inflation Important Notes Specifications Troubleshooting Error Code Guide Warranty Contact Us...
- Page 3 Before using the product, please carefully read this User Manual to guarantee correct usage and keep it secure for future reference. Schematic View Battery Level Display Pressure Unit Display (Psi) Actual Pressure Display Value Usage Mode Increase Pressure Key Decrease Pressure Key Power On/Off Key Air Outlet Heat Dissipation...
- Page 4 Usage Warning For Tires with Existing Air Pressure: Activate the device by turning on the power. Engage the inflation pump to begin operation. Attach the tire valve and proceed with inflation. For Completely Flat Tires: the tire valve nozzle to the tire. Start the inflation pump to inflate the tire.
- Page 5 Note After the air pump operates continuously for three minutes, it must rest for eight minutes before being used again. The air pump's outlet may become hot. Avoid touching it. The software is programmed to automatically shut down after continuous operation for two and a half minutes as a safety feature.
- Page 6 Low Battery Indicator If the battery level falls below the designated voltage, the battery display will flash. The device will continue to operate until the voltage falls below the shutdown threshold, at which point it will power off automatically. Recharge the device when this occurs. Usage of Accessories American-style Nozzles: Suitable for mountain bikes, electric bikes, motorcycles, and cars.
- Page 7 Item Recommended Pressure Product Type Folding Bike Tire 45-50psi 12" ,14" ,16" Bicycle Tires 30-50psi 20" ,22" ,24" Bicycle Tires 40-50psi Bicycle 26" ,27.5" ,29" Bicycle Tires 45-65psi 700c Road Bike Hard Tire 100-110psi 700c Road Bike Soft Tire 100-130psi Motorcycle, Electric Motorcycle 30-43psi...
- Page 8 Mode Switching Press the "-" key to cycle through three inflation scenarios. There is no special mode. The device is preset to 45 psi, but the pressure can be adjusted freely between 3-150 psi before use. Bicycle Mode: Default setting at 45 psi, adjustable from 145-30 psi.
- Page 9 high-pressure hose and the device body. Avoid prolonged contact to prevent discomfort. Stop Inflation The inflation pump will automatically cease operation once the preset pressure value is achieved. During inflation, you may manually stop the process at any time by pressing the 'Start/Stop' button. Important Notes For inflatable items such as balloons, toy balls, and swim rings, the pump may not automatically stop if the required inflation...
- Page 10 The product contains a non-removable lithium battery. Do not discard it in fire or expose it to high temperatures to avoid overheating, impact damage, spontaneous combustion, or explosion. Do not store it in vehicles or fold the inflation hose during use to ensure proper airflow.
- Page 11 Specifications Battery Capacity 1000mAh (500mAh ×2) Input 5V/1.5A Charging Port Type-C Recharge Time 1 Hour 15mins Inflation Pressure 3Psi (Minimum), 11OPsi (Maximum) Pressure Accuracy ±0.15bar Inflation Speed 12-15L/min Product Weight 157g Product Dimensions 75.8×51.8×35.9mm Operating Temperature Charging: 0°C to 60°C, Discharging: -10°C to 45°C Storage Temperature -10°C to 60°C Troubleshooting...
- Page 12 Issue: Unable to adjust pressure up or down Solution: Ensure that the device is in the correct scenario mode. Select the pressure-free mode (with no illuminated icons), then adjust the preset pressure within the range of 3-150 psi. Issue: Normal inflation but the pressure reading shows zero Solution: Items like balloons or products with low pressure might be outside the device's measurable range.
- Page 13 Er6: Sensor NTC damaged, open or short circuit, detected during the power-on process. Displays 'Er6', stops the motor, and enters standby mode. Er7: Pressure exceeds 150 psi, detected during the pressure measurement process. Displays 'Er7' as a reminder. Er8: Battery over-temperature (high or low), detected during the charge/discharge process.
- Page 14 Warranty Products that you buy directly from our Powerology website or shop come with a 24-month warranty. The 24-month warranty applies to products purchased directly from our Powerology website or store. If Powerology products are bought from any of our verified retailers, then the product is eligible for only a 12-month warranty.
