F i g u r e 4 : A d v a n c e d C a b l e T e s t e r v 2 H a r d w a r e w i t h b r a c k e t s i n s t a l l e d .
O p t i o n a l m o u n t i n g b r a c k e t s c a n b e i n s t a l l e d o n t h e A C T v 2 t e s t e r s o t h a t i t c a n b e s e c u r e d t o
a w o r k s u r f a c e . T o i n s t a l l t h e b r a c k e t s , s i m p l y r e m o v e t h e s c r e w s a s s h o w n i n t h e d i a g r a m
b e l o w . T h e b r a c k e t c a n t h e n b e a t t a c h e d t o t h e A C T v 2 w i t h t h e p r o v i d e d s c r e w s .
3.2 Software Specifications
T h e w e b i n t e r f a c e r e q u i r e s t h e l a t e s t v e r s i o n o f M o z i l l a F i r e f o x o r G o o g l e C h r o m e w e b
b r o w s e r
T e s t P r o l e s : H e l d i n n o n - v o l a t i l e s t o r a g e o n t h e P r o m i r a p l a t f o r m
T e s t R e s u l t s : U p t o 1 m i l l i o n t e s t r e s u l t s a r e s t o r e d i n a c i r c u l a r b u e r i n n o n - v o l a t i l e
s t o r a g e .
3.3 Physical Specifications
P o w e r S u p p l y : 1 0 0 - 2 4 0 V 5 0 / 6 0 H z A C - a d a p t e r i n c l u d e d
D i m e n s i o n s : W x D x L : 3 0 . 5 x 2 7 . 3 x 1 0 . 2 c m ( 1 2 . 0 x 1 0 . 8 x 4 . 0 i n )
W e i g h t : 3 . 8 k g ( 8 . 4 l b s )
O p e r a t i n g T e m p e r a t u r e : 1 0 ° t o 3 5 ° C ( 5 0 ° t o 9 5 ° F ) n o n - c o n d e n s i n g
4 Advanced Cable Tester v2 Hardware
