Summary of Contents for Castellari RY10H
- Page 1 RY10H...
- Page 2 1.1 Purpose of the Manual ..................3 1.2 Subjects to whom the manual is addressed ............3 1.3 Intended and Unintended Uses of the Machine ............. 4 RY10H Machine Packing Content ..............4 SAFETY AND PREVENTION ................4 2.1 Protection and safety devices ................5 2.2 General Safety Rules ...................
- Page 3 1. INTRODUCTION AND USES 1.1 Purpose of the Manual This manual contains the instructions necessary for the correct and safe use of the RY10H electric olive harvester, hereinafter also referred to as the "machine", distributed by Castellari S.r.l., of Imola (BO). Before using the machine, it is important to read and carefully follow the...
- Page 4 1.3 Intended and Unintended Uses of the Machine Intended use: The Model RY10H battery-powered electric rake is designed and built for olive harvesting. No other use is intended. Castellari srl,...
- Page 5 2.1 Protection and safety devices The machine is equipped with safety devices to protect the operator from all moving parts of the machine. Protective casing: Fixed device that prevents direct contact with moving parts or dangerous parts of the machine. The protection can only be removed by using special tools.
- Page 6 Keep out of reach of children 3. Machine identification and technical data The RY10H is a machine designed to make olive harvesting easier and easier in complete respect of the plant. The shape and movement of the rake teeth are in fact such as to prevent violent mechanical stresses that could damage the plant.
- Page 7 Vibration risk 3.2.2 The vibration level was measured with the machine in motion in accordance with the UNI EN SO 5349-2 : 2015 standard for the evaluation of vibrations transmitted to the HAND-ARM system. The following value has been collected: Hand-arm vibration level: 4.42 m/s2 considering the heaviest use of machines open 3 m.
- Page 8 4.3 Connection Machines should only be connected to a well-charged battery via the terminals at the end of the supplied power cable. For a day's work we recommend a 12V 80A battery (not supplied). Terminal connection mode: make sure the power button is in the OFF position. connect the RED CLAMP to the battery at the + SIGN connect the BLACK CLAMP to the battery at the MARK -...
- Page 9 NB: Avoid touching the moving parts of the machine in any way. To switch off the machine, simply turn the switch back to the opposite position to the on/off position. In the event that the machine is temporarily not in use, it is important to place it in a stable horizontal position in order to avoid risky falls.
- Page 10 5. RY10H Components...
- Page 11 POS. COD. DESCRIPTION QUANTITY RY10H01 12 MT CABLE RY10H02 CARBON SPOKES 35CM RY10H03 UPPER CARTER RY10H04 LOWER CARTER RY10H05 CARTER SCREW KIT RY10H06 LOCKS SPOKES RY10H07 SPOKES SUPPORT SET RY10H08 ROD SUPPORT SCREW KIT RY10H09 COMPLETE DRIVE SET RY10H10 MOTOR SET RY10H11 ROD SET COMPLETE WITH CABLE RY10H12...
- Page 12 Gloves Protectors Protective goggles Helmet Non-slip shoes and anti-crush Adjustments, when the safety devices are disengaged or without casing, must be carried out by a single specialised operator; During these operations, access to the machine is prohibited to non-professionals. Avoid dust deposits on the machine, especially on the electric motor and suction filters.
- Page 13 Clean the machine, freeing it from any dirt residues. check and replace the parts damaged/worn by use at a specialised Castellari service centre. Cover the machine to avoid the deposit of dust and dirt.
- Page 14 Check that the connectors are securely connected to each other. Check that the safety fuse is functional. If all this is not enough, take the machine to a Castellari service center. The machine runs slowly/the combs do not move: The engine or the moving parts may have a malfunction, take the machine to a Castellari service center.
- Page 15 "Construction of scissors for agriculture", Via Lasie 15/a - 40026 IMOLA (BO) ITALY I declare under my sole responsibility that the "RY10H" electric rake complies with the essential health and safety requirements required by Directive 2006/42/EC of the European Parliament and of the Council.
- Page 16 Via Lasie 15/A - 40026 IMOLA (Bo) Tel.39 0542.43659 - +39 0542628142 +39 0542 626930 www.castellarisrl.com - info@castellarisrl.com...
