Sealey AP4804SS.V2 Instructions

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to Wear protective
instructions gloves
1. SAFETY
WARNING! Ensure Health & Safety, local authority, and general workshop
‰
practice regulations are adhered to when using this product.
Locate in a suitable work area.
9
DO NOT let children near the cabinet.
8
DO NOT open more than one drawer at a time.
8
Fill from the bottom drawer up. If the tool cabinet is filled from the top drawer
9
down, it will be top heavy and may fall over.
DO NOT attempt to lift by the side handles, use chains, ropes or other lifting
8
devices.
DO NOT step or climb on the product or on the drawers.
8
DO NOT alter the product in any way, e.g. DO NOT weld on external lock
8
bars or attach electrical equipment. This may cause damage to the product
or cause personal injury.
Keep on a level surface.
9
When moving the cabinet DO NOT pull it. Push the cabinet to prevent injury.
8
Close and lock the drawers before moving the cabinet. If the drawers came
9
open they could make the cabinet unstable.
Apply the brakes when in desired position.
9
DO NOT mount on a truck bed or any other moving object.
8
Be aware of sharp edges wear gloves.
9
2. INTRODUCTION
Anti-fingerprint stainless steel construction. Supplied with a 25mm thick wooden worktop. Four drawers with 45kg capacity each. Each
drawer features aluminium pull handles and non-slip liners. Side storage cupboard with shelf and pegboard inlay. Four large castor
wheels, two fixed and two swivel that include brakes. Cabinet supplied with a heavy-duty side handle for comfort and control when
manoeuvring. Supplied with a lock and two keys. Some simple assembly required.
3. SPECIFICATION
MODEL NO:
Nett Weight:
Overall Size (W x D x H):
Small Drawer (x1):
4. ASSEMBLY
4.1. FIT HANDLE
4.1.1. Attach handle with 6mm x 12mm hex bolts, spring and flat
washers.
4.2. FIT CASTERS
WARNING! Two or more people are required to lay down or stand
‰
up the cabinet. DO NOT stand in front or behind and lock drawers
whilst turning over.
4.2.1. Carefully lay the cabinet upside down with a soft mat underneath
for protection.
4.2.2. Fit the two swivel/braked castors, on the handle side using 10mm
x 25mm bolts, through each castor and into the bottom of the
cabinet. Tighten securely.
4.2.3. Repeat for the two rigid casters on the other side.
© Jack Sealey Limited
4 DRAWER STAINLESS STEEL
MOBILE TOOL CABINET
AP4804SS.V2
MODEL NO:
AP4804SS.V2
63kg
1220 x 460 x 976mm
690 x 399 x 60mm
Original Language Version
Medium Drawer (x2):
Large Drawer (x1):
Cupboard:
690 x 399 x 140mm
690 x 399 x 220mm
440 x 440 x 680mm
AP4804SS.V2 Issue 1 17/05/24
