Mediclinics DJ0050A Manual

General Description
Automatic liquid soap or hand sanitizer gel dispenser, with a capacity of
•
1.2 liters, made of high-impact ABS plastic. Activates automatically
without the user touching the dispenser to reduce cross-contamination
•
and germ spread.
• Elegant and modern design, allowing the dispenser to seamlessly
integrate into any space.
Ideal for installation in bathrooms, kitchens, offices, schools, banks,
•
hospitals, hotels, and restaurants.
• Equipped with a soap content level indicator, located on the front,
allowing constant monitoring of the soap level available inside the
dispenser.
• Fitted with a security lock that opens with a special key provided, to help
prevent tampering, vandalism, and soap theft in public places, while
ensuring hygiene.
• Operates with four alkaline batteries 4 AA LR6 (not included).
• Suitable for liquid soap or hand sanitizing gels.
• It is recommended to use liquid soap or gel-type disinfectant soap with
the following characteristics: Maximum alcohol content of 80%
Density between 0.9 and 1.35 kg/dm3
Viscosity between 500 and 2,500 cps.
No hydroalcoholic soaps/gels containing methanol, chlorine,
nor solid particles or abrasives are permitted
• Wall mounting is achieved through four stainless steel screws with a
diameter of 4 mm (supplied) along with corresponding plastic wall
plugs with a diameter of 6 mm (also supplied).
Components & materials
CASING: Manufactured with high-impact ABS plastic, 3.0 mm thick
•
(DJ0050A), or manufactured with satin-finished AISI 304 stainless
steel (DJ0050ACS), with a level indicator on its front part. It features
an opening at the top thanks to a security lock that opens with the
special key provided.
WALL MOUNTING PLATE: Made of 2.8 mm thick ABS plastic. It is
•
mounted on the wall using four M4 stainless steel screws (supplied)
with their corresponding Ø 6mm plastic wall plugs (also supplied).
• INNER TANK: Manufactured with 1.5 mm thick plastic.
• ANTI-DRIP VALVE: Corrosion-resistant, dispensing 1.2 ml of soap
per service.
8-OP-DO-FT
SURFACE
DJ0050A
White finish
SOAP DISPENSERS
Automatic
DJ0050ACS
Bright finish
Technical specifications
Dimensions
Maximum capacity
Thickness of the casing
Thickness of the wall mounting 2,8 mm
Thickness of the soap tank
Net weight
Quantity dispensed per pump
/pulsación
Dimensions
Dimensions ± 4%
234 x 140 x 102 mm
1,2 L
3,0 mm
1,5 mm
0,7 Kg
1,2 ml
