Summary of Contents for Universal Power Group universal battery LFP12120
- Page 1 UPG No. 48042 universal battery® LiFeP04 (LFP) Battery 12V12AH NEXT GENERATION |iox| Ultra light weight 1 O X the cycle life Smart Battery Charges 3X faster Management System COMP A RE D TO SEALED L E A D - A C I D BATTERIES...
- Page 2 Hello. Welcome to the future of battery technology » Custom engineered for exceptional power, our Universal Battery® LiFeP04 (LFP) batteries are the future in battery technology. Ultra-light weight and more powerful than traditional sealed lead-acid batteries, Universal Battery® LFP batteries deliver the best performance in the most extreme environments.
- Page 3 Battery Usage The two most damaging conditions for any battery are prolonged storage at high temperatures and allowing the battery to be deeply discharged. Compared to lead-acid batteries, LFP batteries have a slower self-discharge rate and therefore can be stored much longer without a charge. LFP batteries can be stored one year or more without damage.
- Page 4 W A R N IN G : Risk of fire, explosion, and bums. Do not disassemble, crush, heat above 100°C (212°F), or incinerate. Dispose of used batteries promptly according to local recycling or waste regulations. Keep batteries out of the reach of children. Never put batteries in mouth.
- Page 5 Specifications _______________________ 12.8 Volts______ Nominal Voltage ______________________ 77° F (25° C) Nominal Capacity 20-hr. (.60 A)________________________ 12.0 Ah_______ 10-hr. (1.2 A)________________________ 12.0 Ah_______ 5-hr. (2.4A)________________________ 12.0 Ah_______ 2-hr. (5.7 A)________________________ 11.4 Ah_______ ____________________ 2.7 lbs (1.22 kgs) Approximate Weight (approx.)______________ <100mQ______ Internal Resistance (% of normal capacity at 68°...
- Page 6 Parallel or Series Parallel Connection You can place a maximum of four batteries in a series for: - 24V system with two in series - 36V system with three in series - 48V system with four in series (Maximum of 4 batteries in series) You can place a maximum of two of these batteries in parallel for: - Two 12v 103Ah in parallel for a 12V 206Ah system, (Maximum of two parallel strings) - Two 12v 12Ah in parallel for a 12V 24Ah system, (Maximum of two parallel strings)
- Page 7 Battery Maintenance - Keep battery clean and free from debris, corrosion or build-up of any kind. - Charge and discharge according to battery specifications. - Please dispose of the battery at your nearest recycling center. Battery Installation Please check battery voltage before use. Battery terminals must be clean to secure a proper connection.
- Page 8 LIMITED WARRANTY STATEMENT Universal Power Group (UPG) warrants your unit to be free from defects in material and workmanship for a period of 2 years from the date of sale to the original user or purchaser. This warranty is non-transferable. If your unit malfunctions or fails within the 2 year period because of a defect in material or workmanship, we will replace or repair the unit.
