Summary of Contents for Metal Arsenal ECCOTARP
- Page 1 Temperature alarm OPERATING AND SETTINGS MANUAL Metal Arsenal s.r.o. T +420 737 802 153 E info@eccotarp.com Poděbradova 1920 T +420 777 472 640 289 22 Lysá nad Labem Owner of Eccotarp www.eccotarp.com Czech Republic T +420 603 117 839 trade mark...
- Page 2 Contents Basic information Characteristics of the Temperature alarm and the contents of the packaging Technical data Safety instructions Charging Instructions for Temperature alarm charging Battery specification Power supply adapter specification Temperature alarm battery charging indicator Settings Basic settings of the Temperature alarm PIN code setting Changes in device settings Operation...
- Page 3 Basic information 1.1 Characteristics of the temperature alarm and the contents of the packaging This document describes the operation and characteristics of the temperature alarm (hereinafter referred to as “alarm” or “device”) and the way of its use as well as possible risks connected with its use.
- Page 4 1.2 Technical data Name Dimensions (mm) Weight (g) Temperature alarm 190 × 115 × 120 1760 Optional accessories at extra cost Siren Beacon Special temperature sensors (other lengths) You can find information about accessories Signal strength Data Battery on page 18. indicator connection charging...
- Page 5 1.3 Safety instructions for 1.3.1 Using the Temperature Alarm When using the alarm, observe these instructions as well as all the safety notices herein. The alarm is intended for measuring the 10. Protect the alarm from direct sunlight. If the alarm temperature of electric batteries.
- Page 6 10. Do not cover the power supply adapter or the alarm 13. Never use a damaged power supply adapter. If it is during the charging process. damaged, please, send it to the manufacturer for repair or replacement. 11. If the alarm is not charged within 5–10 hours, interrupt the charging process.
- Page 7 2.3 Power supply adapter specifications Název Charging station 12 V Mains voltage 100–240 VAC Charging time 5-15 hours 2.4 Temperature alarm battery charging indicator The battery charging level is indicated by a blue icon in the upper right corner of the alarm display. The icon is divided into 5 segments. Each segment represents approximately 20% of battery charging.
- Page 8 connection (up to 100MB per month). Use a cross-point screwdriver (not included) to unscrew the cover protecting the SIM card slot. After the device is turned on, it automatically connects to the mobile operator. Caution! Before you insert the SIM card into the slot, make sure that k it is registered in the mobile operator’s network;...
- Page 9 3.1.1 Using the external keyboard to set the technical data If you have not done so yet, insert the external keyboard’s connector into the USB port marked as “Keyboard” on the side of the device. The external keyboard automatically works in the EN keyboard mode. Turn on Numlock.
- Page 10 9.3 Use the letters on the keyboard to enter the email address. 9.4 The @ character is available on the EN keyboard: press the left Shift key and the 2 key in the upper keyboard line. 9.5 After the complete email address has been entered it must be confirmed and saved.
- Page 11 3.1.2 Setting the technical data without using the external keyboard All the alarm data can be set by using the arrow buttons on the top of the device. Press the down arrow to go to the Temperature limit and SMS contacts settings section.
- Page 12 After entering the ID, press the down arrow to go to the last alarm settings screen. Enter your mobile operator’s APN code in the same way as the telephone numbers and email addresses. After entering the APN code, use the down arrow to go to Periodic 6 hour report, where you choose whether (YES) or not (NO) you want to be sent periodic sensor temperature reports.
- Page 13 3.2 PIN code setting – protecting the device against unauthorised changes to the settings We recommend that only a responsible person is allowed to administer the device. The factory setting of the device is provided with a PIN code of 0000 (the words „zerozerozerozero“). The PIN code can be set by using the external keyboard or the arrow buttons on the top of the device.
- Page 14 3.3.2 Temperature alarm with individual PIN code (XXXX) The device administrator must be a qualified person. Device administration can be done in two ways: using the connected external keyboard or using the arrow buttons on the top of the device. The external keyboard works in the EN mode.
- Page 15 4.2 Temperature alarm installation (e.g. in a monitored vehicle) Put the charged, set and activated (turned-on) alarm with the temperature sensors connected to it and with any connected accessories on the monitored surface so that the whole surface of the T1, T2 and T3 sensors touches the monitored device.
- Page 16 4.3 Mobile operator connection quality test; Accessories (siren and beacon) functionality test Before turning the alarm on for operation and before putting it, for example, into the monitored vehicle, it is recommended to perform mobile operator’s connection quality and a test of accessories quality. This test confirms the functional connection between the alarm and the telephone numbers (email addresses) of the defined recipients of regular and warning messages.
- Page 17 4.4 The Sleep mode After five minutes of no activity (none of the buttons on the top of the alarm are pressed), the alarm goes into the Sleep mode (energy-saving mode), in which it continuously measures vehicle battery temperature but the display is not activated.
- Page 18 After the device has been fully charged, it is automatically disconnected from the charger. If the device remains connected to the charger, charging automatically re-starts after the battery charge level decreases below 80%. If battery capacity decreases under 20%, the device sends an information SMS to the defined recipients. If the alarm fails to send the information email about sensor temperatures three times, an SMS about this problem is sent to the defined recipients.
- Page 19 5.4 Important contact information Manufacturer and qualified service: Metal Arsenal s.r.o. Poděbradova 1920 289 22 Lysá nad Labem Czech Republic info@eccotarp.com T: +420 737 802 153 T: +420 777 472 640 T: +420 603 117 839 5.5 Repair Any repair work must always be done by the manufacturer’s qualified personnel. In order to report any malfunction, order spare parts or lodge a complaint, please contact only your qualified supplier.
- Page 20 Warranty certificate The warranty period is 24 months. The warranty covers: defects caused by manufacturing defects of the material used and any other damage, not caused by demonstrable mishandling by the user or any modification of the product. The warranty does not cover: damages caused by improper handling and use of the product and failure to follow the „user manual“...
