Built-in Electric Induction Cooker
User Manual
[Revision 4.0 October 2018]
READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY DAMAGE AND
MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by this manual may vary in
appearance, assembly, inclusions, specifications, description and packaging.
Advertisement
Related Manuals for EUROCHEF EUC-IN58R
Summary of Contents for EUROCHEF EUC-IN58R
- Page 1 Built-in Electric Induction Cooker User Manual [Revision 4.0 October 2018] READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY DAMAGE AND MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by this manual may vary in appearance, assembly, inclusions, specifications, description and packaging.
- Page 2 Table of Contents Safety................................2 Set-Up ................................3 Operation ................................. 5 Suitable Utensils ............................... 6 Unsuitable Utensils ..............................6 Maintenance ..............................7 Specifications ..............................7 E&OE © 2018 Eurochef...
- Page 3 Do not use nearby any other sources of heat. Elements Never directly wash the cooker with water so as to can react and cause unexpected combustion. avoid danger. E&OE © 2018 Eurochef...
- Page 4 50mm space shall be preserved around the hole. Be sure the thickness of the table surface is at least 30mm. Please select heat-resistant table material to avoid large deformation caused by the heat radiation from the cooker. As shown below: E&OE © 2018 Eurochef...
- Page 5 3. Connect to the mains using the 3*1.5²mm power lines including one earth line (yellow/green), two live lines (brown/black) and two neutral lines (blue and gray). The socket shall be connected according to the relevant standard or connected to a single-pole cut-out. The method of connection is shown below: E&OE © 2018 Eurochef...
- Page 6 E5: The cooking surface has over heated or dry boiled (pot has boiled away all water and has been left on). Please turn off your product and allow to cool for 30 mins. • All other error codes (E1, E2, E3, E4 & E6) will require the product to be returned for inspection. E&OE © 2018 Eurochef...
- Page 7 Power button is pressed. Anti-heating glass pan/pot Pot with curve bottom Pottery Pot Pot with legs Outer Diameter less than 12 cm Alloy with low iron content E&OE © 2018 Eurochef...
- Page 8 Frequency 50/60HZ Total power 6,800W Front left element Φ 220mm 2000W Front right Φ 175mm, 1400W element Rear left element Φ 220mm, 1400W Rear right element Φ 175mm 2000W Note: Requires installation by a licensed electrician. E&OE © 2018 Eurochef...
- Page 9 ©2018 Eurochef. All rights reserved. No part of this document, including descriptive content, concepts, ideas, diagrams or images may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying, scanning or recording, or any information storage and retrieval system, without express permission or consent from the publisher.
