ANTENNA GUIDE
About Omnisite
Our mission is to provide affordable and reliable
monitoring solutions. We aim to surpass customer
expectations by providing excellent products and
services that are innovative, easy to use, and protect the
environment.
VERSION 1.6
317-885-6330
support@omnisite.com
203 West Morris Street
Indianapolis, IN 46225
Advertisement
Summary of Contents for OmniSite S-ANT-CX-BM16-KIT
- Page 1 VERSION 1.6 ANTENNA GUIDE About Omnisite 317-885-6330 support@omnisite.com Our mission is to provide affordable and reliable monitoring solutions. We aim to surpass customer 203 West Morris Street expectations by providing excellent products and Indianapolis, IN 46225 services that are innovative, easy to use, and protect the...
- Page 2 USA. This antenna offers a simple, cost-effective way of providing cellular reception for your Omnisite monitoring product. This antenna can come from our factory pre- mounted on top of our NEMA 4X outdoor enclosure...
- Page 3 800-2500MHz Typical VSWR: ≤ 2.0 Peak Gain: + 11 dBi Impedance: 50 ohm Pattern: Directional Polarization: Linear Connector: SMA Male with 10’ cable Mounting Type: Mast Mount Mounting Method: Mast Clamp; U Bolt Length: 17.5” Width: 2.5” Height: 8.85” www.omnisite.com...
- Page 4 Extension Coax Cable Options Omnisite offers 4 different standard lengths of coax cable used for connection to the end of either our omnidirectional or directional high gain antenna (same coax cable can be used on either antenna) to extend the length of the coax cable in situations where the signal strength is...
- Page 5 Start wrapping the weatherproof tape from the BOTTOM FIRST, moving upward as wrapped, so the water runs off like shingles on a roof. Ensure water CANNOT penetrate wrap. www.omnisite.com...
- Page 6 Product Follow the steps closely below to correctly connect the Coax Cable from the Antenna to the OmniSite Unit. Please reference page 4 for a visual diagram. Make sure the unit is powered off. 1. Drill a ¾” inch hole at the bottom of the enclosure.
- Page 7 You will need to know if your unit has a Verizon or AT&T radio so you can point it toward the correct tower. If you do not know which service your OmniSite product is set for, you may contact customer support for this information. If you don’t know where the tower is, you can use an app like CellMapper or Network cell info Lite.
- Page 8 NEED HELP? We’re here to help! Call Omnisite technical support at 317-885-6330 and select the technical support option. Alternately, email support@omnisite.com. Our technicians are available M-F, 8am-5pm EST.
