Streetwize SWWCP1 Manual

7” wireless car screen with apple carplay & android auto
Hide thumbs

Advertisement

Quick Links

Download this manual
7" Wireless Car Screen
with Apple CarPlay & Android Auto
Contents
•
7-inch DVR with touchscreen display
•
12V Power cable
•
Mounting bracket
•
1080P Rearcam & AUX cable
Thank you for choosing the Streetwize 7" Wireless Car Display, Apple CarPlay & Android Auto.
This device is designed to enhance your driving experience by providing a seamless integration of
your smartphone with your vehicle's infotainment system.
SWWCP1

Advertisement

loading
Need help?

Need help?

Do you have a question about the SWWCP1 and is the answer not in the manual?

Questions and answers

Related Manuals for Streetwize SWWCP1

Summary of Contents for Streetwize SWWCP1

  • Page 1 • 1080P Rearcam & AUX cable Thank you for choosing the Streetwize 7” Wireless Car Display, Apple CarPlay & Android Auto. This device is designed to enhance your driving experience by providing a seamless integration of your smartphone with your vehicle’s infotainment system.

  • Page 2: Health And Safety Guidelines

    Health and Safety Guidelines • Always prioritise safe driving. Never use the touchscreen while driving. • Always adhere to all local traffic laws and regulations. • Install the device where it won’t obstruct your view or interfere with vehicle controls. •...
  • Page 3 Setting Up & Operation - Securing The Screen To Your Dashboard 1. Clean the surface: Ensure the surface of your dashboard is clean and dry before applying the mount. 2. Peel the adhesive backing: Remove the protective film from the adhesive base. 3.
  • Page 4 Rear View Camera Installation The rear-view camera should be installed at the rear of the car, preferably above the license plate. The camera can be fixed with stickers or screws. (Note: Before installing the screws, please check if the reversing camera is installed upside down.) The extra RED wire near the rear-view camera is used to sense the reversing state.
  • Page 5 Main Menu From here you can adjust the sound levels, screen brightness, play multimedia, use the recording function & access the system settings menu. Volume: Press this button to adjust the volume levels of your device. Brightness: Press this button to adjust the screen brightness. Screen: Press this button to quickly turn off the screen.

  • Page 6: System Settings Menu

    System Settings Menu From the main menu press the settings button to access the System Settings Menu to utilise the following functions. Loop Recording: Press this button to access the Loop recording settings. This can be set for 1, 3 or 5 minutes (Fig. 1). Fig.1 Car OSD: From this menu you can set your licence...
  • Page 7 Setting Guideline (with rearcam attached): Press this button to access the reverse parking assist settings (Fig. 4). Park the car in the middle of the parking space and adjust the position of the reversing assist line so that the reversing assist line levels the parking line on the left.
  • Page 8 Date Format: From this menu you can choose how to display the date on the device, choose from 3 options (Fig. 9). Fig.9 Format SD: Use this menu to format your SD card. Fig.10 Reset Factory: pressing this button will restore all the settings to the initial state.
  • Page 9 How To Connect To CarPlay CarPlay (iOS): 1. Turn on the Bluetooth and find the related device (Fig.10). 2. Connect with Bluetooth manually, or a pop-up window will appear for Bluetooth pairing; click “Pair.” (Fig.11). 3. Wait for the prompt “Use CarPlay with ‘zlink’?” and click to confirm (Fig.12). Fig.10 Fig.11 Fig.12...
  • Page 10 Apple AirPlay Setup 1. Select “AirPlay” from the menu. 2. Connect your phone to the device’s Wi-Fi hotspot (e.g., “TF790_xxx”). 3. Open the control centre on your iPhone and select “Screen Mirroring.” 4. Choose “zj-airplay” to mirror your phone to the display. Note: Some copyrighted content may not support screen mirroring and will appear as a black screen.
  • Page 11 Problem Solution • Check if your phone supports the feature. CarPlay/Android Auto not connecting. • Ensure the phone’s software and required apps are up to date. • Some apps restrict content from being Screen mirroring blackout. mirrored due to copyright. •...

  • Page 12: Technical Specification

    Technical Specification Product Name: 7” Wireless Car Screen with Apple CarPlay & Android Auto Product Code: SWWCP1 Display Size: 6.86inch 40PIN 1280*480 WiFi: l802.11ac/b/g/n 2.4G/5G Reversing Camera: 1080P@30FPS Car Charger: Input 12-24V; Output 5V/2.5A TYPE-C Streetwize, For Product Support: EU Regd. Address: Suite GA, Marsland House, E: support@streetwize.co.uk...
